CPN::ExternalEndpoint Class Reference

Inheritance diagram for CPN::ExternalEndpoint:

Collaboration diagram for CPN::ExternalEndpoint:

Public Member Functions
	ExternalEndpoint (const std::string &name, Key_t nodekey, shared_ptr< Context > context, bool iswriter_)
virtual	~ExternalEndpoint ()
bool	IsWriter () const
const std::string &	GetName () const
Key_t	GetKey () const
shared_ptr< QueueReader >	GetIQueue (const std::string &portname)
	This method is for use by the user to aquire a reader endpoint. This function blocks until the CPN::Kernel hands this node the queue associated with the endpoint. More...
shared_ptr< QueueWriter >	GetOQueue (const std::string &portname)
	This method is for use by the user to aquire a writer endpoint. This function blocks until the CPN::Kernel hands this node the queue associated with the endpoint. More...
void	CreateReader (shared_ptr< QueueBase > q)
	for use by the CPN::Kernel to create a new read endpoint. More...
void	CreateWriter (shared_ptr< QueueBase > q)
	for use by the CPN::Kernel to create a new writer endpoint. More...
void	NotifyTerminate ()
	Called by the kernel when it is shutting down. More...
virtual void	Shutdown ()
	Perform actions (like joining a thread) before destruction. More...
virtual bool	IsPurePseudo ()
virtual void	LogState ()
	For debugging ONLY! More...

Protected Attributes
Logger	logger

Private Attributes
bool	iswriter

Detailed Description

Definition at line 166 of file Kernel.cc.

Constructor & Destructor Documentation

CPN::ExternalEndpoint::ExternalEndpoint ( const std::string &  name, Key_t  nodekey, shared_ptr< Context >  context, bool  iswriter_  )

inline

Definition at line 168 of file Kernel.cc.

            : PseudoNode(name, nodekey, context), iswriter(iswriter_) {}

virtual CPN::ExternalEndpoint::~ExternalEndpoint ( )

inlinevirtual

Definition at line 171 of file Kernel.cc.

{}

Member Function Documentation

void CPN::PseudoNode::CreateReader ( shared_ptr< QueueBase >  q )

inherited

for use by the CPN::Kernel to create a new read endpoint.

Definition at line 55 of file PseudoNode.cc.

References ASSERT, CPN::PseudoNode::cond, CPN::PseudoNode::d4rnode, CPN::PseudoNode::lock, CPN::PseudoNode::readermap, and Sync::ReentrantCondition::Signal().

                                                         {
        Sync::AutoReentrantLock arl(lock);
        Key_t readerkey = q->GetReaderKey();
        d4rnode->AddReader(q);
        q->SetReaderNode(d4rnode);
        q->SignalReaderTagChanged();
        ASSERT(readermap.find(readerkey) == readermap.end(), "The reader already exists");
        shared_ptr<QueueReader> reader;
        reader = shared_ptr<QueueReader>(new QueueReader(this, q));
        readermap.insert(std::make_pair(readerkey, reader));
        cond.Signal();
    }

Here is the call graph for this function:

void CPN::PseudoNode::CreateWriter ( shared_ptr< QueueBase >  q )

inherited

for use by the CPN::Kernel to create a new writer endpoint.

Definition at line 68 of file PseudoNode.cc.

References ASSERT, CPN::PseudoNode::cond, CPN::PseudoNode::d4rnode, CPN::PseudoNode::lock, Sync::ReentrantCondition::Signal(), and CPN::PseudoNode::writermap.

                                                         {
        Sync::AutoReentrantLock arl(lock);
        Key_t writerkey = q->GetWriterKey();
        d4rnode->AddWriter(q);
        q->SetWriterNode(d4rnode);
        q->SignalWriterTagChanged();
        ASSERT(writermap.find(writerkey) == writermap.end(), "The writer already exists.");
        shared_ptr<QueueWriter> writer;
        writer = shared_ptr<QueueWriter>(new QueueWriter(this, q));
        writermap.insert(std::make_pair(writerkey, writer));
        cond.Signal();
    }

Here is the call graph for this function:

shared_ptr< QueueReader > CPN::PseudoNode::GetIQueue ( const std::string &  portname )

inherited

This method is for use by the user to aquire a reader endpoint. This function blocks until the CPN::Kernel hands this node the queue associated with the endpoint.

Parameters

portname

the port name of the reader to get.

Returns

a shared pointer to a reader for he given endpoint name

Definition at line 43 of file PseudoNode.cc.

References CPN::PseudoNode::context, CPN::PseudoNode::GetReader(), and CPN::PseudoNode::nodekey.

                                                                           {
        context->CheckTerminated();
        Key_t ekey = context->GetCreateReaderKey(nodekey, portname);
        return GetReader(ekey);
    }

Here is the call graph for this function:

Key_t CPN::PseudoNode::GetKey ( ) const

inlineinherited

Returns

the process network wide unique id for this node

Definition at line 43 of file PseudoNode.h.

Referenced by CPN::NodeBase::EntryPoint().

{ return nodekey; }

Here is the caller graph for this function:

const std::string& CPN::PseudoNode::GetName ( ) const

inlineinherited

Returns

the unique name of this node

Definition at line 40 of file PseudoNode.h.

Referenced by CPN::NodeBase::EntryPoint(), and CPN::NodeBase::GetParam().

{ return name; }

Here is the caller graph for this function:

shared_ptr< QueueWriter > CPN::PseudoNode::GetOQueue ( const std::string &  portname )

inherited

This method is for use by the user to aquire a writer endpoint. This function blocks until the CPN::Kernel hands this node the queue associated with the endpoint.

Parameters

portname

the port name fo the writer to get.

Returns

a shared pointer to a writer for the given endpoint name.

Definition at line 49 of file PseudoNode.cc.

References CPN::PseudoNode::context, CPN::PseudoNode::GetWriter(), and CPN::PseudoNode::nodekey.

                                                                           {
        context->CheckTerminated();
        Key_t ekey = context->GetCreateWriterKey(nodekey, portname);
        return GetWriter(ekey);
    }

Here is the call graph for this function:

bool CPN::PseudoNode::IsPurePseudo ( )

virtualinherited

Reimplemented in CPN::NodeBase.

Definition at line 163 of file PseudoNode.cc.

                                  {
        return true;
    }

bool CPN::ExternalEndpoint::IsWriter ( ) const

inline

Definition at line 173 of file Kernel.cc.

References iswriter.

{ return iswriter; }

void CPN::PseudoNode::LogState ( )

virtualinherited

For debugging ONLY!

Reimplemented in CPN::NodeBase.

Definition at line 167 of file PseudoNode.cc.

References D4R::Tag::Count(), CPN::PseudoNode::d4rnode, Logger::Error(), D4R::Tag::Key(), CPN::PseudoNode::logger, CPN::PseudoNode::nodekey, D4R::Tag::QueueKey(), D4R::Tag::QueueSize(), CPN::PseudoNode::readermap, and CPN::PseudoNode::writermap.

Referenced by CPN::NodeBase::LogState().

                              {
        logger.Error("Logging (key: %llu), %u readers, %u writers",
                nodekey, readermap.size(), writermap.size());
        D4R::Tag tag = d4rnode->GetPrivateTag();
        logger.Error("Private key: (%llu, %llu, %llu, %llu)", tag.Count(), tag.Key(), tag.QueueSize(), tag.QueueKey());
        tag = d4rnode->GetPublicTag();
        logger.Error("Public key: (%llu, %llu, %llu, %llu)", tag.Count(), tag.Key(), tag.QueueSize(), tag.QueueKey());
        ReaderMap::iterator r = readermap.begin();
        while (r != readermap.end()) {
            r->second->GetQueue()->LogState();
            ++r;
        }
        WriterMap::iterator w = writermap.begin();
        while (w != writermap.end()) {
            w->second->GetQueue()->LogState();
            ++w;
        }
    }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::PseudoNode::NotifyTerminate ( )

inherited

Called by the kernel when it is shutting down.

Definition at line 123 of file PseudoNode.cc.

References CPN::PseudoNode::cond, CPN::PseudoNode::lock, CPN::PseudoNode::readermap, Sync::ReentrantCondition::Signal(), and CPN::PseudoNode::writermap.

                                     {
        Sync::AutoReentrantLock arl(lock);
        cond.Signal();
        WriterMap::iterator witr = writermap.begin();
        while (witr != writermap.end()) { (witr++)->second->NotifyTerminate(); }
        ReaderMap::iterator ritr = readermap.begin();
        while (ritr != readermap.end()) { (ritr++)->second->NotifyTerminate(); }
    }

Here is the call graph for this function:

void CPN::PseudoNode::Shutdown ( )

virtualinherited

Perform actions (like joining a thread) before destruction.

Reimplemented in CPN::NodeBase.

Definition at line 81 of file PseudoNode.cc.

References CPN::PseudoNode::lock, CPN::PseudoNode::readermap, AutoLock< Lockable >::Unlock(), and CPN::PseudoNode::writermap.

Referenced by CPN::NodeBase::Shutdown().

                              {
        Sync::AutoReentrantLock arl(lock);
        ReaderMap readers;
        readers.swap(readermap);
        WriterMap writers;
        writers.swap(writermap);
        arl.Unlock();
        for (ReaderMap::iterator i = readers.begin(); i != readers.end(); ++i) {
            i->second->GetQueue()->ShutdownReader();
        }
        for (WriterMap::iterator i = writers.begin(); i != writers.end(); ++i) {
            i->second->GetQueue()->ShutdownWriter();
        }
        readers.clear();
        writers.clear();

    }

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

bool CPN::ExternalEndpoint::iswriter

private

Definition at line 175 of file Kernel.cc.

Referenced by IsWriter().

Logger CPN::PseudoNode::logger

protectedinherited

Definition at line 76 of file PseudoNode.h.

Referenced by CPN::NodeBase::EntryPoint(), CPN::PseudoNode::LogState(), and CPN::NodeBase::LogState().

---

The documentation for this class was generated from the following file:

• lib/Kernel.cc
