CPN::NodeAttr Class Reference

Attributes for a node. More...

#include <NodeAttr.h>

Collaboration diagram for CPN::NodeAttr:

Public Member Functions
	NodeAttr (const std::string &name_, const std::string &nodetype_)
NodeAttr &	SetName (const std::string &name_)
NodeAttr &	SetTypeName (const std::string &nodetype_)
NodeAttr &	SetKernel (const std::string &kname)
NodeAttr &	SetKernelKey (Key_t k)
NodeAttr &	SetParam (const std::string &key, const std::string value)
template<typename T >
NodeAttr &	SetParam (const std::string &key, T value)
NodeAttr &	SetKey (Key_t key_)
const std::string &	GetKernel () const
Key_t	GetKernelKey () const
const std::string &	GetName () const
const std::string &	GetTypeName () const
const std::map< std::string, std::string > &	GetParams () const
Key_t	GetKey () const

Private Attributes
std::string	kernelname
Key_t	kernelkey
std::string	name
std::string	nodetype
std::map< std::string, std::string >	params
Key_t	key

Detailed Description

Attributes for a node.

This structure contains all the attributes and parameters a node needs to start up. Note that this structure is used to pass to the Kernel to create a node and that fields like key are set by the Kernel.

The only required parameters are the name and node type.

The other parameters that the user may set are:

The kernel for the node can be set as either the kernel name or the kernel key. If the kernel key is set kernel name is ignored. See SetKernel and SetKernelKey.

The parameters sent to the node. See SetParam and GetParam

Note that the key attribute are set by the kernel when the node is to be created and such are overwritten.

Definition at line 58 of file NodeAttr.h.

Constructor & Destructor Documentation

CPN::NodeAttr::NodeAttr ( const std::string &  name_, const std::string &  nodetype_  )

inline

Definition at line 60 of file NodeAttr.h.

            : kernelname(),
            kernelkey(0),
            name(name_),
            nodetype(nodetype_),
            key(0)
        {}

Member Function Documentation

const std::string& CPN::NodeAttr::GetKernel ( ) const

inline

Definition at line 107 of file NodeAttr.h.

Referenced by CPN::Kernel::CreateNode(), and CPN::RemoteContextClient::SendCreateNode().

{ return kernelname; }

Here is the caller graph for this function:

Key_t CPN::NodeAttr::GetKernelKey ( ) const

inline

Definition at line 108 of file NodeAttr.h.

Referenced by CPN::Kernel::CreateNode().

{ return kernelkey; }

Here is the caller graph for this function:

Key_t CPN::NodeAttr::GetKey ( ) const

inline

Definition at line 116 of file NodeAttr.h.

Referenced by CPN::Kernel::InternalCreateNode(), and CPN::RemoteContextClient::SendCreateNode().

{ return key; }

Here is the caller graph for this function:

const std::string& CPN::NodeAttr::GetName ( ) const

inline

Definition at line 110 of file NodeAttr.h.

Referenced by CPN::Kernel::CreateNode(), CPN::VariantCPNLoader::LoadNode(), and CPN::RemoteContextClient::SendCreateNode().

{ return name; }

Here is the caller graph for this function:

const std::map<std::string, std::string>& CPN::NodeAttr::GetParams ( ) const

inline

Definition at line 114 of file NodeAttr.h.

Referenced by CPN::RemoteContextClient::SendCreateNode().

{ return params; }

Here is the caller graph for this function:

const std::string& CPN::NodeAttr::GetTypeName ( ) const

inline

Definition at line 112 of file NodeAttr.h.

Referenced by CPN::Kernel::InternalCreateNode(), and CPN::RemoteContextClient::SendCreateNode().

{ return nodetype; }

Here is the caller graph for this function:

NodeAttr& CPN::NodeAttr::SetKernel ( const std::string &  kname )

inline

Definition at line 79 of file NodeAttr.h.

Referenced by CPN::VariantCPNLoader::LoadNode(), and CPN::MsgToNodeAttr().

                                                    {
            kernelname = kname;
            return *this;
        }

Here is the caller graph for this function:

NodeAttr& CPN::NodeAttr::SetKernelKey ( Key_t  k )

inline

Definition at line 84 of file NodeAttr.h.

Referenced by CPN::Kernel::CreateNode().

                                        {
            kernelkey = k;
            return *this;
        }

Here is the caller graph for this function:

NodeAttr& CPN::NodeAttr::SetKey ( Key_t  key_ )

inline

Definition at line 102 of file NodeAttr.h.

Referenced by CPN::Kernel::CreateNode(), and CPN::MsgToNodeAttr().

                                     {
            key = key_;
            return *this;
        }

Here is the caller graph for this function:

NodeAttr& CPN::NodeAttr::SetName ( const std::string &  name_ )

inline

Definition at line 69 of file NodeAttr.h.

                                                  {
            name = name_;
            return *this;
        }

NodeAttr& CPN::NodeAttr::SetParam ( const std::string &  key, const std::string  value  )

inline

Definition at line 89 of file NodeAttr.h.

Referenced by CPN::VariantCPNLoader::LoadNode(), and CPN::MsgToNodeAttr().

                                                                        {
            params[key] = value;
            return *this;
        }

Here is the caller graph for this function:

template<typename T >

NodeAttr& CPN::NodeAttr::SetParam ( const std::string &  key, T  value  )

inline

Definition at line 95 of file NodeAttr.h.

                                                          {
            std::ostringstream oss;
            oss << value;
            params[key] = oss.str();
            return *this;
        }

NodeAttr& CPN::NodeAttr::SetTypeName ( const std::string &  nodetype_ )

inline

Definition at line 74 of file NodeAttr.h.

                                                          {
            nodetype = nodetype_;
            return *this;
        }

Member Data Documentation

Key_t CPN::NodeAttr::kernelkey

private

Definition at line 120 of file NodeAttr.h.

std::string CPN::NodeAttr::kernelname

private

Definition at line 119 of file NodeAttr.h.

Key_t CPN::NodeAttr::key

private

Definition at line 124 of file NodeAttr.h.

std::string CPN::NodeAttr::name

private

Definition at line 121 of file NodeAttr.h.

std::string CPN::NodeAttr::nodetype

private

Definition at line 122 of file NodeAttr.h.

std::map<std::string, std::string> CPN::NodeAttr::params

private

Definition at line 123 of file NodeAttr.h.

---

The documentation for this class was generated from the following file:

• include/cpn/NodeAttr.h
