Namespaces
	NodeBasePrivate

Classes
class	KernelBase

class	NodeLoader

class	PseudoNode

class	QueueReader
	Definition of the reader portion of the CPN queue class. More...

class	QueueReleaser

class	QueueWriter
	Definition of the writer portion of the CPN queue class. More...

class	Context
	The CPN::Context abstraction that holds all the global state for the process network. More...

class	ShutdownException
	An exception indicating that the Kernel has shut down. More...

class	TypeMismatchException
	An exception indicating that there is a type mismatch in the queue. More...

class	BrokenQueueException
	An exception indicating that the node tried to write to a shutdown queue. More...

class	IQueue
	Template class to do type conversion for reader end of the queue. More...

class	Kernel
	The Kernel declaration. More...

class	KernelAttr
	The attribute for the Kernel. More...

class	NodeAttr
	Attributes for a node. More...

class	NodeBase
	The definition common to all nodes in the process network. More...

class	NodeFactory
	The node factory provides a method for the kernel to create arbitrary user defined Nodes. More...

class	OQueue
	A template class to do type conversion for the writer end of the queue. More...

class	QueueAttr
	The attributes for a queue. More...

class	SimpleQueueAttr
	This is a simplified internal representation of the queue attributes needed to create a queue. This is for internal use only. More...

class	RemoteContext

class	RemoteContextClient
	This abstract class is the remote context client. More...

class	RemoteContextDaemon

class	RemoteContextServer
	the server for the remote context. More...

class	VariantCPNLoader

class	ConnectionServer

class	ThresholdQueue
	A version of the ThresholdQueue that provides the CPN Queue interface This queue implementation creates a memory mapped object which has as a minimum size the machine page size. So there is an effective minimum queue size. Any queue size less than the page size will be expanded to the page size. More...

class	ExternalEndpoint

class	LocalContext
	A local implementation of the Context interface. More...

class	PacketDecoder

class	PacketEncoder

struct	PacketHeader

class	Packet

class	PacketHandler

class	QueueBase
	The base class for all queues in the CPN library. More...

class	RemoteQueue

class	RemoteQueueBase

class	RemoteQueueHolder

Typedefs
typedef shared_ptr< NodeFactory >(*	CPNInitPrototype )(void)
	This is the prototype of the function that is called by the dynamic library loading facility. More...

typedef uint64_t	Key_t

typedef AutoLock< PthreadMutex >	AutoPLock

Enumerations
enum	RCTXMT_t { RCTXMT_SETUP_KERNEL, RCTXMT_GET_KERNEL_INFO, RCTXMT_SIGNAL_KERNEL_START, RCTXMT_SIGNAL_KERNEL_END, RCTXMT_CREATE_WRITER, RCTXMT_CREATE_READER, RCTXMT_CREATE_QUEUE, RCTXMT_CREATE_NODE, RCTXMT_CREATE_NODE_KEY, RCTXMT_SIGNAL_NODE_START, RCTXMT_SIGNAL_NODE_END, RCTXMT_GET_NODE_INFO, RCTXMT_GET_NUM_NODE_LIVE, RCTXMT_GET_CREATE_READER_KEY, RCTXMT_GET_READER_INFO, RCTXMT_GET_CREATE_WRITER_KEY, RCTXMT_GET_WRITER_INFO, RCTXMT_CONNECT_ENDPOINTS, RCTXMT_GET_READERS_WRITER, RCTXMT_GET_WRITERS_READER, RCTXMT_TERMINATE, RCTXMT_LOG }
	RCTXMT Remote Context Message Type These are the message types that the remote context uses to send information back and forth. More...

enum	QueueHintStatus { QUEUEHINT_DEFAULT = 0, QUEUEHINT_THRESHOLD, QUEUEHINT_RDMA }

enum	{ PACKET_SYNCWORD = 0xF1F0C0DE, PACKET_REVERSE_SYNCWORD = 0xDEC0F0F1, PACKET_HEADERLENGTH = 64 }
	some packet header constants. More...

enum	PacketType_t { PACKET_ENQUEUE, PACKET_DEQUEUE, PACKET_READBLOCK, PACKET_WRITEBLOCK, PACKET_ENDOFWRITE, PACKET_ENDOFREAD, PACKET_GROW, PACKET_D4RTAG, PACKET_FLUSH, PACKET_RESET, PACKET_ID_READER, PACKET_ID_WRITER }

Functions
bool	TypeCompatable (const std::string &type1, const std::string &type2)

template<class type >
std::string	TypeName ()

template<class type >
unsigned	GetTypeSize ()

template<>
unsigned	GetTypeSize< void > ()

	REGISTER_TYPE_NAME (void)

	REGISTER_TYPE_NAME (int8_t)

	REGISTER_TYPE_NAME (uint8_t)

	REGISTER_TYPE_NAME (int16_t)

	REGISTER_TYPE_NAME (uint16_t)

	REGISTER_TYPE_NAME (int32_t)

	REGISTER_TYPE_NAME (uint32_t)

	REGISTER_TYPE_NAME (int64_t)

	REGISTER_TYPE_NAME (uint64_t)

	REGISTER_TYPE_NAME (float)

	REGISTER_TYPE_NAME (double)

	REGISTER_TYPE_NAME (long double)

	REGISTER_TYPE (std::complex< int8_t >,"complex<int8_t>")

	REGISTER_TYPE (std::complex< uint8_t >,"complex<uint8_t>")

	REGISTER_TYPE (std::complex< int16_t >,"complex<int16_t>")

	REGISTER_TYPE (std::complex< uint16_t >,"complex<uint16_t>")

	REGISTER_TYPE (std::complex< int32_t >,"complex<int32_t>")

	REGISTER_TYPE (std::complex< uint32_t >,"complex<uint32_t>")

	REGISTER_TYPE (std::complex< int64_t >,"complex<int64_t>")

	REGISTER_TYPE (std::complex< uint64_t >,"complex<uint64_t>")

	REGISTER_TYPE (std::complex< float >,"complex<float>")

	REGISTER_TYPE (std::complex< double >,"complex<double>")

	REGISTER_TYPE (std::complex< long double >,"complex<long double>")

static QueueHintStatus	ParseQueueHintForMBS (std::string hint)

bool	ValidPacket (const PacketHeader *ph) CPN_LOCAL

void	InitPacket (PacketHeader *ph, uint32_t datalen, PacketType_t type) CPN_LOCAL

NodeAttr	MsgToNodeAttr (const Variant &msg)

SimpleQueueAttr	MsgToQueueAttr (const Variant &msg)

const char *	BoolString (bool tf)

Detailed Description

Namespace that seperates all the CPN specific names from the global namespace.

Author: John Bridgman

Typedef Documentation

typedef AutoLock<PthreadMutex> CPN::AutoPLock

Definition at line 35 of file ConnectionServer.cc.

typedef shared_ptr<NodeFactory>(* CPN::CPNInitPrototype)(void)

This is the prototype of the function that is called by the dynamic library loading facility.

Definition at line 39 of file NodeLoader.h.

typedef uint64_t CPN::Key_t

Key_t is used for all the keys for each of the objects.

Definition at line 79 of file common.h.

Enumeration Type Documentation

anonymous enum

some packet header constants.

Enumerator
PACKET_SYNCWORD
PACKET_REVERSE_SYNCWORD
PACKET_HEADERLENGTH

Definition at line 44 of file PacketHeader.h.

          {
         PACKET_SYNCWORD = 0xF1F0C0DE,
         PACKET_REVERSE_SYNCWORD  = 0xDEC0F0F1,
         PACKET_HEADERLENGTH = 64
     };

enum CPN::PacketType_t

The packet types.

Enumerator
PACKET_ENQUEUE
PACKET_DEQUEUE
PACKET_READBLOCK
PACKET_WRITEBLOCK
PACKET_ENDOFWRITE
PACKET_ENDOFREAD
PACKET_GROW
PACKET_D4RTAG
PACKET_FLUSH
PACKET_RESET
PACKET_ID_READER
PACKET_ID_WRITER

Definition at line 53 of file PacketHeader.h.

                       {
         PACKET_ENQUEUE,
         PACKET_DEQUEUE,
         PACKET_READBLOCK,
         PACKET_WRITEBLOCK,
         PACKET_ENDOFWRITE,
         PACKET_ENDOFREAD,
         PACKET_GROW,
         PACKET_D4RTAG,
         PACKET_FLUSH,
         PACKET_RESET,

         PACKET_ID_READER,
         PACKET_ID_WRITER
     };

enum CPN::QueueHintStatus

Enumerator
QUEUEHINT_DEFAULT
QUEUEHINT_THRESHOLD
QUEUEHINT_RDMA

Definition at line 328 of file Kernel.cc.

                          {
         QUEUEHINT_DEFAULT = 0,
         QUEUEHINT_THRESHOLD,
         QUEUEHINT_RDMA
     };

enum CPN::RCTXMT_t

RCTXMT Remote Context Message Type These are the message types that the remote context uses to send information back and forth.

Enumerator
RCTXMT_SETUP_KERNEL	Commands for dealing with kernels.
RCTXMT_GET_KERNEL_INFO
RCTXMT_SIGNAL_KERNEL_START
RCTXMT_SIGNAL_KERNEL_END
RCTXMT_CREATE_WRITER	Commands to tell other kernels to create objects.
RCTXMT_CREATE_READER
RCTXMT_CREATE_QUEUE
RCTXMT_CREATE_NODE
RCTXMT_CREATE_NODE_KEY
RCTXMT_SIGNAL_NODE_START
RCTXMT_SIGNAL_NODE_END
RCTXMT_GET_NODE_INFO
RCTXMT_GET_NUM_NODE_LIVE
RCTXMT_GET_CREATE_READER_KEY
RCTXMT_GET_READER_INFO
RCTXMT_GET_CREATE_WRITER_KEY
RCTXMT_GET_WRITER_INFO
RCTXMT_CONNECT_ENDPOINTS
RCTXMT_GET_READERS_WRITER
RCTXMT_GET_WRITERS_READER
RCTXMT_TERMINATE	Context commands.
RCTXMT_LOG

Definition at line 33 of file RCTXMT.h.

                   {
         RCTXMT_SETUP_KERNEL,
         RCTXMT_GET_KERNEL_INFO,
         RCTXMT_SIGNAL_KERNEL_START,
         RCTXMT_SIGNAL_KERNEL_END,
         RCTXMT_CREATE_WRITER,
         RCTXMT_CREATE_READER,
         RCTXMT_CREATE_QUEUE,
         RCTXMT_CREATE_NODE,
         RCTXMT_CREATE_NODE_KEY,
         RCTXMT_SIGNAL_NODE_START,
         RCTXMT_SIGNAL_NODE_END,
         RCTXMT_GET_NODE_INFO,
         RCTXMT_GET_NUM_NODE_LIVE,
         RCTXMT_GET_CREATE_READER_KEY,
         RCTXMT_GET_READER_INFO,
         RCTXMT_GET_CREATE_WRITER_KEY,
         RCTXMT_GET_WRITER_INFO,
         RCTXMT_CONNECT_ENDPOINTS,
         RCTXMT_GET_READERS_WRITER,
         RCTXMT_GET_WRITERS_READER,
         RCTXMT_TERMINATE,
         RCTXMT_LOG
     };

Function Documentation

const char* CPN::BoolString ( bool tf )

Definition at line 859 of file RemoteQueue.cc.

Referenced by CPN::RemoteQueue::LogState().

                                     {
         if (tf) {
             return "t";
         } else {
             return "f";
         }
     }

Here is the caller graph for this function:

template<class type >

unsigned CPN::GetTypeSize ( )

Definition at line 46 of file QueueDatatypes.h.

                            {
         return sizeof(type);
     }

template<>

unsigned CPN::GetTypeSize< void > ( )

inline

Definition at line 52 of file QueueDatatypes.h.

52 { return 1; }

void CPN::InitPacket	(	PacketHeader *	ph,
		uint32_t	datalen,
		PacketType_t	type
	)

inline

Definition at line 102 of file PacketHeader.h.

References PACKET_SYNCWORD.

Referenced by CPN::Packet::Init().

                                                                                             {
         memset(ph, 0, sizeof(PacketHeader));
         ph->syncWord = PACKET_SYNCWORD;
         ph->dataLength = datalen;
         ph->dataType = type;
     }

Here is the caller graph for this function:

NodeAttr CPN::MsgToNodeAttr ( const Variant & msg )

Definition at line 215 of file RemoteContextClient.cc.

References CPN::NodeAttr::SetKernel(), CPN::NodeAttr::SetKey(), and CPN::NodeAttr::SetParam().

Referenced by CPN::RemoteContextClient::DispatchMessage().

                                                {
         NodeAttr attr(msg["name"].AsString(), msg["nodetype"].AsString());
         attr.SetKernel(msg["kernel"].AsString());
         attr.SetKey(msg["key"].AsNumber<Key_t>());
         if (msg.Contains("param")) {
             for (Variant::ConstMapIterator i = msg["param"].MapBegin(), e = msg["param"].MapEnd();
                     i != e; ++i)
             {
                 attr.SetParam(i->first, i->second.AsString());
             }
         }
         return attr;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

SimpleQueueAttr CPN::MsgToQueueAttr ( const Variant & msg )

Definition at line 250 of file RemoteContextClient.cc.

References CPN::SimpleQueueAttr::SetAlpha(), CPN::SimpleQueueAttr::SetDatatype(), CPN::SimpleQueueAttr::SetHint(), CPN::SimpleQueueAttr::SetLength(), CPN::SimpleQueueAttr::SetMaxThreshold(), CPN::SimpleQueueAttr::SetMaxWriteThreshold(), CPN::SimpleQueueAttr::SetNumChannels(), CPN::SimpleQueueAttr::SetReaderKey(), CPN::SimpleQueueAttr::SetReaderNodeKey(), CPN::SimpleQueueAttr::SetWriterKey(), and CPN::SimpleQueueAttr::SetWriterNodeKey().

Referenced by CPN::RemoteContextClient::DispatchMessage().

                                                        {
         SimpleQueueAttr attr;
         attr.SetHint(msg["queuehint"].AsString());
         attr.SetDatatype(msg["datatype"].AsString());
         attr.SetLength(msg["queueLength"].AsUnsigned());
         attr.SetMaxThreshold(msg["maxThreshold"].AsUnsigned());
         attr.SetNumChannels(msg["numChannels"].AsUnsigned());
         attr.SetReaderKey(msg["readerkey"].AsNumber<Key_t>());
         attr.SetWriterKey(msg["writerkey"].AsNumber<Key_t>());
         attr.SetReaderNodeKey(msg["readernodekey"].AsNumber<Key_t>());
         attr.SetWriterNodeKey(msg["writernodekey"].AsNumber<Key_t>());
         attr.SetAlpha(msg["alpha"].AsDouble());
         attr.SetMaxWriteThreshold(msg["maxwritethreshold"].AsUnsigned());
         return attr;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

static QueueHintStatus CPN::ParseQueueHintForMBS ( std::string hint )

static

Definition at line 334 of file Kernel.cc.

References QUEUEHINT_DEFAULT, QUEUEHINT_RDMA, and QUEUEHINT_THRESHOLD.

Referenced by CPN::Kernel::CreateLocalQueue(), CPN::Kernel::CreateReaderEndpoint(), and CPN::Kernel::CreateWriterEndpoint().

                                                                 {
         static const char threshold_str[] = "threshold";
         static const char *threshold_end = threshold_str + sizeof(threshold_str) - 1;
         static const char rdma_str[] = "rdma";
         static const char *rdma_end = rdma_str + sizeof(rdma_str) - 1;
         bool match = true;
         std::string::iterator h_cur = hint.begin();
         std::string::iterator h_end = hint.end();
         for (const char *cur = &threshold_str[0]; cur != threshold_end; ++cur) {
             if (h_cur == h_end || *h_cur != *cur) {
                 match = false;
                 break;
             }
             ++h_cur;
         }
         if (match) { return QUEUEHINT_THRESHOLD; }
         match = true;
         h_cur = hint.begin();
         for (const char *cur = &rdma_str[0]; cur != rdma_end; ++cur) {
             if (h_cur == h_end || *h_cur != *cur) {
                 match = false;
                 break;
             }
             ++h_cur;
         }
         if (match) { return QUEUEHINT_RDMA; }
         return QUEUEHINT_DEFAULT;
     }

Here is the caller graph for this function:

CPN::REGISTER_TYPE	(	std::complex< int8_t >	,
		"complex<int8_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< uint8_t >	,
		"complex<uint8_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< int16_t >	,
		"complex<int16_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< uint16_t >	,
		"complex<uint16_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< int32_t >	,
		"complex<int32_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< uint32_t >	,
		"complex<uint32_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< int64_t >	,
		"complex<int64_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< uint64_t >	,
		"complex<uint64_t>"
	)

CPN::REGISTER_TYPE	(	std::complex< float >	,
		"complex<float>"
	)

CPN::REGISTER_TYPE	(	std::complex< double >	,
		"complex<double>"
	)

CPN::REGISTER_TYPE	(	std::complex< long double >	,
		"complex<long double>"
	)

CPN::REGISTER_TYPE_NAME ( void )

CPN::REGISTER_TYPE_NAME ( int8_t )

CPN::REGISTER_TYPE_NAME ( uint8_t )

CPN::REGISTER_TYPE_NAME ( int16_t )

CPN::REGISTER_TYPE_NAME ( uint16_t )

CPN::REGISTER_TYPE_NAME ( int32_t )

CPN::REGISTER_TYPE_NAME ( uint32_t )

CPN::REGISTER_TYPE_NAME ( int64_t )

CPN::REGISTER_TYPE_NAME ( uint64_t )

CPN::REGISTER_TYPE_NAME ( float )

CPN::REGISTER_TYPE_NAME ( double )

CPN::REGISTER_TYPE_NAME ( long double )

bool CPN::TypeCompatable	(	const std::string &	type1,
		const std::string &	type2
	)

Definition at line 28 of file QueueDatatypes.cc.

Referenced by CPN::IQueue< T >::IQueue(), and CPN::OQueue< T >::OQueue().

                                                                         {
         if (type1 == "void") {
             return true;
         }
         if (type2 == "void") {
             return true;
         }
         return type1 == type2;
     }

Here is the caller graph for this function:

template<class type >

std::string CPN::TypeName ( )

Definition at line 40 of file QueueDatatypes.h.

                          {
         return typeid(type).name();
     }

bool CPN::ValidPacket ( const PacketHeader * ph )

inline

Definition at line 98 of file PacketHeader.h.

References PACKET_SYNCWORD.

Referenced by CPN::Packet::Valid().

                                                               {
         return ph->syncWord == PACKET_SYNCWORD;
     }

Here is the caller graph for this function:

Namespaces

Classes

Typedefs

Enumerations

Functions

Detailed Description

Typedef Documentation

Enumeration Type Documentation

Function Documentation
