The CPN::Context abstraction that holds all the global state for the process network. More...

#include <Context.h>

Inheritance diagram for CPN::Context:

Collaboration diagram for CPN::Context:

Public Member Functions
virtual	~Context ()

virtual Key_t	SetupKernel (const std::string &name, const std::string &hostname, const std::string &servname, KernelBase *kernel)=0
	Called by the Kernel when it has successfully set it self up. This gives the Context a way to notify the Kernel of events and lets other Kernels look up the connection information for this Kernel. More...

virtual Key_t	SetupKernel (const std::string &name, KernelBase *kernel)=0
	Called by the kernel when it is not in remote mode. More...

virtual Key_t	GetKernelKey (const std::string &kernel)=0

virtual std::string	GetKernelName (Key_t kernelkey)=0

virtual void	GetKernelConnectionInfo (Key_t kernelkey, std::string &hostname, std::string &servname)=0
	obtain the connection information for the given kernel More...

virtual void	SignalKernelEnd (Key_t kernelkey)=0
	Signal to the Context that the given kernel is dead. More...

virtual Key_t	WaitForKernelStart (const std::string &kernel)=0
	Does not return until the given kernel has started. More...

virtual void	SignalKernelStart (Key_t kernelkey)=0
	Signal to the context that the given kernel has started. More...

virtual void	SendCreateWriter (Key_t kernelkey, const SimpleQueueAttr &attr)=0
	Tell a given kernel that it needs to create a queue write end. More...

virtual void	SendCreateReader (Key_t kernelkey, const SimpleQueueAttr &attr)=0
	Tell a given kernel that it needs to create a queue read end. More...

virtual void	SendCreateQueue (Key_t kernelkey, const SimpleQueueAttr &attr)=0
	Tell a given kernel that it needs to create a queue. More...

virtual void	SendCreateNode (Key_t kernelkey, const NodeAttr &attr)=0
	Tell a given kernel that it needs to create a node. More...

virtual Key_t	CreateNodeKey (Key_t kernelkey, const std::string &nodename)=0
	Tell the context to allocate a new node key and data structure for a node with nodename which is on kernelkey. More...

virtual Key_t	GetNodeKey (const std::string &nodename)=0

virtual std::string	GetNodeName (Key_t nodekey)=0

virtual Key_t	GetNodeKernel (Key_t nodekey)=0

virtual void	SignalNodeStart (Key_t nodekey)=0
	Called by the node startup routine to indicate that the node has started. More...

virtual void	SignalNodeEnd (Key_t nodekey)=0
	Called by the node cleanup routine to indicate that the node has ended. More...

virtual Key_t	WaitForNodeStart (const std::string &nodename)=0
	Waits until the node starts and returns the key, if the node is already started returns the key. More...

virtual void	WaitForNodeEnd (const std::string &nodename)=0
	Waits for the given node to signal end. More...

virtual void	WaitForAllNodeEnd ()=0
	Convenience method which waits until there are no nodes running. If no node have started then this will return immediately. More...

virtual Key_t	GetCreateReaderKey (Key_t nodekey, const std::string &portname)=0
	Get the key associated with the given endpoint for the given node. Creates the information if it does not exist. More...

virtual Key_t	GetReaderNode (Key_t portkey)=0

virtual Key_t	GetReaderKernel (Key_t portkey)=0

virtual std::string	GetReaderName (Key_t portkey)=0

virtual Key_t	GetCreateWriterKey (Key_t nodekey, const std::string &portname)=0

virtual Key_t	GetWriterNode (Key_t portkey)=0

virtual Key_t	GetWriterKernel (Key_t portkey)=0

virtual std::string	GetWriterName (Key_t portkey)=0

virtual void	ConnectEndpoints (Key_t writerkey, Key_t readerkey, const std::string &qname)=0
	Called by the kernel when a queue is created. Note that the endpoints may have been created when the node requests them but the queue may be created long after that. More...

virtual Key_t	GetReadersWriter (Key_t readerkey)=0

virtual Key_t	GetWritersReader (Key_t writerkey)=0

virtual void	Terminate ()=0
	Signal to the Context that the network is terminating. After this call most methods will throw a ShutdownException. More...

virtual bool	IsTerminated ()=0

void	CheckTerminated ()
	Convenience method that checks IsTerminated and if so throws a ShutdownException. More...

virtual bool	RequireRemote ()
	Lets the kernel know that this context type requires remote activity. This overrides the kernel option for remote activity. Default value is false. More...

virtual unsigned	CalculateGrowSize (unsigned currentsize, unsigned request)
	Calculate the new queue size when a queue needs to grow. More...

virtual int	LogLevel () const =0

virtual int	LogLevel (int level)=0

virtual void	Log (int level, const std::string &msg)=0
	Log a message to this outputer. More...

Static Public Member Functions
static shared_ptr< Context >	Local ()
	Create a local context. More...

Protected Member Functions
	Context ()

Detailed Description

The CPN::Context abstraction that holds all the global state for the process network.

All methods may through a CPN::ShutdownException.

Note that all key values should be unique across all objects. That is to say that even though a node and a kernel are of different types none of there keys should ever be equal.

Note that the only function here that should be called outside of the library (i.e. by the user of the library) are the log level functions the Get functions and the Wait functions and the Terminate functions.

Definition at line 47 of file Context.h.

Constructor & Destructor Documentation

CPN::Context::~Context ( )

virtual

Definition at line 37 of file Context.cc.

37 {

38 }

CPN::Context::Context ( )

protected

Definition at line 33 of file Context.cc.

34 {

35 }

Member Function Documentation

virtual unsigned CPN::Context::CalculateGrowSize	(	unsigned	currentsize,
		unsigned	request
	)

inlinevirtual

Calculate the new queue size when a queue needs to grow.

Returns: the new queue size

Definition at line 275 of file Context.h.

275 { return currentsize + request; }

void CPN::Context::CheckTerminated ( )

Convenience method that checks IsTerminated and if so throws a ShutdownException.

Exceptions

ShutdownException

Definition at line 44 of file Context.cc.

References IsTerminated().

                                   {
         if (IsTerminated()) {
             throw ShutdownException();
         }
     }

Here is the call graph for this function:

virtual void CPN::Context::ConnectEndpoints	(	Key_t	writerkey,
		Key_t	readerkey,
		const std::string &	qname
	)

pure virtual

Called by the kernel when a queue is created. Note that the endpoints may have been created when the node requests them but the queue may be created long after that.

Parameters

writerkey	the unique key for the writer endpoint
readerkey	the unique key for the reader endpoint

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::CreateNodeKey	(	Key_t	kernelkey,
		const std::string &	nodename
	)

pure virtual

Tell the context to allocate a new node key and data structure for a node with nodename which is on kernelkey.

Parameters

kernelkey	the id of the kernel that the node will run on
nodename	the name of the node

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetCreateReaderKey	(	Key_t	nodekey,
		const std::string &	portname
	)

pure virtual

Get the key associated with the given endpoint for the given node. Creates the information if it does not exist.

Parameters

nodekey	the unique id for the node
portname	the name of the endpoint.

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetCreateWriterKey	(	Key_t	nodekey,
		const std::string &	portname
	)

pure virtual

See Also: GetCreateReaderKey

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual void CPN::Context::GetKernelConnectionInfo	(	Key_t	kernelkey,
		std::string &	hostname,
		std::string &	servname
	)

pure virtual

obtain the connection information for the given kernel

Parameters

kernelkey	the unique id for the kernel
hostname	(output) string to be filled with the hostname
servname	(output) string to be filled with the service name

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetKernelKey ( const std::string & kernel )

pure virtual

Parameters

kernel the name of the kernel

Returns: the key for the given kernel.

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual std::string CPN::Context::GetKernelName ( Key_t kernelkey )

pure virtual

Parameters

kernelkey the key to the kernel

Returns: the name for the kernel

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetNodeKernel ( Key_t nodekey )

pure virtual

Parameters

nodekey the unique key for the node

Returns: the key for the kernel the node is running on

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetNodeKey ( const std::string & nodename )

pure virtual

Returns: the unique key associated with the given node name.

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual std::string CPN::Context::GetNodeName ( Key_t nodekey )

pure virtual

Returns: the name associated with the given node key

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetReaderKernel ( Key_t portkey )

pure virtual

Parameters

portkey the unique id for the port

Returns: the key for the kernel this port is on

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual std::string CPN::Context::GetReaderName ( Key_t portkey )

pure virtual

Parameters

portkey the unique id for the port

Returns: the name of the port

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetReaderNode ( Key_t portkey )

pure virtual

Parameters

portkey the unique id for the port

Returns: the key for the node this port is on

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetReadersWriter ( Key_t readerkey )

pure virtual

Parameters

readerkey a unique reader key

Returns: the writer key associated with this reader key if there is one

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetWriterKernel ( Key_t portkey )

pure virtual

See Also: GetReaderKernel

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual std::string CPN::Context::GetWriterName ( Key_t portkey )

pure virtual

See Also: GetReaderName

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetWriterNode ( Key_t portkey )

pure virtual

See Also: GetReaderNode

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::GetWritersReader ( Key_t writerkey )

pure virtual

Parameters

writerkey a unique writer key

Returns: the reader key associated with this writer

Exceptions

ShutdownException
std::invalid_argument

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual bool CPN::Context::IsTerminated ( )

pure virtual

Returns: true if Terminate has been called

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

Referenced by CheckTerminated().

Here is the caller graph for this function:

shared_ptr< Context > CPN::Context::Local ( )

static

Create a local context.

Returns: a new local context.

Definition at line 29 of file Context.cc.

Referenced by CPN::Kernel::Kernel(), and CPN::VariantCPNLoader::LoadContext().

                                        {
         return shared_ptr<Context>(new LocalContext);
     }

Here is the caller graph for this function:

virtual void LoggerOutput::Log	(	int	level,
		const std::string &	msg
	)

pure virtualinherited

Log a message to this outputer.

Parameters

level	the level of this message
msg	the message

Implemented in LoggerStdOutput, Logger, CPN::LocalContext, and CPN::RemoteContextClient.

Referenced by Logger::Log().

Here is the caller graph for this function:

virtual int LoggerOutput::LogLevel ( ) const

pure virtualinherited

Returns: the current log level

Implemented in LoggerStdOutput, CPN::LocalContext, Logger, and CPN::RemoteContextClient.

Referenced by Logger::Logger().

Here is the caller graph for this function:

virtual int LoggerOutput::LogLevel ( int level )

pure virtualinherited

Parameters

level the new log level

Returns: the new log level

Implemented in LoggerStdOutput, CPN::LocalContext, Logger, and CPN::RemoteContextClient.

bool CPN::Context::RequireRemote ( )

virtual

Lets the kernel know that this context type requires remote activity. This overrides the kernel option for remote activity. Default value is false.

Returns: true or false

Reimplemented in CPN::RemoteContextClient.

Definition at line 40 of file Context.cc.

                                 {
         return false;
     }

virtual void CPN::Context::SendCreateNode	(	Key_t	kernelkey,
		const NodeAttr &	attr
	)

pure virtual

Tell a given kernel that it needs to create a node.

Parameters

kernelkey	the id of the kernel
attr	the node attribute

Exceptions

ShutdownException

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual void CPN::Context::SendCreateQueue	(	Key_t	kernelkey,
		const SimpleQueueAttr &	attr
	)

pure virtual

Tell a given kernel that it needs to create a queue.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual void CPN::Context::SendCreateReader	(	Key_t	kernelkey,
		const SimpleQueueAttr &	attr
	)

pure virtual

Tell a given kernel that it needs to create a queue read end.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual void CPN::Context::SendCreateWriter	(	Key_t	kernelkey,
		const SimpleQueueAttr &	attr
	)

pure virtual

Tell a given kernel that it needs to create a queue write end.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implemented in CPN::LocalContext, and CPN::RemoteContextClient.

virtual Key_t CPN::Context::SetupKernel	(	const std::string &	name,
		const std::string &	hostname,
		const std::string &	servname,
		KernelBase *	kernel
	)

pure virtual

Called by the Kernel when it has successfully set it self up. This gives the Context a way to notify the Kernel of events and lets other Kernels look up the connection information for this Kernel.

Parameters
