SocketAddress Class Reference

An abstraction of a socket address with convenience methods. More...

#include <SocketAddress.h>

Collaboration diagram for SocketAddress:

Classes
union	address_

Public Types
enum	Type_t { IPV4, IPV6, LOCAL }

Public Member Functions
	SocketAddress ()
	SocketAddress (addrinfo *info)
	SocketAddress (addrinfo *info, unsigned portnum)
	SocketAddress (sockaddr *addr, socklen_t len)
	~SocketAddress ()
std::string	GetHostName (bool numerichost=true) const
std::string	GetServName () const
unsigned	GetServ () const
Type_t	GetType () const
sockaddr *	GetAddr ()
socklen_t &	GetLen ()
sa_family_t &	Family ()
sa_family_t	Family () const
void	SetFromSockName (int fd)
	Fill this SocketAddress with data from this side of the connection represented by fd. More...
void	SetFromPeerName (int fd)
	Fill this SocketAddress with data from the other side of the connection represented by fd. More...

Static Public Member Functions
static SockAddrList	CreateIPFromServ (const char *servname)
	Return a list of valid socket addresses for the given service name All CreateIP functions create IP addresses. More...
static SockAddrList	CreateIPFromServ (const std::string &servname)
static SockAddrList	CreateIPFromHost (const char *hostname)
static SockAddrList	CreateIPFromHost (const std::string &hostname)
static SockAddrList	CreateIP (unsigned serv)
	Return a list of valid socket address for the given service number or port number. More...
static SockAddrList	CreateIP (const char *hostname, const char *servname)
static SockAddrList	CreateIP (const std::string &hostname, const std::string &servname)
static SockAddrList	CreateIP (const char *hostname, unsigned serv)
static SockAddrList	CreateIP (const std::string &hostname, unsigned serv)
static SockAddrList	CreateIP (const std::string &hostname)

Static Private Member Functions
static SockAddrList	Lookup (const char *const hostname, const char *const port, int family, unsigned portnum)

Private Attributes
socklen_t	length
union SocketAddress::address_	address

Detailed Description

An abstraction of a socket address with convenience methods.

Definition at line 42 of file SocketAddress.h.

Member Enumeration Documentation

enum SocketAddress::Type_t

Enumerator
IPV4
IPV6
LOCAL

Definition at line 45 of file SocketAddress.h.

                {
        IPV4,
        IPV6,
        LOCAL
    };

Constructor & Destructor Documentation

SocketAddress::SocketAddress

(

)

Definition at line 33 of file SocketAddress.cc.

References address.

Referenced by Lookup().

    : length(0)
{
    memset(&address, 0, sizeof(address));
}

Here is the caller graph for this function:

SocketAddress::SocketAddress

(

addrinfo *

info

)

Definition at line 174 of file SocketAddress.cc.

References address, and length.

                                           {
    length = info->ai_addrlen;
    memcpy(&address, info->ai_addr, length);
}

SocketAddress::SocketAddress	(	addrinfo *	info,
		unsigned	portnum
	)

Definition at line 179 of file SocketAddress.cc.

References address, Family(), SocketAddress::address_::in, SocketAddress::address_::in6, and length.

                                                             {
    length = info->ai_addrlen;
    memcpy(&address, info->ai_addr, length);
    uint16_t port = (uint16_t)portnum;
    port = htons(port);
    switch (Family()) {
    case AF_INET:
        address.in.sin_port = port;
        break;
    case AF_INET6:
        address.in6.sin6_port = port;
        break;
    default:
        break;
    }
}

Here is the call graph for this function:

SocketAddress::SocketAddress	(	sockaddr *	addr,
		socklen_t	len
	)

Create a SocketAddress from the underlying sockaddr and length

Parameters

addr	pointer tot he address structure
len	the length of the address structure

Definition at line 196 of file SocketAddress.cc.

References address, and length.

                                                          {
    memcpy(&address, addr, len);
    length = len;
}

SocketAddress::~SocketAddress ( )

inline

Definition at line 94 of file SocketAddress.h.

{}

Member Function Documentation

SockAddrList SocketAddress::CreateIP ( unsigned  serv )

static

Return a list of valid socket address for the given service number or port number.

Definition at line 103 of file SocketAddress.cc.

References address, Family(), SocketAddress::address_::in, and length.

Referenced by CPN::ConnectionServer::ConnectWriter(), CPN::Kernel::Kernel(), and CPN::VariantCPNLoader::LoadContext().

                                                  {
    SocketAddress addr;
    addr.Family() = AF_INET;
    addr.address.in.sin_port = htons(serv);
    addr.address.in.sin_addr.s_addr = INADDR_ANY;
    addr.length = sizeof(sockaddr_in);
    SockAddrList list;
    list.push_back(addr);
    return list;
}

Here is the call graph for this function:

Here is the caller graph for this function:

SockAddrList SocketAddress::CreateIP ( const char *  hostname, const char *  servname  )

static

Parameters

hostname	The hostname to lookup
servname	the service name to lookup, may be a number string for the port

Returns

a list of valid addresses to connect to the given host/port

Definition at line 114 of file SocketAddress.cc.

References Lookup().

                                                                               {
    return Lookup(hostname, servname, AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIP ( const std::string &  hostname, const std::string &  servname  )

static

Definition at line 118 of file SocketAddress.cc.

References Lookup().

                                                                                         {
    return Lookup(hostname.c_str(), servname.c_str(), AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIP ( const char *  hostname, unsigned  serv  )

static

Parameters

hostname	the hostname to lookup
serv	the port number

Returns

a list of valid address to connect to the given host/port

Definition at line 122 of file SocketAddress.cc.

References Lookup().

                                                                        {
    return Lookup(hostname, 0, AF_UNSPEC, serv);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIP ( const std::string &  hostname, unsigned  serv  )

static

Definition at line 126 of file SocketAddress.cc.

References Lookup().

                                                                             {
    return Lookup(hostname.c_str(), 0, AF_UNSPEC, serv);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIP ( const std::string &  hostname )

static

Create socket addresses from hostname:port, [hostname]:port type strings as described in RFC 2732.

Parameters

hostname

Definition at line 130 of file SocketAddress.cc.

References Lookup().

                                                              {
    std::string host;
    std::string port;
    std::string::const_iterator it, e;
    e = hostname.end();
    it = hostname.begin();
    bool in_address = false;
    bool at_port = false;
    while (it != e) {
        if (in_address) {
            if (*it == ']') {
                in_address = false;
            } else {
                host.push_back(*it);
            }
        }
        if (at_port) {
            port.push_back(*it);
        } else {
            switch (*it) {
            case '[':
                in_address = true;
                break;
            case ':':
                at_port = true;
                break;
            default:
                host.push_back(*it);
                break;
            }
        }
        ++it;
    }
    const char *h = 0;
    const char *p = 0;
    if (!host.empty()) {
        h = host.c_str();
    }
    if (!port.empty()) {
        p = port.c_str();
    }
    return Lookup(h, p, AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIPFromHost ( const char *  hostname )

static

Definition at line 95 of file SocketAddress.cc.

References Lookup().

                                                                 {
    return Lookup(hostname, 0, AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIPFromHost ( const std::string &  hostname )

static

Definition at line 99 of file SocketAddress.cc.

References Lookup().

                                                                      {
    return Lookup(hostname.c_str(), 0, AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIPFromServ ( const char *  servname )

static

Return a list of valid socket addresses for the given service name All CreateIP functions create IP addresses.

Returns

a list of SocketAddresses

Definition at line 87 of file SocketAddress.cc.

References Lookup().

                                                                 {
    return Lookup(0, servname, AF_UNSPEC, 0);
}

Here is the call graph for this function:

SockAddrList SocketAddress::CreateIPFromServ ( const std::string &  servname )

static

Definition at line 91 of file SocketAddress.cc.

References Lookup().

                                                                      {
    return Lookup(0, servname.c_str(), AF_UNSPEC, 0);
}

Here is the call graph for this function:

sa_family_t& SocketAddress::Family ( )

inline

Definition at line 115 of file SocketAddress.h.

References address, and SocketAddress::address_::storage.

Referenced by SocketHandle::Connect(), CreateIP(), GetServ(), GetType(), ServerSocketHandle::Listen(), and SocketAddress().

{ return address.storage.ss_family; }

Here is the caller graph for this function:

sa_family_t SocketAddress::Family ( ) const

inline

Definition at line 116 of file SocketAddress.h.

References address, and SocketAddress::address_::storage.

{ return address.storage.ss_family; }

sockaddr* SocketAddress::GetAddr ( )

inline

Definition at line 113 of file SocketAddress.h.

References SocketAddress::address_::addr, and address.

Referenced by ServerSocketHandle::Accept(), SocketHandle::Connect(), ServerSocketHandle::Listen(), SetFromPeerName(), and SetFromSockName().

{ return &address.addr; }

Here is the caller graph for this function:

std::string SocketAddress::GetHostName

(

bool

numerichost = true

)

const

Parameters

numerichost

true to force no resolution of host names and just return the number

Returns

a string representation of the host name

Definition at line 201 of file SocketAddress.cc.

References SocketAddress::address_::addr, address, and length.

Referenced by CPN::RemoteContextDaemon::Client::Client(), CPN::Kernel::Kernel(), and CPN::RemoteContextDaemon::Run().

                                                           {
    std::vector<char> hostname(NI_MAXHOST, '\0');
    bool loop = true;
    std::ostringstream oss;
    while (loop) {
        int flags = NI_NUMERICSERV;
        if (numerichost) { flags |= NI_NUMERICHOST; }
        int lookupstatus = getnameinfo(&address.addr, length,
                    &hostname[0], hostname.size(),
                    0, 0,
                    flags);
        switch (lookupstatus) {
        case 0:
            oss << &hostname[0];
            loop = false;
            break;
        case EAI_AGAIN:
            break;
#if !defined(__APPLE__)
        case EAI_OVERFLOW:
            hostname.resize(hostname.size()*2, '\0');
            break;
#endif
        case EAI_BADFLAGS:
        case EAI_FAIL:
        case EAI_FAMILY:
        case EAI_MEMORY:
        case EAI_NONAME:
        case EAI_SYSTEM:
        default:
            throw ErrnoException(gai_strerror(lookupstatus), lookupstatus);
        }
    }
    return oss.str();
}

Here is the caller graph for this function:

socklen_t& SocketAddress::GetLen ( )

inline

Definition at line 114 of file SocketAddress.h.

References length.

Referenced by ServerSocketHandle::Accept(), SocketHandle::Connect(), ServerSocketHandle::Listen(), SetFromPeerName(), and SetFromSockName().

{ return length; }

Here is the caller graph for this function:

unsigned SocketAddress::GetServ

(

)

const

Returns

the service (port) number

Definition at line 271 of file SocketAddress.cc.

References address, Family(), SocketAddress::address_::in, and SocketAddress::address_::in6.

                                      {
    uint16_t retval = 0;
    switch (Family()) {
    case AF_INET:
        retval = address.in.sin_port;
        break;
    case AF_INET6:
        retval = address.in6.sin6_port;
        break;
    default:
        break;
    }
    return (unsigned)ntohs(retval);
}

Here is the call graph for this function:

std::string SocketAddress::GetServName

(

)

const

Returns

the service (port) name or number as a string.

Definition at line 237 of file SocketAddress.cc.

References SocketAddress::address_::addr, address, and length.

Referenced by CPN::RemoteContextDaemon::Client::Client(), CPN::Kernel::Kernel(), and CPN::RemoteContextDaemon::Run().

                                           {
    std::vector<char> servname(NI_MAXSERV, '\0');
    bool loop = true;
    std::ostringstream oss;
    while (loop) {
        int lookupstatus = getnameinfo(&address.addr, length,
                    0, 0,
                    &servname[0], servname.size(),
                    NI_NUMERICSERV);
        switch (lookupstatus) {
        case 0:
            oss << &servname[0];
            loop = false;
            break;
        case EAI_AGAIN:
            break;
#if !defined(__APPLE__)
        case EAI_OVERFLOW:
            servname.resize(servname.size()*2, '\0');
            break;
#endif
        case EAI_BADFLAGS:
        case EAI_FAIL:
        case EAI_FAMILY:
        case EAI_MEMORY:
        case EAI_NONAME:
        case EAI_SYSTEM:
        default:
            throw ErrnoException(gai_strerror(lookupstatus), lookupstatus);
        }
    }
    return oss.str();
}

Here is the caller graph for this function:

SocketAddress::Type_t SocketAddress::GetType

(

)

const

Definition at line 286 of file SocketAddress.cc.

References ASSERT, Family(), IPV4, IPV6, and LOCAL.

                                                 {
    Type_t type;
    switch (Family()) {
    case AF_INET:
        type = IPV4;
        break;
    case AF_INET6:
        type = IPV6;
        break;
    case AF_UNIX:
        type = LOCAL;
        break;
    default:
        ASSERT(false, "Unknown address type.");
    }
    return type;
}

Here is the call graph for this function:

SockAddrList SocketAddress::Lookup ( const char *const  hostname, const char *const  port, int  family, unsigned  portnum  )

staticprivate

Definition at line 39 of file SocketAddress.cc.

References SocketAddress().

Referenced by CreateIP(), CreateIPFromHost(), and CreateIPFromServ().

                                      {
    addrinfo hints = {0};
    // Get only supported types.
    hints.ai_flags = AI_ADDRCONFIG;
    hints.ai_family = family;
    hints.ai_socktype = SOCK_STREAM;
    if (0 == hostname || *hostname == '\0') {
        hints.ai_flags |= AI_PASSIVE;
    }
    addrinfo *res = 0;
    int lookupstatus = 0;
    do {
        lookupstatus = getaddrinfo(hostname, port, &hints, &res);
        switch (lookupstatus) {
            case EAI_AGAIN:
                // try again
            case EAI_MEMORY:
                // our of memory, try again?
            case 0:
                // Success.
                break;
            case EAI_ADDRFAMILY:
            case EAI_BADFLAGS:
            case EAI_FAIL:
            case EAI_FAMILY:
            case EAI_NODATA:
            case EAI_NONAME:
            case EAI_SERVICE:
            case EAI_SOCKTYPE:
            case EAI_SYSTEM:
            default:
                throw ErrnoException(gai_strerror(lookupstatus), lookupstatus);
        }
    } while (lookupstatus != 0);

    SockAddrList results;
    for (addrinfo *rp = res; rp != 0; rp = rp->ai_next) {
        if (port) {
            results.push_back(SocketAddress(rp));
        } else {
            results.push_back(SocketAddress(rp, portnum));
        }
    }
    freeaddrinfo(res);
    return results;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void SocketAddress::SetFromPeerName

(

int

fd

)

Fill this SocketAddress with data from the other side of the connection represented by fd.

Parameters

fd	the socket to use

Definition at line 311 of file SocketAddress.cc.

References GetAddr(), and GetLen().

Referenced by CPN::RemoteContextDaemon::Client::Client().

                                          {
    GetLen() = sizeof(sockaddr_storage);
    if (getpeername(fd, GetAddr(), &GetLen()) != 0) {
        throw ErrnoException();
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void SocketAddress::SetFromSockName

(

int

fd

)

Fill this SocketAddress with data from this side of the connection represented by fd.

Parameters

fd	the socket to use

Definition at line 304 of file SocketAddress.cc.

References GetAddr(), and GetLen().

Referenced by CPN::ConnectionServer::GetAddress(), and CPN::RemoteContextDaemon::Run().

                                          {
    GetLen() = sizeof(sockaddr_storage);
    if (getsockname(fd, GetAddr(), &GetLen()) != 0) {
        throw ErrnoException();
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

union SocketAddress::address_ SocketAddress::address

private

Referenced by CreateIP(), Family(), GetAddr(), GetHostName(), GetServ(), GetServName(), and SocketAddress().

socklen_t SocketAddress::length

private

Definition at line 135 of file SocketAddress.h.

Referenced by CreateIP(), GetHostName(), GetLen(), GetServName(), and SocketAddress().

---

The documentation for this class was generated from the following files:

• include/cpn/io/SocketAddress.h
• lib/io/SocketAddress.cc
