CPN::RemoteContextDaemon Class Reference

#include <RemoteContextDaemon.h>

Inheritance diagram for CPN::RemoteContextDaemon:

Collaboration diagram for CPN::RemoteContextDaemon:

Classes
class	Client

Public Types
typedef AutoLock< PthreadMutex >	ALock

Public Member Functions
	RemoteContextDaemon (const SocketAddress &addr)
	RemoteContextDaemon (const SockAddrList &addrs)
	~RemoteContextDaemon ()
void	Run ()
	Run the actual Context returns when the context is terminated and all clients have disconnected. More...
bool	IsTerminated () const
int	DebugLevel () const
int	DebugLevel (int level)
void	Listen (const SocketAddress &addr, int queuelength=256)
void	Listen (const SockAddrList &addrs, int queuelength=256)
int	Accept (SocketAddress &addr)
int	Accept ()
void	SetReuseAddr (bool reuse=true)
	Turn on reuse of the address. Only takes effect if set before Listen. More...
bool	GetReuseAddr ()
int	Poll (double timeout)
bool	Readable (bool r)
	Set that the file is currently readable or not. More...
bool	Readable () const
	Gives the current readability status of the file. More...
bool	Writeable (bool w)
	Set that this file is currently writeable or not. More...
bool	Writeable () const
	Gives the current writability status of the file. More...
int	FD () const
int	FD (int filed)
	Set the current file descriptor. More...
bool	Eof () const
bool	Eof (bool e)
	Set/reset the end of file condition. More...
bool	Good () const
	Convenience method for testing if the file this FileHandle has is open and not at end of file. More...
bool	Closed () const
void	SetBlocking (bool blocking)
	Manipulate how the current file handles blocking. More...
bool	IsBlocking () const
	Test if the current file is in blocking or non blocking mode. More...
void	Reset ()
	Clear all internal state including the file descriptor! WARNING does not close the file! More...
void	Close ()
	Close the file and reset the internal state. More...
unsigned	Read (void *ptr, unsigned len)
	Read data from the file descriptor. More...
unsigned	Readv (const iovec *iov, int iovcnt)
	scatter gather io version of Read More...
unsigned	Write (const void *ptr, unsigned len)
	Write data to the file descriptor. More...
unsigned	Writev (const iovec *iov, int iovcnt)
	scatter gather io version of Write More...
void	Flush ()
	Tell the OS to flush any buffers it has. May not be supported for all file types. More...

Static Public Member Functions
static int	Poll (IteratorRef< FileHandle * > begin, IteratorRef< FileHandle * > end, double timeout)
	poll a list of FileHandles for any activity and call the appropriate On method. More...
static void	SetBlocking (int fd, bool blocking)
	a convenience method that allows one to set the same blocking parameters for a file descriptor without setting it inside a FileHandle. More...
static bool	IsBlocking (int fd)
	Test the given file descriptor if it is in blocking mode. More...

Protected Member Functions
void	DispatchMessage (const std::string &sender, const Variant &msg)
	Process the given message. More...
void	dbprintf (int level, const char *fmt,...)
virtual void	OnReadable ()
	Called by Poll when it detects that the file is readable. More...
virtual void	OnWriteable ()
	Called by Poll when it detects that the file is writeable. More...

Protected Attributes
PthreadMutex	file_lock
int	fd
bool	readable
bool	writeable
bool	eof

Private Types
typedef std::tr1::shared_ptr < Client >	ClientPtr
typedef std::map< std::string, ClientPtr >	ClientMap

Private Member Functions
void	Terminate ()
void	Terminate (const std::string &name)
void	Read ()
void	SendMessage (const std::string &recipient, const Variant &msg)
	Send the given message to the given client. More...
void	BroadcastMessage (const Variant &msg)
	Broadcast a message to all clients. More...
void	LogMessage (const std::string &msg)
	Log a message. More...

Private Attributes
ClientMap	clients

Friends
class	Client

Detailed Description

The RemoteContextDaemon is an implementation of RemoteContextServer that uses simple tcp/ip and listens on an address you specify.

Definition at line 41 of file RemoteContextDaemon.h.

Member Typedef Documentation

typedef AutoLock<PthreadMutex> FileHandle::ALock

inherited

Definition at line 43 of file FileHandle.h.

typedef std::map<std::string, ClientPtr> CPN::RemoteContextDaemon::ClientMap

private

Definition at line 75 of file RemoteContextDaemon.h.

typedef std::tr1::shared_ptr<Client> CPN::RemoteContextDaemon::ClientPtr

private

Definition at line 74 of file RemoteContextDaemon.h.

Constructor & Destructor Documentation

CPN::RemoteContextDaemon::RemoteContextDaemon

(

const SocketAddress &

addr

)

Definition at line 31 of file RemoteContextDaemon.cc.

References ServerSocketHandle::Listen(), and ServerSocketHandle::SetReuseAddr().

    {
        SetReuseAddr();
        Listen(addr);
    }

Here is the call graph for this function:

CPN::RemoteContextDaemon::RemoteContextDaemon

(

const SockAddrList &

addrs

)

Definition at line 37 of file RemoteContextDaemon.cc.

References ServerSocketHandle::Listen(), and ServerSocketHandle::SetReuseAddr().

    {
        SetReuseAddr();
        Listen(addrs);
    }

Here is the call graph for this function:

CPN::RemoteContextDaemon::~RemoteContextDaemon

(

)

Definition at line 42 of file RemoteContextDaemon.cc.

                                              {
    }

Member Function Documentation

int ServerSocketHandle::Accept ( SocketAddress &  addr )

inherited

Accept an incoming connection.

Parameters

addr	a SocketAddress object to fill with the address of the connecting peer.

Returns

-1 if no connection >=0 on success

Exceptions

ErrnoException

for errors

Definition at line 46 of file ServerSocketHandle.cc.

References ServerSocketHandle::Accept().

Referenced by CPN::ConnectionServer::Poll().

                                                  {
    return Accept(&addr);
}

Here is the call graph for this function:

Here is the caller graph for this function:

int ServerSocketHandle::Accept ( )

inherited

Accept an incoming connection

Definition at line 50 of file ServerSocketHandle.cc.

Referenced by ServerSocketHandle::Accept(), and Read().

                               {
    return Accept(0);
}

Here is the caller graph for this function:

void CPN::RemoteContextDaemon::BroadcastMessage ( const Variant &  msg )

privatevirtual

Broadcast a message to all clients.

Parameters

msg	the message to send to all clients

Implements CPN::RemoteContextServer.

Definition at line 125 of file RemoteContextDaemon.cc.

References clients, CPN::RemoteContextServer::dbprintf(), and CPN::RemoteContextServer::IsTerminated().

                                                                 {
        if (IsTerminated()) {
            dbprintf(1, "Trying to braodcast after shutdown\n%s", libvariant::SerializeJSON(msg).c_str());
            return;
        }
        ClientMap::iterator entry = clients.begin();
        dbprintf(4, "broadcast:%s\n", libvariant::SerializeJSON(msg).c_str());
        while (entry != clients.end()) {
            entry->second->Send(msg);
            ++entry;
        }
    }

Here is the call graph for this function:

void FileHandle::Close ( )

inherited

Close the file and reset the internal state.

Definition at line 146 of file FileHandle.cc.

References FileHandle::eof, FileHandle::fd, FileHandle::file_lock, FileHandle::readable, and FileHandle::writeable.

Referenced by CPN::ConnectionServer::Close(), CPN::RemoteContext::EntryPoint(), CPN::RemoteQueue::HandleError(), CPN::RemoteQueue::InternalCheckStatus(), and Terminate().

                       {
    ALock al(file_lock);
    if (fd != -1) {
        if (close(fd) != 0) {
            throw ErrnoException();
        }
        fd = -1;
    }
    readable = false;
    writeable = false;
    eof = false;
}

Here is the caller graph for this function:

bool FileHandle::Closed ( ) const

inlineinherited

Returns

false if this FileHandle has an open file

Definition at line 128 of file FileHandle.h.

References FileHandle::fd, and FileHandle::file_lock.

Referenced by SocketHandle::Connect(), CPN::ConnectionServer::ConnectReader(), CPN::ConnectionServer::ConnectWriter(), CPN::RemoteQueue::FileThreadEntryPoint(), CPN::RemoteQueue::InternalCheckStatus(), CPN::RemoteQueue::LogState(), CPN::ConnectionServer::LogState(), Run(), CPN::RemoteContextDaemon::Client::Send(), and CPN::RemoteContext::SendMessage().

{ ALock al(file_lock); return fd == -1; }

Here is the caller graph for this function:

void CPN::RemoteContextServer::dbprintf ( int  level, const char *  fmt,   ...  )

protectedinherited

Definition at line 40 of file RemoteContextServer.cc.

References CPN::RemoteContextServer::debuglevel.

Referenced by BroadcastMessage(), CPN::RemoteContextDaemon::Client::Client(), CPN::RemoteContextServer::CreateNodeKey(), CPN::RemoteContextServer::DispatchMessage(), LogMessage(), Run(), SendMessage(), CPN::RemoteContextServer::SetupKernel(), CPN::RemoteContextServer::SignalKernelEnd(), CPN::RemoteContextServer::SignalKernelStart(), CPN::RemoteContextServer::SignalNodeEnd(), CPN::RemoteContextServer::SignalNodeStart(), and Terminate().

                                                                      {
        if (debuglevel >= level) {
            va_list ap;
            va_start(ap, fmt);
            vprintf(fmt, ap);
            va_end(ap);
        }
    }

Here is the caller graph for this function:

int CPN::RemoteContextServer::DebugLevel ( ) const

inlineinherited

Definition at line 126 of file RemoteContextServer.h.

References CPN::RemoteContextServer::debuglevel.

{ return debuglevel; }

int CPN::RemoteContextServer::DebugLevel ( int  level )

inlineinherited

Definition at line 127 of file RemoteContextServer.h.

References CPN::RemoteContextServer::debuglevel.

{ return debuglevel = level; }

void CPN::RemoteContextServer::DispatchMessage ( const std::string &  sender, const Variant &  msg  )

protectedinherited

Process the given message.

Parameters

sender	a string id for the client
msg	the message that the client sent

Definition at line 49 of file RemoteContextServer.cc.

References ASSERT, CPN::RemoteContextServer::ConnectEndpoints(), CPN::RemoteContextServer::CreateNodeKey(), CPN::RemoteContextServer::dbprintf(), CPN::RemoteContextServer::GetCreateEndpointKey(), CPN::RemoteContextServer::GetEndpointInfo(), CPN::RemoteContextServer::GetKernelInfo(), CPN::RemoteContextServer::GetNodeInfo(), CPN::RemoteContextServer::GetNumNodeLive(), CPN::RemoteContextServer::IsTerminated(), CPN::RemoteContextServer::LogMessage(), CPN::RCTXMT_CONNECT_ENDPOINTS, CPN::RCTXMT_CREATE_NODE, CPN::RCTXMT_CREATE_NODE_KEY, CPN::RCTXMT_CREATE_QUEUE, CPN::RCTXMT_CREATE_READER, CPN::RCTXMT_CREATE_WRITER, CPN::RCTXMT_GET_CREATE_READER_KEY, CPN::RCTXMT_GET_CREATE_WRITER_KEY, CPN::RCTXMT_GET_KERNEL_INFO, CPN::RCTXMT_GET_NODE_INFO, CPN::RCTXMT_GET_NUM_NODE_LIVE, CPN::RCTXMT_GET_READER_INFO, CPN::RCTXMT_GET_WRITER_INFO, CPN::RCTXMT_LOG, CPN::RCTXMT_SETUP_KERNEL, CPN::RCTXMT_SIGNAL_KERNEL_END, CPN::RCTXMT_SIGNAL_KERNEL_START, CPN::RCTXMT_SIGNAL_NODE_END, CPN::RCTXMT_SIGNAL_NODE_START, CPN::RCTXMT_TERMINATE, CPN::RemoteContextServer::RouteKernelMessage(), CPN::RemoteContextServer::SetupKernel(), CPN::RemoteContextServer::SignalKernelEnd(), CPN::RemoteContextServer::SignalKernelStart(), CPN::RemoteContextServer::SignalNodeEnd(), CPN::RemoteContextServer::SignalNodeStart(), and CPN::RemoteContextServer::Terminate().

                                                                                         {
        dbprintf(4, "msg:%s:%s\n", sender.c_str(), libvariant::SerializeJSON(msg).c_str());
        if (!msg.IsMap()) { return; }
        if (IsTerminated()) {
            return;
        }
        RCTXMT_t type = msg["type"].AsNumber<RCTXMT_t>();
        switch (type) {
        case RCTXMT_SETUP_KERNEL:
            SetupKernel(sender, msg);
            break;
        case RCTXMT_SIGNAL_KERNEL_START:
            SignalKernelStart(msg);
            break;
        case RCTXMT_SIGNAL_KERNEL_END:
            SignalKernelEnd(msg);
            break;
        case RCTXMT_GET_KERNEL_INFO:
            GetKernelInfo(sender, msg);
            break;
        case RCTXMT_CREATE_WRITER:
        case RCTXMT_CREATE_READER:
        case RCTXMT_CREATE_QUEUE:
        case RCTXMT_CREATE_NODE:
            RouteKernelMessage(msg);
            break;
        case RCTXMT_CREATE_NODE_KEY:
            CreateNodeKey(sender, msg);
            break;
        case RCTXMT_SIGNAL_NODE_START:
            SignalNodeStart(msg);
            break;
        case RCTXMT_SIGNAL_NODE_END:
            SignalNodeEnd(msg);
            break;
        case RCTXMT_GET_NODE_INFO:
            GetNodeInfo(sender, msg);
            break;
        case RCTXMT_GET_NUM_NODE_LIVE:
            GetNumNodeLive(sender, msg);
            break;
        case RCTXMT_GET_CREATE_READER_KEY:
            GetCreateEndpointKey(sender, msg);
            break;
        case RCTXMT_GET_READER_INFO:
            GetEndpointInfo(sender, msg);
            break;
        case RCTXMT_GET_CREATE_WRITER_KEY:
            GetCreateEndpointKey(sender, msg);
            break;
        case RCTXMT_GET_WRITER_INFO:
            GetEndpointInfo(sender, msg);
            break;
        case RCTXMT_CONNECT_ENDPOINTS:
            ConnectEndpoints(msg);
            break;
        case RCTXMT_TERMINATE:
            Terminate();
            break;
        case RCTXMT_LOG:
            LogMessage(sender + ":" + msg["msg"].AsString());
            break;
        default:
            ASSERT(false);
        }
    }

Here is the call graph for this function:

bool FileHandle::Eof ( ) const

inlineinherited

Returns

the current end of file condition

Definition at line 115 of file FileHandle.h.

References FileHandle::eof, and FileHandle::file_lock.

Referenced by CPN::RemoteQueue::EnqueuePacket(), CPN::RemoteContext::EntryPoint(), CPN::RemoteQueue::InternalCheckStatus(), CPN::RemoteContextDaemon::Client::Read(), and CPN::RemoteQueue::Read().

{ ALock al(file_lock); return eof; }

Here is the caller graph for this function:

bool FileHandle::Eof ( bool  e )

inlineinherited

Set/reset the end of file condition.

Parameters

e	the new end of file condition

Returns

the new end of file condition

Definition at line 120 of file FileHandle.h.

References FileHandle::eof, and FileHandle::file_lock.

{ ALock al(file_lock); return eof = e; }

int FileHandle::FD ( ) const

inlineinherited

Returns

the current set file descriptor

Definition at line 106 of file FileHandle.h.

References FileHandle::fd, and FileHandle::file_lock.

Referenced by ServerSocketHandle::Accept(), CPN::RemoteContextDaemon::Client::Client(), SocketHandle::Connect(), CPN::ConnectionServer::ConnectWriter(), SocketHandle::CreatePair(), CPN::RemoteQueue::FileThreadEntryPoint(), FileHandle::Flush(), CPN::ConnectionServer::GetAddress(), SocketHandle::GetKeepAlive(), SocketHandle::GetLingerTimeout(), SocketHandle::GetNoDelay(), SocketHandle::GetPendingError(), SocketHandle::GetReceiveBufferSize(), SocketHandle::GetReceiveTimeout(), SocketHandle::GetSendBufferSize(), SocketHandle::GetSendTimeout(), FileHandle::IsBlocking(), ServerSocketHandle::Listen(), FileHandle::Poll(), Run(), FileHandle::SetBlocking(), SocketHandle::SetKeepAlive(), SocketHandle::SetLingerTimeout(), SocketHandle::SetNoDelay(), SocketHandle::SetReceiveBufferSize(), SocketHandle::SetReceiveTimeout(), SocketHandle::SetSendBufferSize(), SocketHandle::SetSendTimeout(), SocketHandle::ShutdownRead(), SocketHandle::ShutdownWrite(), and WakeupHandle::WakeupHandle().

{ ALock al(file_lock); return fd; }

Here is the caller graph for this function:

int FileHandle::FD ( int  filed )

inlineinherited

Set the current file descriptor.

Parameters

filed

the new file descriptor

Returns

the new file descriptor

Definition at line 111 of file FileHandle.h.

References FileHandle::fd, and FileHandle::file_lock.

{ ALock al(file_lock); return fd = filed; }

void FileHandle::Flush ( )

inherited

Tell the OS to flush any buffers it has. May not be supported for all file types.

Definition at line 293 of file FileHandle.cc.

References FileHandle::FD().

                       {
    if (fsync(FD()) != 0) {
        throw ErrnoException();
    }
}

Here is the call graph for this function:

bool ServerSocketHandle::GetReuseAddr ( )

inlineinherited

Definition at line 71 of file ServerSocketHandle.h.

References ServerSocketHandle::reuse_addr.

{ return reuse_addr; }

bool FileHandle::Good ( ) const

inlineinherited

Convenience method for testing if the file this FileHandle has is open and not at end of file.

Returns

true if open and not at end of file otherwise false

Definition at line 125 of file FileHandle.h.

References FileHandle::eof, FileHandle::fd, and FileHandle::file_lock.

Referenced by CPN::RemoteContext::EntryPoint(), and CPN::RemoteContextDaemon::Client::Read().

{ ALock al(file_lock); return !(eof || fd == -1); }

Here is the caller graph for this function:

bool FileHandle::IsBlocking ( ) const

inherited

Test if the current file is in blocking or non blocking mode.

Returns

true if blocking or false if non blocking

Definition at line 128 of file FileHandle.cc.

References FileHandle::FD().

                                  {
    return IsBlocking(FD());
}

Here is the call graph for this function:

bool FileHandle::IsBlocking ( int  fd )

staticinherited

Test the given file descriptor if it is in blocking mode.

Parameters

fd	the file descriptor to test

Returns

true if blocking or false if non blocking

Definition at line 132 of file FileHandle.cc.

                                  {
    int flags = fcntl(fd, F_GETFL, 0);
    if (-1 == flags) { throw ErrnoException(); }
    return !(flags & O_NONBLOCK);
}

bool CPN::RemoteContextServer::IsTerminated ( ) const

inlineinherited

Returns

whether or not the context is in the shutdown state.

Definition at line 125 of file RemoteContextServer.h.

References CPN::RemoteContextServer::shutdown.

Referenced by BroadcastMessage(), CPN::RemoteContextServer::DispatchMessage(), Run(), SendMessage(), and Terminate().

{ return shutdown; }

Here is the caller graph for this function:

void ServerSocketHandle::Listen ( const SocketAddress &  addr, int  queuelength = 256  )

inherited

Open a new socket and try to listen on the given SocketAddress.

Definition at line 30 of file ServerSocketHandle.cc.

Referenced by CPN::ConnectionServer::ConnectionServer(), ServerSocketHandle::Listen(), RemoteContextDaemon(), and ServerSocketHandle::ServerSocketHandle().

                                                                          {
    int error = 0;
    if (!Listen(addr, queuelength, error)) { throw ErrnoException(error); }
}

Here is the caller graph for this function:

void ServerSocketHandle::Listen ( const SockAddrList &  addrs, int  queuelength = 256  )

inherited

Open a new socket and try to listen on one of the addresses in the given list.

Definition at line 35 of file ServerSocketHandle.cc.

References ServerSocketHandle::Listen().

                                                                          {
    int error = 0;
    bool success = false;
    for (SockAddrList::const_iterator itr = addrs.begin();
            itr != addrs.end(); ++itr) {
        success = Listen(*itr, queuelength, error);
        if (success) break;
    }
    if (!success) throw ErrnoException(error);
}

Here is the call graph for this function:

void CPN::RemoteContextDaemon::LogMessage ( const std::string &  msg )

privatevirtual

Log a message.

Parameters

msg	the message to be logged

Implements CPN::RemoteContextServer.

Definition at line 138 of file RemoteContextDaemon.cc.

References CPN::RemoteContextServer::dbprintf().

                                                             {
        dbprintf(1, "log:%s\n", msg.c_str());
    }

Here is the call graph for this function:

virtual void FileHandle::OnReadable ( )

inlineprotectedvirtualinherited

Called by Poll when it detects that the file is readable.

Reimplemented in WakeupHandle.

Definition at line 210 of file FileHandle.h.

References FileHandle::Readable().

Referenced by FileHandle::Poll().

{ Readable(true); }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void FileHandle::OnWriteable ( )

inlineprotectedvirtualinherited

Called by Poll when it detects that the file is writeable.

Definition at line 212 of file FileHandle.h.

References FileHandle::Writeable().

Referenced by FileHandle::Poll().

{ Writeable(true); }

Here is the call graph for this function:

Here is the caller graph for this function:

int FileHandle::Poll ( IteratorRef< FileHandle * >  begin, IteratorRef< FileHandle * >  end, double  timeout  )

staticinherited

poll a list of FileHandles for any activity and call the appropriate On method.

Definition at line 34 of file FileHandle.cc.

References FileHandle::FD(), FileHandle::fd, FileHandle::OnReadable(), FileHandle::OnWriteable(), FileHandle::Readable(), and FileHandle::Writeable().

Referenced by CPN::RemoteContext::EntryPoint(), CPN::RemoteQueue::FileThreadEntryPoint(), CPN::ConnectionServer::Poll(), FileHandle::Poll(), and Run().

                                                                                                 {
    fd_set rfd;
    fd_set wfd;
    FD_ZERO(&rfd);
    FD_ZERO(&wfd);
    int maxfd = 0;
    IteratorRef<FileHandle*> itr = begin;
    while (itr != end) {
        FileHandle *han = *itr;
        int fd = han->FD();
        if (fd < 0) {
            return -1;
        } else {
            bool set = false;
            if (!han->Readable()) {
                FD_SET(fd, &rfd);
                set = true;
            }
            if (!han->Writeable()) {
                FD_SET(fd, &wfd);
                set = true;
            }
            if (set) { maxfd = std::max(maxfd, fd); }
        }
        ++itr;
    }
    timeval tv;
    timeval *ptv = 0;
    if (timeout >= 0) {
        tv.tv_sec = (int)timeout;
        tv.tv_usec = (int)((timeout - tv.tv_sec) * 1e6);
        ptv = &tv;
    }
    int ret = select(maxfd + 1, &rfd, &wfd, 0, ptv);
    if (ret < 0) {
        if (errno == EINTR) {
            return 0;
        }
        throw ErrnoException();
    }
    itr = begin;
    while (itr != end) {
        FileHandle *han = *itr;
        int fd = han->FD();
        if (fd >= 0) {
            if (FD_ISSET(fd, &rfd)) {
                han->OnReadable();
            }
            if (FD_ISSET(fd, &wfd)) {
                han->OnWriteable();
            }
        }
        ++itr;
    }
    return ret;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int FileHandle::Poll ( double  timeout )

inherited

Poll the current file descriptor for activity specified by the current readable or writeable status, if false poll that value, and call one of OnWriteable or OnReadable whos default action is to set Readable or Writeable to true.

Parameters

timeout

-1 to wait forever for activity 0 to poll and return immediately or a time to wait in seconds.

Returns

zero if timed out, positive if an event occurred or negative if an error occurred.

Definition at line 106 of file FileHandle.cc.

References FileHandle::Poll().

                                   {
    FileHandle *fh = this;
    return Poll(&fh, &fh + 1, timeout);
}

Here is the call graph for this function:

void CPN::RemoteContextDaemon::Read ( )

private

Definition at line 104 of file RemoteContextDaemon.cc.

References ServerSocketHandle::Accept(), Client, clients, and FileHandle::Readable().

Referenced by Run().

                                   {
        int nfd = Accept();
        if (nfd >= 0) {
            ClientPtr conn = ClientPtr(new Client(this, nfd));
            clients.insert(std::make_pair(conn->GetName(), conn));
            Readable(false);
        }
    }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned FileHandle::Read ( void *  ptr, unsigned  len  )

inherited

Read data from the file descriptor.

Will set the end of file condition if read detects end of file.

Note

All the read functions will set readable to false if they read less than the requested amount or we are non blocking and a would block condition happened.

Parameters

ptr	pointer to write data to
len	the maximum number of bytes to write to ptr

Returns

0 if no bytes read (check Eof) or the number of bytes read

Definition at line 159 of file FileHandle.cc.

References FileHandle::eof, FileHandle::fd, FileHandle::file_lock, FileHandle::Readable(), and FileHandle::readable.

Referenced by CPN::RemoteQueue::D4RTagPacket(), and WakeupHandle::Read().

                                                 {
    int filed;
    {
        ALock al(file_lock);
        if (eof || fd == -1) { return 0; }
        filed = fd;
    }
    unsigned bytesread = 0;
    int num = read(filed, ptr, len);
    if (num < 0) {
        int error = errno;
        switch (error) {
        case EAGAIN:
            Readable(false);
        case EINTR:
        case ENOMEM:
            break;
        default:
            throw ErrnoException(error);
        }
    } else if (num == 0 && len != 0) {
        ALock al(file_lock);
        eof = true;
        readable = false;
    } else {
        if (unsigned(num) < len) { Readable(false); }
        bytesread = num;
    }
    return bytesread;
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool FileHandle::Readable ( bool  r )

inlineinherited

Set that the file is currently readable or not.

Parameters

r	true or false

Returns

the new readable status

Definition at line 86 of file FileHandle.h.

References FileHandle::file_lock, and FileHandle::readable.

Referenced by CPN::RemoteContext::EntryPoint(), FileHandle::Poll(), CPN::ConnectionServer::Poll(), and CPN::RemoteQueue::Read().

{ ALock al(file_lock); return readable = r; }

Here is the caller graph for this function:

bool FileHandle::Readable ( ) const

inlineinherited

Gives the current readability status of the file.

Returns

true if it is known that a read will not block

Definition at line 91 of file FileHandle.h.

References FileHandle::file_lock, and FileHandle::readable.

Referenced by ServerSocketHandle::Accept(), CPN::RemoteContextDaemon::Client::Client(), FileHandle::OnReadable(), Read(), FileHandle::Read(), FileHandle::Readv(), SocketHandle::Recv(), Run(), and WakeupHandle::WakeupHandle().

{ ALock al(file_lock); return readable; }

Here is the caller graph for this function:

unsigned FileHandle::Readv ( const iovec *  iov, int  iovcnt  )

inherited

scatter gather io version of Read

Returns

see Read

Definition at line 190 of file FileHandle.cc.

References FileHandle::eof, FileHandle::fd, FileHandle::file_lock, FileHandle::Readable(), and FileHandle::readable.

Referenced by CPN::RemoteQueue::EnqueuePacket().

                                                       {
    int filed;
    {
        ALock al(file_lock);
        if (eof || fd == -1) { return 0; }
        filed = fd;
    }
    unsigned len = 0;
    for (int i = 0; i < iovcnt; ++i) {
        len += iov[i].iov_len;
    }
    unsigned bytesread = 0;
    int num = readv(filed, iov, iovcnt);
    if (num < 0) {
        int error = errno;
        switch (error) {
        case EAGAIN:
            Readable(false);
        case EINTR:
        case ENOMEM:
            break;
        default:
            throw ErrnoException(error);
        }
    } else if (num == 0 && len != 0) {
        ALock al(file_lock);
        eof = true;
        readable = false;
    } else {
        if (unsigned(num) < len) { Readable(false); }
        bytesread = num;
    }
    return bytesread;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void FileHandle::Reset ( )

inherited

Clear all internal state including the file descriptor! WARNING does not close the file!

Definition at line 138 of file FileHandle.cc.

References FileHandle::eof, FileHandle::fd, FileHandle::file_lock, FileHandle::readable, and FileHandle::writeable.

Referenced by CPN::ConnectionServer::ConnectWriter(), CPN::RemoteQueue::FileThreadEntryPoint(), and FileHandle::~FileHandle().

                       {
    ALock al(file_lock);
    readable = false;
    writeable = false;
    eof = false;
    fd = -1;
}

Here is the caller graph for this function:

void CPN::RemoteContextDaemon::Run

(

)

Run the actual Context returns when the context is terminated and all clients have disconnected.

Definition at line 45 of file RemoteContextDaemon.cc.

References clients, FileHandle::Closed(), CPN::RemoteContextServer::dbprintf(), FileHandle::FD(), SocketAddress::GetHostName(), SocketAddress::GetServName(), CPN::RemoteContextServer::IsTerminated(), FileHandle::Poll(), Read(), FileHandle::Readable(), SocketAddress::SetFromSockName(), and Terminate().

                                  {
        Readable(false);
        SocketAddress addr;
        addr.SetFromSockName(FD());
        dbprintf(1, "Listening on %s:%s\n", addr.GetHostName().c_str(), addr.GetServName().c_str());
        while (true) {
            std::vector<FileHandle*> fds;
            if (!Closed()) {
                if (Readable()) {
                    Read();
                }
                fds.push_back(this);
            }
            ClientMap::iterator itr = clients.begin();
            while (itr != clients.end()) {
                ClientPtr client = itr->second;
                if (client->Closed()) {
                    ClientMap::iterator todelete = itr;
                    ++itr;
                    clients.erase(todelete);
                    Terminate();
                } else {
                    if (client->Readable()) {
                        client->Read();
                    }
                    fds.push_back(client.get());
                    ++itr;
                }
            }
            if ((clients.empty() && IsTerminated()) || fds.empty()) {
                break;
            }
            Poll(fds.begin(), fds.end(), -1);
        }
    }

Here is the call graph for this function:

void CPN::RemoteContextDaemon::SendMessage ( const std::string &  recipient, const Variant &  msg  )

privatevirtual

Send the given message to the given client.

Parameters

recipient	the id (previously used in DispatchMessage sender)
msg	the message to be sent to the client

Implements CPN::RemoteContextServer.

Definition at line 113 of file RemoteContextDaemon.cc.

References ASSERT, clients, CPN::RemoteContextServer::dbprintf(), and CPN::RemoteContextServer::IsTerminated().

                                                                                        {
        if (IsTerminated()) {
            dbprintf(1, "Trying to send a reply after shutdown\n%s:%s",
                    recipient.c_str(), libvariant::SerializeJSON(msg).c_str());
            return;
        }
        ClientMap::iterator entry = clients.find(recipient);
        ASSERT(entry != clients.end());
        dbprintf(4, "reply:%s:%s\n", recipient.c_str(), libvariant::SerializeJSON(msg).c_str());
        entry->second->Send(msg);
    }

Here is the call graph for this function:

void FileHandle::SetBlocking ( bool  blocking )

inherited

Manipulate how the current file handles blocking.

Parameters

blocking

true to set to blocking mode (default) false to set to non blocking mode.

In non blocking mode all reads and writes will not block. Use Poll to block.

Definition at line 111 of file FileHandle.cc.

References FileHandle::FD().

Referenced by WakeupHandle::WakeupHandle().

                                          {
    SetBlocking(FD(), blocking);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void FileHandle::SetBlocking ( int  fd, bool  blocking  )

staticinherited

a convenience method that allows one to set the same blocking parameters for a file descriptor without setting it inside a FileHandle.

Parameters

fd	the file descriptor
blocking	true or false see SetBlock

Definition at line 115 of file FileHandle.cc.

                                                  {
    int flags = fcntl(fd, F_GETFL, 0);
    if (-1 == flags) { throw ErrnoException(); }
    if (blocking) {
        flags &= ~O_NONBLOCK;
    } else {
        flags |= O_NONBLOCK;
    }
    if (fcntl(fd, F_SETFL, flags) != 0) {
        throw ErrnoException();
    }
}

void ServerSocketHandle::SetReuseAddr ( bool  reuse = true )

inlineinherited

Turn on reuse of the address. Only takes effect if set before Listen.

Definition at line 70 of file ServerSocketHandle.h.

References ServerSocketHandle::reuse_addr.

Referenced by RemoteContextDaemon().

{ reuse_addr = true; }

Here is the caller graph for this function:

void CPN::RemoteContextDaemon::Terminate ( )

privatevirtual

Cause the context to go into the shutdown state.

Reimplemented from CPN::RemoteContextServer.

Definition at line 81 of file RemoteContextDaemon.cc.

References clients, FileHandle::Close(), CPN::RemoteContextServer::IsTerminated(), and CPN::RemoteContextServer::Terminate().

Referenced by Run().

                                        {
        if (IsTerminated()) return;
        CPN::RemoteContextServer::Terminate();
        Close();
        ClientMap::iterator itr = clients.begin();
        while (itr != clients.end()) {
            ClientPtr client = itr->second;
            if (!client->Closed()) {
                try {
                    client->ShutdownWrite();
                } catch (const ErrnoException &e) {
                    //ignore
                }
            }
            ++itr;
        }
    }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::RemoteContextDaemon::Terminate ( const std::string &  name )

private

Definition at line 99 of file RemoteContextDaemon.cc.

References clients, and CPN::RemoteContextServer::dbprintf().

                                                             {
        dbprintf(1, "Terminating %s\n", name.c_str());
        clients[name]->Close();
    }

Here is the call graph for this function:

unsigned FileHandle::Write ( const void *  ptr, unsigned  len  )

inherited

Write data to the file descriptor.

Note

All write functions will set Writeable to false if they write less than the amount requested or if the file is in non blocking mode and the write returned would block.

Parameters

ptr	pointer to beginning of data to write
len	length of data to write

Returns

number of bytes written

Definition at line 225 of file FileHandle.cc.

References FileHandle::fd, FileHandle::file_lock, and FileHandle::Writeable().

Referenced by CPN::ConnectionServer::ConnectWriter(), CPN::RemoteContextDaemon::Client::Send(), CPN::RemoteContext::SendMessage(), and CPN::RemoteQueue::WriteBytes().

                                                        {
    int filed;
    {
        ALock al(file_lock);
        if (fd == -1) { return 0; }
        filed = fd;
    }
    unsigned written = 0;
    int num = write(filed, ptr, len);
    if (num < 0) {
        int error = errno;
        switch (error) {
        case EAGAIN: // Would block
        //case EWOULDBLOCK:
            Writeable(false);
        case EINTR: // Returned because of signal
        case ENOMEM:
        case ENOBUFS: // Buffers are full
            break;
        case EPIPE:
        case EBADF:
        case EFAULT:
        case EFBIG:
        case EINVAL:
        case EIO:
        case ENOSPC:
        default:
            throw ErrnoException(error);
        }
    } else {
        if (unsigned(num) < len) { Writeable(false); }
        written = num;
    }
    return written;
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool FileHandle::Writeable ( bool  w )

inlineinherited

Set that this file is currently writeable or not.

Parameters

w	true or false

Returns

the new writeable status

Definition at line 97 of file FileHandle.h.

References FileHandle::file_lock, and FileHandle::writeable.

Referenced by FileHandle::Poll().

{ ALock al(file_lock); return writeable = w; }

Here is the caller graph for this function:

bool FileHandle::Writeable ( ) const

inlineinherited

Gives the current writability status of the file.

Returns

true if it is known that a write will not block

Definition at line 102 of file FileHandle.h.

References FileHandle::file_lock, and FileHandle::writeable.

Referenced by FileHandle::OnWriteable(), SocketHandle::Send(), WakeupHandle::WakeupHandle(), FileHandle::Write(), and FileHandle::Writev().

{ ALock al(file_lock); return writeable; }

Here is the caller graph for this function:

unsigned FileHandle::Writev ( const iovec *  iov, int  iovcnt  )

inherited

scatter gather io version of Write

Returns

see Write

Definition at line 261 of file FileHandle.cc.

References FileHandle::fd, FileHandle::file_lock, and FileHandle::Writeable().

Referenced by CPN::RemoteQueue::WriteBytes().

                                                        {
    int filed;
    {
        ALock al(file_lock);
        if (fd == -1) { return 0; }
        filed = fd;
    }
    unsigned written = 0;
    int num = writev(filed, iov, iovcnt);
    if (num < 0) {
        int error = errno;
        switch (error) {
        case EAGAIN:
            Writeable(false);
        case EINTR:
        case ENOMEM:
        case ENOBUFS:
            break;
        default:
            throw ErrnoException(error);
        }
    } else {
        unsigned len = 0;
        for (int i = 0; i < iovcnt; ++i) {
            len += iov[i].iov_len;
        }
        if (unsigned(num) < len) { Writeable(false); }
        written = num;
    }
    return written;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Friends And Related Function Documentation

friend class Client

friend

Definition at line 73 of file RemoteContextDaemon.h.

Referenced by Read().

Member Data Documentation

ClientMap CPN::RemoteContextDaemon::clients

private

Definition at line 77 of file RemoteContextDaemon.h.

Referenced by BroadcastMessage(), Read(), Run(), SendMessage(), and Terminate().

bool FileHandle::eof

protectedinherited

Definition at line 217 of file FileHandle.h.

Referenced by FileHandle::Close(), FileHandle::Eof(), FileHandle::Good(), FileHandle::Read(), FileHandle::Readv(), SocketHandle::Recv(), and FileHandle::Reset().

int FileHandle::fd

protectedinherited

Definition at line 214 of file FileHandle.h.

Referenced by FileHandle::Close(), FileHandle::Closed(), FileHandle::FD(), FileHandle::Good(), FileHandle::Poll(), FileHandle::Read(), FileHandle::Readv(), SocketHandle::Recv(), FileHandle::Reset(), SocketHandle::Send(), FileHandle::Write(), FileHandle::Writev(), and FileHandle::~FileHandle().

PthreadMutex FileHandle::file_lock

mutableprotectedinherited

Definition at line 213 of file FileHandle.h.

Referenced by FileHandle::Close(), FileHandle::Closed(), FileHandle::Eof(), FileHandle::FD(), FileHandle::Good(), FileHandle::Read(), FileHandle::Readable(), FileHandle::Readv(), SocketHandle::Recv(), FileHandle::Reset(), SocketHandle::Send(), WakeupHandle::SendWakeup(), FileHandle::Write(), FileHandle::Writeable(), and FileHandle::Writev().

bool FileHandle::readable

protectedinherited

Definition at line 215 of file FileHandle.h.

Referenced by FileHandle::Close(), FileHandle::Read(), FileHandle::Readable(), FileHandle::Readv(), SocketHandle::Recv(), and FileHandle::Reset().

bool FileHandle::writeable

protectedinherited

Definition at line 216 of file FileHandle.h.

Referenced by FileHandle::Close(), FileHandle::Reset(), and FileHandle::Writeable().

---

The documentation for this class was generated from the following files:

• include/cpn/remote_context/RemoteContextDaemon.h
• lib/RemoteContextDaemon.cc
