A version of the ThresholdQueue that provides the CPN Queue interface This queue implementation creates a memory mapped object which has as a minimum size the machine page size. So there is an effective minimum queue size. Any queue size less than the page size will be expanded to the page size. More...

#include <CPNThresholdQueue.h>

Inheritance diagram for CPN::ThresholdQueue:

Collaboration diagram for CPN::ThresholdQueue:

Classes
class	TQImpl

Public Member Functions
	ThresholdQueue (KernelBase *k, const SimpleQueueAttr &attr, bool usembs)

	ThresholdQueue (KernelBase *k, const SimpleQueueAttr &attr, unsigned length, bool usembs)

	~ThresholdQueue ()

const void *	GetRawDequeuePtr (unsigned thresh, unsigned chan)

void	Dequeue (unsigned count)

bool	RawDequeue (void *data, unsigned count, unsigned numChans, unsigned chanStride)

bool	RawDequeue (void *data, unsigned count)

void *	GetRawEnqueuePtr (unsigned thresh, unsigned chan)

void	Enqueue (unsigned count)

void	RawEnqueue (const void *data, unsigned count, unsigned numChans, unsigned chanStride)

void	RawEnqueue (const void *data, unsigned count)

void	Reset ()

void	Flush ()

bool	Flushed () const

unsigned	NumChannels () const

unsigned	Count () const

bool	Empty () const

unsigned	Freespace () const

bool	Full () const

unsigned	MaxThreshold () const

unsigned	QueueLength () const

unsigned	EnqueueChannelStride () const

unsigned	DequeueChannelStride () const

void	Grow (unsigned queueLen, unsigned maxThresh)

Key_t	GetWriterKey () const

Key_t	GetReaderKey () const

const std::string &	GetDatatype () const

void	ShutdownReader ()
	Called by the QueueReader when no more data will be read. More...

void	ShutdownWriter ()
	Called by the QueueWriter when no more data will be written. More...

void	NotifyTerminate ()
	Used to tell any waiting threads that the network is terminating. More...

void	Lock () const

void	Unlock () const

unsigned	ReadRequest ()
	For unit tests. More...

unsigned	WriteRequest ()
	For unit tests. More...

bool	IsReaderShutdown ()

bool	IsWriterShutdown ()

virtual void	LogState ()
	For debugging ONLY!! Otherwise non deterministic output. More...

unsigned	NumEnqueued () const

unsigned	NumDequeued () const

void	SetReaderNode (shared_ptr< Node > n)

void	SetWriterNode (shared_ptr< Node > n)


void	SignalReaderTagChanged ()

void	SignalWriterTagChanged ()

Protected Member Functions
virtual void *	InternalGetRawEnqueuePtr (unsigned thresh, unsigned chan)

virtual void	InternalEnqueue (unsigned count)

virtual const void *	InternalGetRawDequeuePtr (unsigned thresh, unsigned chan)

virtual void	InternalDequeue (unsigned count)

virtual void	InternalReset ()

virtual unsigned	UnlockedNumChannels () const

virtual unsigned	UnlockedMaxThreshold () const

virtual unsigned	UnlockedQueueLength () const

virtual unsigned	UnlockedFreespace () const

virtual bool	UnlockedFull () const

virtual unsigned	UnlockedCount () const

virtual bool	UnlockedEmpty () const

virtual unsigned	UnlockedEnqueueChannelStride () const

virtual unsigned	UnlockedDequeueChannelStride () const

unsigned	UnlockedNumEnqueued () const

unsigned	UnlockedNumDequeued () const

virtual void	UnlockedGrow (unsigned queueLen, unsigned maxThresh)

virtual void	WaitForData ()

virtual bool	ReadBlocked ()

void	NotifyData ()

virtual void	WaitForFreespace ()

virtual bool	WriteBlocked ()

void	NotifyFreespace ()

virtual void	Wait ()

virtual void	Signal ()

virtual void	Detect ()

virtual void	InternalFlush ()

virtual void	UnlockedShutdownReader ()

virtual void	UnlockedShutdownWriter ()

void	ReadBlock ()

void	WriteBlock (unsigned qsize)

virtual void	UnlockedSignalReaderTagChanged ()

virtual void	UnlockedSignalWriterTagChanged ()

Protected Attributes
TQImpl *	queue

TQImpl *	oldqueue

bool	enqueueUseOld

bool	dequeueUseOld

const Key_t	readerkey

const Key_t	writerkey

bool	readshutdown

bool	writeshutdown

unsigned	prepad

unsigned	postpad

unsigned	readrequest

unsigned	writerequest

unsigned	enqueuethresh

unsigned	dequeuethresh

bool	indequeue

bool	inenqueue

bool	flushed

KernelBase *	kernel

bool	useD4R

Logger	logger

PthreadMutex	lock

PthreadCondition	cond

std::string	datatype

shared_ptr< Node >	reader

shared_ptr< Node >	writer

bool	readtagchanged

bool	writetagchanged

bool	incomm

Detailed Description

A version of the ThresholdQueue that provides the CPN Queue interface This queue implementation creates a memory mapped object which has as a minimum size the machine page size. So there is an effective minimum queue size. Any queue size less than the page size will be expanded to the page size.

See Also: QueueBase and ThresholdQueueBase

Definition at line 45 of file CPNThresholdQueue.h.

Constructor & Destructor Documentation

ThresholdQueue< T >::ThresholdQueue	(	KernelBase *	k,
		const SimpleQueueAttr &	attr,
		bool	usembs
	)

Definition at line 32 of file CPNThresholdQueue.cc.

References CPN::SimpleQueueAttr::GetLength(), CPN::SimpleQueueAttr::GetMaxThreshold(), CPN::SimpleQueueAttr::GetNumChannels(), and queue.

         : QueueBase(k, attr), queue(0), oldqueue(0), enqueueUseOld(false), dequeueUseOld(false)
     {
         ThresholdQueueAttr qattr(attr.GetLength(), attr.GetMaxThreshold(),
                 attr.GetNumChannels(), usembs);
         queue = new TQImpl(qattr);
     }

Here is the call graph for this function:

ThresholdQueue< T >::ThresholdQueue	(	KernelBase *	k,
		const SimpleQueueAttr &	attr,
		unsigned	length,
		bool	usembs
	)

Definition at line 40 of file CPNThresholdQueue.cc.

References CPN::SimpleQueueAttr::GetMaxThreshold(), CPN::SimpleQueueAttr::GetNumChannels(), and queue.

         : QueueBase(k, attr), queue(0), oldqueue(0), enqueueUseOld(false), dequeueUseOld(false)
     {
         ThresholdQueueAttr qattr(length, attr.GetMaxThreshold(),
                 attr.GetNumChannels(), usembs);
         queue = new TQImpl(qattr);
     }

Here is the call graph for this function:

ThresholdQueue< T >::~ThresholdQueue ( )

Definition at line 50 of file CPNThresholdQueue.cc.

References oldqueue, and queue.

                                     {
         delete queue;
         queue = 0;
         delete oldqueue;
         oldqueue = 0;
     }

Member Function Documentation

unsigned CPN::QueueBase::Count ( ) const

inherited

Returns: the number of bytes in the queue.

Definition at line 205 of file QueueBase.cc.

References CPN::QueueBase::UnlockedCount().

                                     {
         AutoLock<const QueueBase> al(*this);
         return UnlockedCount();
     }

Here is the call graph for this function:

void CPN::QueueBase::Dequeue ( unsigned count )

inherited

This function is used to remove elements from the queue. count elements will be removed from the queue when this function is called.

Parameters

count the number of bytes to remove from the queue

Definition at line 92 of file QueueBase.cc.

References CPN::QueueBase::dequeuethresh, CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::indequeue, CPN::QueueBase::InternalDequeue(), CPN::QueueBase::NotifyFreespace(), CPN::QueueBase::readerkey, and CPN::QueueBase::readshutdown.

Referenced by CPN::QueueBase::RawDequeue().

                                           {
         if (!GetRawDequeuePtr(count, 0)) { throw BrokenQueueException(readerkey); }
         AutoLock<QueueBase> al(*this);
         dequeuethresh = 0;
         indequeue = false;
         if (readshutdown) { throw BrokenQueueException(readerkey); }
         InternalDequeue(count);
         NotifyFreespace();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned CPN::QueueBase::DequeueChannelStride ( ) const

inherited

Returns: The current dequeue channel stride. This value is only guaranteed to be consistent inbetween a call to GetDequeuePtr and Dequeue.

Definition at line 240 of file QueueBase.cc.

References CPN::QueueBase::UnlockedDequeueChannelStride().

                                                    {
         AutoLock<const QueueBase> al(*this);
         return UnlockedDequeueChannelStride();
     }

Here is the call graph for this function:

void CPN::QueueBase::Detect ( )

protectedvirtualinherited

Called by the D4R algorithm when it has detected an artificial deadlock and this queue should be changed.

Implements D4R::QueueBase.

Definition at line 373 of file QueueBase.cc.

References CPN::KernelBase::CalculateGrowSize(), Logger::Debug(), CPN::QueueBase::kernel, CPN::QueueBase::logger, CPN::QueueBase::UnlockedCount(), CPN::QueueBase::UnlockedGrow(), CPN::QueueBase::UnlockedMaxThreshold(), CPN::QueueBase::UnlockedQueueLength(), and CPN::QueueBase::writerequest.

                            {
         unsigned size = kernel->CalculateGrowSize(UnlockedCount(), writerequest);
         logger.Debug("Detect: Grow(%u, %u)", size, writerequest);
         UnlockedGrow(size, writerequest);
         logger.Debug("New size: (%u, %u)", UnlockedQueueLength(), UnlockedMaxThreshold());
     }

Here is the call graph for this function:

bool CPN::QueueBase::Empty ( ) const

inherited

Returns: true if the queue is empty

Definition at line 210 of file QueueBase.cc.

References CPN::QueueBase::UnlockedEmpty().

                                 {
         AutoLock<const QueueBase> al(*this);
         return UnlockedEmpty();
     }

Here is the call graph for this function:

void CPN::QueueBase::Enqueue ( unsigned count )

inherited

This function is used to release the buffer obtained with GetRawEnqueuePtr. The count specifies the number of entries that we want to be placed in the buffer.

Note: A call to this function without an accompanying call to GetRawEnqueuePtr is undefined.

Parameters

count the number of bytes to be placed in the buffer

Invariant: count <= thresh from GetRawEnqueuePtr

Definition at line 160 of file QueueBase.cc.

References CPN::QueueBase::enqueuethresh, CPN::QueueBase::inenqueue, CPN::QueueBase::InternalEnqueue(), CPN::QueueBase::NotifyData(), CPN::QueueBase::writerkey, and CPN::QueueBase::writeshutdown.

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), and CPN::QueueBase::RawEnqueue().

                                           {
         AutoLock<QueueBase> al(*this);
         enqueuethresh = 0;
         inenqueue = false;
         if (writeshutdown) { throw BrokenQueueException(writerkey); }
         InternalEnqueue(count);
         NotifyData();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned CPN::QueueBase::EnqueueChannelStride ( ) const

inherited

Returns: The current enqueue channel stride. This value is only guaranteed to be consistent inbetween a call to GetEnqueuePtr and Enqueue.

Definition at line 235 of file QueueBase.cc.

References CPN::QueueBase::UnlockedEnqueueChannelStride().

                                                    {
         AutoLock<const QueueBase> al(*this);
         return UnlockedEnqueueChannelStride();
     }

Here is the call graph for this function:

void CPN::QueueBase::Flush ( )

inherited

Definition at line 186 of file QueueBase.cc.

References CPN::QueueBase::InternalFlush().

                           {
         AutoLock<const QueueBase> al(*this);
         InternalFlush();
     }

Here is the call graph for this function:

bool CPN::QueueBase::Flushed ( ) const

inherited

Definition at line 191 of file QueueBase.cc.

References CPN::QueueBase::flushed.

                                   {
         AutoLock<const QueueBase> al(*this);
         return flushed;
     }

unsigned CPN::QueueBase::Freespace ( ) const

inherited

Returns: the number of bytes we can add to the queue without blocking.

Definition at line 215 of file QueueBase.cc.

References CPN::QueueBase::UnlockedFreespace().

                                         {
         AutoLock<const QueueBase> al(*this);
         return UnlockedFreespace();
     }

Here is the call graph for this function:

bool CPN::QueueBase::Full ( ) const

inherited

Returns: true if the queue is full, false otherwise

Definition at line 220 of file QueueBase.cc.

References CPN::QueueBase::UnlockedFull().

                                {
         AutoLock<const QueueBase> al(*this);
         return UnlockedFull();
     }

Here is the call graph for this function:

const std::string& CPN::QueueBase::GetDatatype ( ) const

inlineinherited

Returns: the datatype name associated with this queue

Definition at line 213 of file QueueBase.h.

213 { return datatype; }

CPN::QueueBase::datatype

std::string datatype

Definition: QueueBase.h:291

const void * CPN::QueueBase::GetRawDequeuePtr	(	unsigned	thresh,
		unsigned	chan
	)

inherited

Get a pointer to a buffer containing elements.

Note: access to the memory locations pointed to by the returned pointer after Dequeue has been called is undefined.

Parameters

thresh	the number of bytes to get
chan	the channel to use

Returns: A void* to a block of memory containing thresh bytes or 0 if there are not thresh bytes available.

Definition at line 63 of file QueueBase.cc.

References ASSERT, CPN::KernelBase::CheckTerminated(), CPN::QueueBase::dequeuethresh, CPN::QueueBase::flushed, CPN::KernelBase::GrowQueueMaxThreshold(), CPN::QueueBase::indequeue, CPN::QueueBase::InternalGetRawDequeuePtr(), CPN::QueueBase::kernel, CPN::QueueBase::readerkey, CPN::QueueBase::readrequest, CPN::QueueBase::readshutdown, CPN::QueueBase::Signal(), CPN::QueueBase::UnlockedGrow(), CPN::QueueBase::UnlockedMaxThreshold(), CPN::QueueBase::WaitForData(), CPN::QueueBase::WriteBlocked(), CPN::QueueBase::writerequest, and CPN::QueueBase::writeshutdown.

Referenced by CPN::QueueBase::Dequeue(), and CPN::QueueBase::RawDequeue().

                                                                           {
         kernel->CheckTerminated();
         AutoLock<QueueBase> al(*this);
         if (indequeue) { ASSERT(dequeuethresh >= thresh); }
         else { dequeuethresh = thresh; }
         while (true) {
             const void *ptr = InternalGetRawDequeuePtr(thresh, chan);
             if (ptr ||
                     (writeshutdown && !(thresh > UnlockedMaxThreshold() && kernel->GrowQueueMaxThreshold()))
                     || flushed) {
                 if (ptr) { indequeue = true; }
                 return ptr;
             }
             if (readshutdown) { throw BrokenQueueException(readerkey); }
             if (thresh > UnlockedMaxThreshold() && kernel->GrowQueueMaxThreshold()) {
                 //printf("Grow(%u, %u)\n", 2*thresh, thresh);
                 UnlockedGrow(2*thresh, thresh);
                 Signal();
             } else if (WriteBlocked() && kernel->GrowQueueMaxThreshold()) {
                 UnlockedGrow(writerequest + thresh, thresh);
                 Signal();
             } else {
                 readrequest = thresh;
                 WaitForData();
                 readrequest = 0;
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void * CPN::QueueBase::GetRawEnqueuePtr	(	unsigned	thresh,
		unsigned	chan
	)

inherited

Return a pointer to a buffer of memory that contains thresh entries that we can write into.

Note: A call to this function without an accompanying call to Enqueue is undefined.; An access to the memory locations defined by the return value is undefined after a call to Enqueue.

Parameters

thresh	the number bytes we need in the returned buffer.
chan	the channel to use

Returns: void* to the memory buffer, 0 if not enough space available

Definition at line 121 of file QueueBase.cc.

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), and CPN::QueueBase::RawEnqueue().

                                                                     {
         kernel->CheckTerminated();
         AutoLock<QueueBase> al(*this);
         // Only the enqueuer may call flush and reset will clear all state as if we
         // had not done anything yet, so block here
         while (flushed) {
             if (readshutdown || writeshutdown) { throw BrokenQueueException(writerkey); }
             if (useD4R) {
                 WriteBlock(-1);
             } else {
                 Wait();
             }
         }
         if (inenqueue) { ASSERT(enqueuethresh >= thresh); }
         else { enqueuethresh = thresh; }
         bool grown = false;
         while (true) {
             void *ptr = InternalGetRawEnqueuePtr(thresh, chan);
             if (ptr) {
                 inenqueue = true;
                 return ptr;
             }
             if (readshutdown || writeshutdown) { throw BrokenQueueException(writerkey); }
             if (thresh > UnlockedMaxThreshold() && kernel->GrowQueueMaxThreshold()) {
                 //printf("Grow(%u, %u)\n", 2*thresh, thresh);
                 UnlockedGrow(2*thresh, thresh);
                 Signal();
             } else if (!grown && ReadBlocked() && kernel->GrowQueueMaxThreshold()) {
                 UnlockedGrow(readrequest + thresh, thresh);
                 Signal();
                 grown = true;
             } else {
                 writerequest = thresh;
                 WaitForFreespace();
                 writerequest = 0;
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

Key_t CPN::QueueBase::GetReaderKey ( ) const

inlineinherited

Returns: the reader key associated with this queue

Definition at line 211 of file QueueBase.h.

211 { return readerkey; }

CPN::QueueBase::readerkey

const Key_t readerkey

Definition: QueueBase.h:273

Key_t CPN::QueueBase::GetWriterKey ( ) const

inlineinherited

Returns: the writer key associated with this queue

Definition at line 209 of file QueueBase.h.

209 { return writerkey; }

CPN::QueueBase::writerkey

const Key_t writerkey

Definition: QueueBase.h:274

void CPN::QueueBase::Grow	(	unsigned	queueLen,
		unsigned	maxThresh
	)

inherited

Ensure that this queue has at least queueLen bytes of space and can support at least maxThresh as the maxThreshold the new queue length will be max(queueLen, QueueLength()) and the new max threshold will be max(maxThresh, MaxThreshold())

Note: that the caller must guarantee that both an enqueue and dequeue are not both outstanding. Otherwise this will fail.

Parameters

queueLen	the next queue length
maxThresh	the next max threshold

Definition at line 245 of file QueueBase.cc.

References CPN::QueueBase::UnlockedGrow().

                                                               {
         AutoLock<QueueBase> al(*this);
         UnlockedGrow(queueLen, maxThresh);
     }

Here is the call graph for this function:

void ThresholdQueue< T >::InternalDequeue ( unsigned count )

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 140 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::Dequeue(), dequeueUseOld, oldqueue, and queue.

Referenced by CPN::RemoteQueue::InternalDequeue(), and CPN::RemoteQueue::SendEnqueuePacket().

                                                        {
         if (dequeueUseOld) {
             dequeueUseOld = false;
             delete oldqueue;
             oldqueue = 0;
         }
         queue->Dequeue(count);
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void ThresholdQueue< T >::InternalEnqueue ( unsigned count )

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 69 of file CPNThresholdQueue.cc.

References ASSERT, ThresholdQueueBase::Count(), ThresholdQueueBase::Dequeue(), ThresholdQueueBase::Enqueue(), enqueueUseOld, ThresholdQueueBase::GetRawDequeuePtr(), ThresholdQueueBase::GetRawEnqueuePtr(), ThresholdQueueBase::MaxThreshold(), ThresholdQueueBase::NumChannels(), oldqueue, and queue.

Referenced by CPN::RemoteQueue::EnqueuePacket(), and CPN::RemoteQueue::InternalEnqueue().

                                                        {
         if (enqueueUseOld) {
             oldqueue->Dequeue(oldqueue->Count());
             oldqueue->Enqueue(count);

             unsigned count;
             while ( (count = oldqueue->Count()) != 0 ) {
                 if (count > oldqueue->MaxThreshold()) {
                     count = oldqueue->MaxThreshold();
                 }
                 for (unsigned chan = 0; chan < queue->NumChannels(); chan++) {
                     const void* src = oldqueue->GetRawDequeuePtr(count, chan);
                     void* dst = queue->GetRawEnqueuePtr(count, chan);
                     ASSERT(src && dst);
                     memcpy(dst,src,count);
                 }

                 queue->Enqueue(count);
                 oldqueue->Dequeue(count);
             }

             enqueueUseOld = false;
             delete oldqueue;
             oldqueue = 0;
         } else {
             queue->Enqueue(count);
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::InternalFlush ( )

protectedvirtualinherited

Reimplemented in CPN::RemoteQueue.

Definition at line 265 of file QueueBase.cc.

References PthreadCondition::Broadcast(), CPN::QueueBase::cond, CPN::QueueBase::flushed, CPN::QueueBase::InternalEnqueue(), CPN::QueueBase::InternalGetRawEnqueuePtr(), CPN::QueueBase::postpad, CPN::QueueBase::readshutdown, CPN::QueueBase::UnlockedEnqueueChannelStride(), CPN::QueueBase::UnlockedNumChannels(), CPN::QueueBase::WaitForFreespace(), CPN::QueueBase::writerequest, CPN::QueueBase::writerkey, and CPN::QueueBase::writeshutdown.

Referenced by CPN::QueueBase::Flush(), and CPN::RemoteQueue::InternalFlush().

                                   {
         if (readshutdown || writeshutdown) { throw BrokenQueueException(writerkey); }
         if (postpad > 0) {
             while (true) {
                 void *ptr = InternalGetRawEnqueuePtr(postpad, 0);
                 if (ptr) {
                     unsigned num_chans = UnlockedNumChannels();
                     unsigned chanstride = UnlockedEnqueueChannelStride();
                     for (unsigned chan = 0; chan < num_chans; ++chan) {
                         memset((char*)ptr + chanstride*chan, 0, postpad);
                     }
                     InternalEnqueue(postpad);
                 } else {
                     if (readshutdown || writeshutdown) { throw BrokenQueueException(writerkey); }
                     writerequest = postpad;
                     WaitForFreespace();
                     writerequest = 0;
                 }
             }
         }
         flushed = true;
         cond.Broadcast();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

const void * ThresholdQueue< T >::InternalGetRawDequeuePtr	(	unsigned	thresh,
		unsigned	chan
	)

protectedvirtual

Implements CPN::QueueBase.

Definition at line 126 of file CPNThresholdQueue.cc.

References ASSERT, dequeueUseOld, ThresholdQueueBase::GetRawDequeuePtr(), CPN::QueueBase::indequeue, oldqueue, and queue.

Referenced by CPN::RemoteQueue::SendEnqueuePacket().

                                                                                        {
         const void *ret = 0;
         if (dequeueUseOld) {
             // The ONLY reason this code path should be followed is if the node made a getdequeueptr
             // then called getdequeueptr again before dequeue when a grow happens inbetween
             ASSERT(indequeue);
             ret = oldqueue->GetRawDequeuePtr(thresh, chan);
             ASSERT(ret);
         } else {
             ret = queue->GetRawDequeuePtr(thresh, chan);
         }
         return ret;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void * ThresholdQueue< T >::InternalGetRawEnqueuePtr	(	unsigned	thresh,
		unsigned	chan
	)

protectedvirtual

Implements CPN::QueueBase.

Definition at line 57 of file CPNThresholdQueue.cc.

References ASSERT, enqueueUseOld, ThresholdQueueBase::GetRawEnqueuePtr(), CPN::QueueBase::inenqueue, oldqueue, and queue.

Referenced by CPN::RemoteQueue::EnqueuePacket().

                                                                                  {
         void *ret = 0;
         if (enqueueUseOld) {
             ASSERT(inenqueue);
             ret = oldqueue->GetRawEnqueuePtr(thresh, chan);
             ASSERT(ret);
         } else {
             ret = queue->GetRawEnqueuePtr(thresh, chan);
         }
         return ret;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void ThresholdQueue< T >::InternalReset ( )

protectedvirtual

Reimplemented from CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 173 of file CPNThresholdQueue.cc.

References dequeueUseOld, enqueueUseOld, CPN::QueueBase::InternalReset(), oldqueue, queue, and ThresholdQueueBase::Reset().

Referenced by CPN::RemoteQueue::InternalReset().

                                        {
         if (dequeueUseOld || enqueueUseOld) {
             dequeueUseOld = false;
             enqueueUseOld = false;
             delete oldqueue;
             oldqueue = 0;
         }
         queue->Reset();
         QueueBase::InternalReset();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool CPN::QueueBase::IsReaderShutdown ( )

inherited

Definition at line 390 of file QueueBase.cc.

References CPN::QueueBase::readshutdown.

                                      {
         AutoLock<QueueBase> al(*this);
         return readshutdown;
     }

bool CPN::QueueBase::IsWriterShutdown ( )

inherited

Definition at line 395 of file QueueBase.cc.

References CPN::QueueBase::writeshutdown.

                                      {
         AutoLock<QueueBase> al(*this);
         return writeshutdown;
     }

void CPN::QueueBase::Lock ( ) const

inlinevirtualinherited

These functions are to access the lock for the queue.

Implements D4R::QueueBase.

Definition at line 221 of file QueueBase.h.

References lock, and PthreadMutex::Lock().

221 { lock.Lock(); }

PthreadMutex::Lock

PthreadMutex & Lock(void)

Definition: PthreadMutex.h:49

CPN::QueueBase::lock

PthreadMutex lock

Definition: QueueBase.h:289

Here is the call graph for this function:

void CPN::QueueBase::LogState ( )

virtualinherited

For debugging ONLY!! Otherwise non deterministic output.

Reimplemented in CPN::RemoteQueue.

Definition at line 400 of file QueueBase.cc.

References CPN::QueueBase::dequeuethresh, CPN::QueueBase::enqueuethresh, Logger::Error(), CPN::QueueBase::flushed, CPN::QueueBase::indequeue, CPN::QueueBase::inenqueue, CPN::QueueBase::logger, CPN::QueueBase::readerkey, CPN::QueueBase::readrequest, CPN::QueueBase::readshutdown, CPN::QueueBase::UnlockedCount(), CPN::QueueBase::UnlockedFreespace(), CPN::QueueBase::UnlockedMaxThreshold(), CPN::QueueBase::UnlockedNumDequeued(), CPN::QueueBase::UnlockedNumEnqueued(), CPN::QueueBase::UnlockedQueueLength(), CPN::QueueBase::writerequest, CPN::QueueBase::writerkey, and CPN::QueueBase::writeshutdown.

Referenced by CPN::RemoteQueue::LogState().

                              {
         logger.Error("Printing state (w:%llu r:%llu)", readerkey, writerkey);
         logger.Error("size: %u, maxthresh: %u count: %u free: %u, flushed: %d",
                 UnlockedQueueLength(), UnlockedMaxThreshold(), UnlockedCount(), UnlockedFreespace(),
                 (int)flushed);
         logger.Error("readrequest: %u, writerequest: %u numenqueued: %u, numdequeued: %u",
                 readrequest, writerequest, UnlockedNumEnqueued(), UnlockedNumDequeued());
         if (indequeue) {
             logger.Error("Indequeue (thresh: %u)", dequeuethresh);
         }
         if (inenqueue) {
             logger.Error("Inenqueue (thresh: %u)", enqueuethresh);
         }
         if (readshutdown) {
             logger.Error("Reader shutdown");
         }
         if (writeshutdown) {
             logger.Error("Writer shutdown");
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned CPN::QueueBase::MaxThreshold ( ) const

inherited

Returns: the maximum threshold this queue supports in bytes

Definition at line 225 of file QueueBase.cc.

References CPN::QueueBase::UnlockedMaxThreshold().

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), and UnlockedGrow().

                                            {
         AutoLock<const QueueBase> al(*this);
         return UnlockedMaxThreshold();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::NotifyData ( )

protectedinherited

Definition at line 341 of file QueueBase.cc.

References PthreadCondition::Broadcast(), CPN::QueueBase::cond, CPN::QueueBase::readrequest, and CPN::QueueBase::UnlockedCount().

Referenced by CPN::QueueBase::Enqueue(), and CPN::RemoteQueue::EnqueuePacket().

                                {
         if (UnlockedCount() >= readrequest) {
             cond.Broadcast();
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::NotifyFreespace ( )

protectedinherited

Definition at line 362 of file QueueBase.cc.

References PthreadCondition::Broadcast(), CPN::QueueBase::cond, CPN::QueueBase::UnlockedFreespace(), and CPN::QueueBase::writerequest.

Referenced by CPN::QueueBase::Dequeue(), and CPN::RemoteQueue::SendEnqueuePacket().

                                     {
         if (UnlockedFreespace() >= writerequest) {
             cond.Broadcast();
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::NotifyTerminate ( )

inherited

Used to tell any waiting threads that the network is terminating.

Definition at line 368 of file QueueBase.cc.

References PthreadCondition::Broadcast(), and CPN::QueueBase::cond.

                                     {
         AutoLock<QueueBase> al(*this);
         cond.Broadcast();
     }

Here is the call graph for this function:

unsigned CPN::QueueBase::NumChannels ( ) const

inherited

Returns: the number of channels supported by this queue.

Definition at line 200 of file QueueBase.cc.

References CPN::QueueBase::UnlockedNumChannels().

                                           {
         AutoLock<const QueueBase> al(*this);
         return UnlockedNumChannels();
     }

Here is the call graph for this function:

unsigned CPN::QueueBase::NumDequeued ( ) const

inherited

Definition at line 321 of file QueueBase.cc.

References CPN::QueueBase::UnlockedNumDequeued().

                                           {
         AutoLock<const QueueBase> al(*this);
         return UnlockedNumDequeued();
     }

Here is the call graph for this function:

unsigned CPN::QueueBase::NumEnqueued ( ) const

inherited

Definition at line 316 of file QueueBase.cc.

References CPN::QueueBase::UnlockedNumEnqueued().

                                           {
         AutoLock<const QueueBase> al(*this);
         return UnlockedNumEnqueued();
     }

Here is the call graph for this function:

unsigned CPN::QueueBase::QueueLength ( ) const

inherited

Returns: the maximum number of bytes that can be put in this queue.

Definition at line 230 of file QueueBase.cc.

References CPN::QueueBase::UnlockedQueueLength().

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), CPN::RemoteQueue::GrowPacket(), UnlockedGrow(), and CPN::RemoteQueue::UnlockedGrow().

                                           {
         AutoLock<const QueueBase> al(*this);
         return UnlockedQueueLength();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool CPN::QueueBase::RawDequeue	(	void *	data,
		unsigned	count,
		unsigned	numChans,
		unsigned	chanStride
	)

inherited

Dequeue data from the queue directly into the memory pointed to by data. This function shall be equivalent to a call to GetRawDequeuePtr then a memcpy and then a call to Dequeue.

Parameters

data	poiner to memory to dequeue to
count	the number of bytes to copy into data
numChans	the number of channels to write to
chanStride	the distance in bytes between the beginning of the channels in data.

Returns: true on success false on failure

Definition at line 102 of file QueueBase.cc.

References ASSERT, CPN::QueueBase::Dequeue(), and CPN::QueueBase::GetRawDequeuePtr().

Referenced by CPN::QueueBase::RawDequeue().

                                                                                                  {
         const void *src = GetRawDequeuePtr(count, 0);
         char *dest = (char*)data;
         if (!src) { return false; }
         memcpy(dest, src, count);
         for (unsigned chan = 1; chan < numChans; ++chan) {
             src = GetRawDequeuePtr(count, chan);
             ASSERT(src);
             dest += chanStride;
             memcpy(dest, src, count);
         }
         Dequeue(count);
         return true;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool CPN::QueueBase::RawDequeue	(	void *	data,
		unsigned	count
	)

inherited

A version of RawDequeue to use when there is only 1 channel.

Parameters

data	the data to enqueue
count	the number of bytes to enqueue

Returns: true on success false if we have reached the end of the queue

Definition at line 117 of file QueueBase.cc.

References CPN::QueueBase::RawDequeue().

                                                          {
         return RawDequeue(data, count, 1, 0);
     }

Here is the call graph for this function:

void CPN::QueueBase::RawEnqueue	(	const void *	data,
		unsigned	count,
		unsigned	numChans,
		unsigned	chanStride
	)

inherited

This function shall be equivalent to a call to GetRqwEnqueuePtr and a memcpy and then a call to Enqueue

The underlying implementatin may implement ether the GetRawEnqueuePtr and Enqueue or RawEnqueue and then implement the other in terms of the one implemented.

Parameters

data	pointer to the memory to enqueue
count	the number of bytes to enqueue
numChans	the number of channels to write to
chanStride	the distance in bytes between the beginning of the channels in data.

Definition at line 169 of file QueueBase.cc.

References CPN::QueueBase::Enqueue(), and CPN::QueueBase::GetRawEnqueuePtr().

Referenced by CPN::QueueBase::RawEnqueue().

                                                                                                        {
         void *dest = GetRawEnqueuePtr(count, 0);
         const char *src = (char*)data;
         memcpy(dest, src, count);
         for (unsigned chan = 1; chan < numChans; ++chan) {
             dest = GetRawEnqueuePtr(count, chan);
             src += chanStride;
             memcpy(dest, src, count);
         }
         Enqueue(count);
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::RawEnqueue	(	const void *	data,
		unsigned	count
	)

inherited

A version of RawEnqueue to use when there is only 1 channel.

Parameters

data	pointer to the memory to enqueue
count	the number of bytes to enqueue

Definition at line 196 of file QueueBase.cc.

References CPN::QueueBase::RawEnqueue().

                                                                {
         return RawEnqueue(data, count, 1, 0);
     }

Here is the call graph for this function:

void D4R::QueueBase::ReadBlock ( )

protectedinherited

reader ===> writer ReadBlock requires that you already hold the lock and if it is reentrant then a single unlock will release the lock.

Exceptions

D4R::DeadlockException

Definition at line 71 of file D4RQueue.cc.

References D4R::QueueBase::incomm, D4R::QueueBase::ReadBlocked(), D4R::QueueBase::reader, D4R::QueueBase::Signal(), D4R::QueueBase::Wait(), D4R::QueueBase::writer, and D4R::QueueBase::writetagchanged.

Referenced by CPN::QueueBase::WaitForData().

                               {
         if (!writer) {
             while (ReadBlocked() && !writer) {
                 Wait();
             }
         }
         if (!ReadBlocked()) { return; }
         writetagchanged = false;
         try {
             while (incomm) { Wait(); }
             ScopeSetter<bool> ss(incomm, true);
             AutoUnlock<QueueBase> au(*this);
             reader->Block(writer->GetPublicTag(), -1);
         } catch (...) { Signal(); throw; }
         Signal();
         while (ReadBlocked()) {
             if (writetagchanged) {
                 writetagchanged = false;
                 bool detect;
                 try {
                     while (incomm) { Wait(); }
                     ScopeSetter<bool> ss(incomm, true);
                     AutoUnlock<QueueBase> au(*this);
                     detect = reader->Transmit(writer->GetPublicTag());
                 } catch (...) { Signal(); throw; }
                 Signal();
                 if (detect) {
                     throw DeadlockException("True deadlock detected");
                 }
             } else {
                 Wait();
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool CPN::QueueBase::ReadBlocked ( )

protectedvirtualinherited

Returns: true if we are blocked

Implements D4R::QueueBase.

Definition at line 336 of file QueueBase.cc.

References CPN::KernelBase::CheckTerminated(), CPN::QueueBase::flushed, CPN::QueueBase::kernel, CPN::QueueBase::readrequest, CPN::QueueBase::readshutdown, CPN::QueueBase::UnlockedCount(), and CPN::QueueBase::writeshutdown.

Referenced by CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::WaitForData(), and CPN::QueueBase::WaitForData().

                                 {
         kernel->CheckTerminated();
         return UnlockedCount() < readrequest && !(readshutdown || writeshutdown) && !flushed;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned CPN::QueueBase::ReadRequest ( )

inherited

For unit tests.

Definition at line 380 of file QueueBase.cc.

References CPN::QueueBase::readrequest.

                                     {
         AutoLock<QueueBase> al(*this);
         return readrequest;
     }

void CPN::QueueBase::Reset ( )

inherited

Definition at line 181 of file QueueBase.cc.

References CPN::QueueBase::InternalReset().

                           {
         AutoLock<const QueueBase> al(*this);
         InternalReset();
     }

Here is the call graph for this function:

void D4R::QueueBase::SetReaderNode ( shared_ptr< Node > n )

inherited

Set the node which is reading from this queue

Parameters

n the node

Definition at line 59 of file D4RQueue.cc.

References D4R::QueueBase::reader, and D4R::QueueBase::Signal().

Referenced by CPN::RemoteQueue::RemoteQueue().

                                                     {
         AutoLock<QueueBase> al(*this);
         reader = n;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void D4R::QueueBase::SetWriterNode ( shared_ptr< Node > n )

inherited

Set the node which is writing to this queue.

Parameters

n the node

Definition at line 65 of file D4RQueue.cc.

References D4R::QueueBase::Signal(), and D4R::QueueBase::writer.

Referenced by CPN::RemoteQueue::RemoteQueue().

                                                     {
         AutoLock<QueueBase> al(*this);
         writer = n;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::ShutdownReader ( )

inherited

Called by the QueueReader when no more data will be read.

Definition at line 250 of file QueueBase.cc.

References CPN::QueueBase::UnlockedShutdownReader().

Referenced by CPN::RemoteQueue::FileThreadEntryPoint().

                                    {
         AutoLock<QueueBase> al(*this);
         UnlockedShutdownReader();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::ShutdownWriter ( )

inherited

Called by the QueueWriter when no more data will be written.

Definition at line 260 of file QueueBase.cc.

References CPN::QueueBase::UnlockedShutdownWriter().

Referenced by CPN::RemoteQueue::FileThreadEntryPoint().

                                    {
         AutoLock<QueueBase> al(*this);
         UnlockedShutdownWriter();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void CPN::QueueBase::Signal ( )

inlineprotectedvirtualinherited

Signal that Wait should return

Implements D4R::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 247 of file QueueBase.h.

Referenced by CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::Signal(), CPN::QueueBase::UnlockedShutdownReader(), and CPN::QueueBase::UnlockedShutdownWriter().

247 { cond.Broadcast(); }

PthreadCondition::Broadcast

PthreadCondition & Broadcast(void)

Definition: PthreadCondition.cc:76

CPN::QueueBase::cond

PthreadCondition cond

Definition: QueueBase.h:290

Here is the caller graph for this function:

void D4R::QueueBase::SignalReaderTagChanged ( )

inherited

These functions are called by the D4R::Node when thier tag changes.

Definition at line 139 of file D4RQueue.cc.

References D4R::QueueBase::UnlockedSignalReaderTagChanged().

                                            {
         AutoLock<QueueBase> al(*this);
         UnlockedSignalReaderTagChanged();
     }

Here is the call graph for this function:

void D4R::QueueBase::SignalWriterTagChanged ( )

inherited

Definition at line 150 of file D4RQueue.cc.

References D4R::QueueBase::UnlockedSignalWriterTagChanged().

                                            {
         AutoLock<QueueBase> al(*this);
         UnlockedSignalWriterTagChanged();
     }

Here is the call graph for this function:

void CPN::QueueBase::Unlock ( void ) const

inlinevirtualinherited

Implements D4R::QueueBase.

Definition at line 222 of file QueueBase.h.

References lock, and PthreadMutex::Unlock().

222 { lock.Unlock(); }

PthreadMutex::Unlock

PthreadMutex & Unlock(void)

Definition: PthreadMutex.h:50

CPN::QueueBase::lock

PthreadMutex lock

Definition: QueueBase.h:289

Here is the call graph for this function:

unsigned ThresholdQueue< T >::UnlockedCount ( ) const

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 149 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::Count(), and queue.

                                                  {
         return queue->Count();
     }

Here is the call graph for this function:

unsigned ThresholdQueue< T >::UnlockedDequeueChannelStride ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 110 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::ChannelStride(), dequeueUseOld, oldqueue, and queue.

                                                                 {
         if (dequeueUseOld) {
             return oldqueue->ChannelStride();
         } else {
             return queue->ChannelStride();
         }
     }

Here is the call graph for this function:

bool ThresholdQueue< T >::UnlockedEmpty ( ) const

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 153 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::Empty(), and queue.

                                              {
         return queue->Empty();
     }

Here is the call graph for this function:

unsigned ThresholdQueue< T >::UnlockedEnqueueChannelStride ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 102 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::ChannelStride(), enqueueUseOld, oldqueue, and queue.

                                                                 {
         if (enqueueUseOld) {
             return oldqueue->ChannelStride();
         } else {
             return queue->ChannelStride();
         }
     }

Here is the call graph for this function:

unsigned ThresholdQueue< T >::UnlockedFreespace ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 118 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::Freespace(), and queue.

Referenced by CPN::RemoteQueue::GetState().

                                                      {
         return queue->Freespace();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool ThresholdQueue< T >::UnlockedFull ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 122 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::Full(), and queue.

                                             {
         return queue->Full();
     }

Here is the call graph for this function:

void ThresholdQueue< T >::UnlockedGrow	(	unsigned	queueLen,
		unsigned	maxThresh
	)

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 184 of file CPNThresholdQueue.cc.

References ASSERT, dequeueUseOld, enqueueUseOld, CPN::ThresholdQueue::TQImpl::Grow(), CPN::QueueBase::indequeue, CPN::QueueBase::inenqueue, CPN::QueueBase::MaxThreshold(), oldqueue, queue, and CPN::QueueBase::QueueLength().

Referenced by CPN::RemoteQueue::EnqueuePacket(), CPN::RemoteQueue::GrowPacket(), and CPN::RemoteQueue::UnlockedGrow().

                                                                            {
         if (queueLen <= queue->QueueLength() && maxThresh <= queue->MaxThreshold()) return;
         ASSERT(!(inenqueue && indequeue), "Unhandled grow case of having an outstanding dequeue and enqueue");
         if (oldqueue) {
             // If the old queue is still around we have to still be in the same state
             ASSERT(enqueueUseOld == inenqueue);
             ASSERT(dequeueUseOld == indequeue);
             queue->Grow(queueLen, maxThresh, false);
         } else if (!inenqueue && !indequeue) {
             queue->Grow(queueLen, maxThresh, false);
         } else {
             enqueueUseOld = inenqueue;
             dequeueUseOld = indequeue;
             // this should make a duplicate
             oldqueue = queue->Grow(queueLen, maxThresh, true);
             if (!oldqueue) {
                 enqueueUseOld = false;
                 enqueueUseOld = false;
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned ThresholdQueue< T >::UnlockedMaxThreshold ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 157 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::MaxThreshold(), and queue.

Referenced by CPN::RemoteQueue::GetState(), and CPN::RemoteQueue::UnlockedGrow().

                                                         {
         return queue->MaxThreshold();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned ThresholdQueue< T >::UnlockedNumChannels ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 98 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::NumChannels(), and queue.

                                                        {
         return queue->NumChannels();
     }

Here is the call graph for this function:

unsigned ThresholdQueue< T >::UnlockedNumDequeued ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 169 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::ElementsDequeued(), and queue.

Referenced by CPN::RemoteQueue::GetState().

                                                        {
         return queue->ElementsDequeued();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned ThresholdQueue< T >::UnlockedNumEnqueued ( ) const

protectedvirtual

Implements CPN::QueueBase.

Definition at line 165 of file CPNThresholdQueue.cc.

References ThresholdQueueBase::ElementsEnqueued(), and queue.

Referenced by CPN::RemoteQueue::GetState().

                                                        {
         return queue->ElementsEnqueued();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned ThresholdQueue< T >::UnlockedQueueLength ( ) const

protectedvirtual

Implements CPN::QueueBase.

Reimplemented in CPN::RemoteQueue.

Definition at line 161 of file CPNThresholdQueue.cc.

References queue, and ThresholdQueueBase::QueueLength().

                                                        {
         return queue->QueueLength();
     }

Here is the call graph for this function:

void CPN::QueueBase::UnlockedShutdownReader ( )

protectedvirtualinherited

Definition at line 255 of file QueueBase.cc.

References CPN::QueueBase::readshutdown, and CPN::QueueBase::Signal().

Referenced by CPN::RemoteQueue::EndOfReadPacket(), CPN::RemoteQueue::InternalCheckStatus(), and CPN::QueueBase::ShutdownReader().

                                            {
         readshutdown = true;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::UnlockedShutdownWriter ( )

protectedvirtualinherited

Definition at line 311 of file QueueBase.cc.

References CPN::QueueBase::Signal(), and CPN::QueueBase::writeshutdown.

Referenced by CPN::RemoteQueue::EndOfWritePacket(), CPN::RemoteQueue::InternalCheckStatus(), and CPN::QueueBase::ShutdownWriter().

                                            {
         writeshutdown = true;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void D4R::QueueBase::UnlockedSignalReaderTagChanged ( )

protectedvirtualinherited

Reimplemented in CPN::RemoteQueue.

Definition at line 144 of file D4RQueue.cc.

References DEBUG, D4R::QueueBase::reader, D4R::QueueBase::readtagchanged, D4R::QueueBase::Signal(), and D4R::QueueBase::writer.

Referenced by CPN::RemoteQueue::D4RTagPacket(), D4R::QueueBase::SignalReaderTagChanged(), and CPN::RemoteQueue::UnlockedSignalReaderTagChanged().

                                                    {
         DEBUG("%s: (%llu -> %llu)\n", __PRETTY_FUNCTION__, (writer ? writer->GetPrivateTag().Key() : 0), (reader ? reader->GetPrivateTag().Key() : 0));
         readtagchanged = true;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void D4R::QueueBase::UnlockedSignalWriterTagChanged ( )

protectedvirtualinherited

Reimplemented in CPN::RemoteQueue.

Definition at line 155 of file D4RQueue.cc.

References DEBUG, D4R::QueueBase::reader, D4R::QueueBase::Signal(), D4R::QueueBase::writer, and D4R::QueueBase::writetagchanged.

Referenced by CPN::RemoteQueue::D4RTagPacket(), D4R::QueueBase::SignalWriterTagChanged(), and CPN::RemoteQueue::UnlockedSignalWriterTagChanged().

                                                    {
         DEBUG("%s: (%llu -> %llu)\n", __PRETTY_FUNCTION__, (writer ? writer->GetPrivateTag().Key() : 0), (reader ? reader->GetPrivateTag().Key() : 0));
         writetagchanged = true;
         Signal();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void CPN::QueueBase::Wait ( )

inlineprotectedvirtualinherited

Wait untill Signal is called. Must be holding the lock to call.

Implements D4R::QueueBase.

Definition at line 246 of file QueueBase.h.

References lock.

Referenced by CPN::RemoteQueue::ActionThreadEntryPoint(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::WaitForData(), and CPN::RemoteQueue::WaitForFreespace().

246 { cond.Wait(lock); }

PthreadCondition::Wait

PthreadCondition & Wait(PthreadMutex &mutex)

Definition: PthreadCondition.cc:84

CPN::QueueBase::cond

PthreadCondition cond

Definition: QueueBase.h:290

CPN::QueueBase::lock

PthreadMutex lock

Definition: QueueBase.h:289

Here is the caller graph for this function:

void CPN::QueueBase::WaitForData ( )

protectedvirtualinherited

Reimplemented in CPN::RemoteQueue.

Definition at line 326 of file QueueBase.cc.

References CPN::QueueBase::cond, CPN::QueueBase::lock, D4R::QueueBase::ReadBlock(), CPN::QueueBase::ReadBlocked(), CPN::QueueBase::useD4R, and PthreadCondition::Wait().

Referenced by CPN::QueueBase::GetRawDequeuePtr(), and CPN::RemoteQueue::WaitForData().

                                 {
         if (useD4R) {
             ReadBlock();
         } else {
             while (ReadBlocked()) {
                 cond.Wait(lock);
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::QueueBase::WaitForFreespace ( )

protectedvirtualinherited

Reimplemented in CPN::RemoteQueue.

Definition at line 347 of file QueueBase.cc.

References CPN::QueueBase::cond, CPN::QueueBase::lock, CPN::QueueBase::UnlockedQueueLength(), CPN::QueueBase::useD4R, PthreadCondition::Wait(), D4R::QueueBase::WriteBlock(), and CPN::QueueBase::WriteBlocked().

Referenced by CPN::QueueBase::GetRawEnqueuePtr(), CPN::QueueBase::InternalFlush(), and CPN::RemoteQueue::WaitForFreespace().

                                      {
         if (useD4R) {
             WriteBlock(UnlockedQueueLength());
         } else {
             while (WriteBlocked()) {
                 cond.Wait(lock);
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void D4R::QueueBase::WriteBlock ( unsigned qsize )

protectedinherited

writer ===> reader WriteBlock requires that you already hold the lock and if it is reentrant then a single unlock will release the lock.

Definition at line 106 of file D4RQueue.cc.

References D4R::QueueBase::Detect(), D4R::QueueBase::incomm, D4R::QueueBase::reader, D4R::QueueBase::readtagchanged, D4R::QueueBase::Signal(), D4R::QueueBase::Wait(), D4R::QueueBase::WriteBlocked(), and D4R::QueueBase::writer.

Referenced by CPN::QueueBase::GetRawEnqueuePtr(), and CPN::QueueBase::WaitForFreespace().

                                              {
         if (!reader) {
             while (WriteBlocked() && !reader) {
                 Wait();
             }
         }
         if (!WriteBlocked()) { return; }
         readtagchanged = false;
         try {
             while (incomm) { Wait(); }
             ScopeSetter<bool> ss(incomm, true);
             AutoUnlock<QueueBase> au(*this);
             writer->Block(reader->GetPublicTag(), qsize);
         } catch (...) { Signal(); throw; }
         Signal();
         while (WriteBlocked()) {
             if (readtagchanged) {
                 readtagchanged = false;
                 bool detect;
                 try {
                     while (incomm) { Wait(); }
                     ScopeSetter<bool> ss(incomm, true);
                     AutoUnlock<QueueBase> au(*this);
                     detect = writer->Transmit(reader->GetPublicTag());
                 } catch (...) { Signal(); throw; }
                 Signal();
                 if (detect) { Detect(); }
             } else {
                 Wait();
             }
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

bool CPN::QueueBase::WriteBlocked ( )

protectedvirtualinherited

Returns: true if we are blocked.

Implements D4R::QueueBase.

Definition at line 357 of file QueueBase.cc.

References CPN::KernelBase::CheckTerminated(), CPN::QueueBase::flushed, CPN::QueueBase::kernel, CPN::QueueBase::readshutdown, CPN::QueueBase::UnlockedFreespace(), CPN::QueueBase::writerequest, and CPN::QueueBase::writeshutdown.

Referenced by CPN::QueueBase::GetRawDequeuePtr(), CPN::RemoteQueue::WaitForFreespace(), and CPN::QueueBase::WaitForFreespace().

                                  {
         kernel->CheckTerminated();
         return (UnlockedFreespace() < writerequest || flushed) && !(readshutdown || writeshutdown);
     }

Here is the call graph for this function:

Here is the caller graph for this function:

unsigned CPN::QueueBase::WriteRequest ( )

inherited

For unit tests.

Definition at line 385 of file QueueBase.cc.

References CPN::QueueBase::writerequest.

                                      {
         AutoLock<QueueBase> al(*this);
         return writerequest;
     }

Member Data Documentation

PthreadCondition CPN::QueueBase::cond

protectedinherited

Definition at line 290 of file QueueBase.h.

Referenced by CPN::QueueBase::InternalFlush(), CPN::QueueBase::InternalReset(), CPN::QueueBase::NotifyData(), CPN::QueueBase::NotifyFreespace(), CPN::QueueBase::NotifyTerminate(), CPN::QueueBase::WaitForData(), and CPN::QueueBase::WaitForFreespace().

std::string CPN::QueueBase::datatype

protectedinherited

Definition at line 291 of file QueueBase.h.

unsigned CPN::QueueBase::dequeuethresh

protectedinherited

Definition at line 282 of file QueueBase.h.

Referenced by CPN::QueueBase::Dequeue(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), and CPN::RemoteQueue::ResetPacket().

bool CPN::ThresholdQueue::dequeueUseOld

protected

Definition at line 90 of file CPNThresholdQueue.h.

Referenced by InternalDequeue(), InternalGetRawDequeuePtr(), InternalReset(), CPN::RemoteQueue::ResetPacket(), UnlockedDequeueChannelStride(), and UnlockedGrow().

unsigned CPN::QueueBase::enqueuethresh

protectedinherited

Definition at line 281 of file QueueBase.h.

Referenced by CPN::QueueBase::Enqueue(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), and CPN::RemoteQueue::ResetPacket().

bool CPN::ThresholdQueue::enqueueUseOld

protected

Definition at line 89 of file CPNThresholdQueue.h.

Referenced by InternalEnqueue(), InternalGetRawEnqueuePtr(), InternalReset(), CPN::RemoteQueue::ResetPacket(), UnlockedEnqueueChannelStride(), and UnlockedGrow().

bool CPN::QueueBase::flushed

protectedinherited

Definition at line 285 of file QueueBase.h.

Referenced by CPN::QueueBase::Flushed(), CPN::RemoteQueue::FlushPacket(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::QueueBase::InternalFlush(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), CPN::QueueBase::ReadBlocked(), CPN::RemoteQueue::ResetPacket(), and CPN::QueueBase::WriteBlocked().

bool D4R::QueueBase::incomm

protectedinherited

Definition at line 126 of file D4RQueue.h.

Referenced by D4R::QueueBase::ReadBlock(), and D4R::QueueBase::WriteBlock().

bool CPN::QueueBase::indequeue

protectedinherited

Definition at line 283 of file QueueBase.h.

Referenced by CPN::QueueBase::Dequeue(), CPN::QueueBase::GetRawDequeuePtr(), InternalGetRawDequeuePtr(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), CPN::RemoteQueue::ResetPacket(), CPN::RemoteQueue::SendEnqueuePacket(), and UnlockedGrow().

bool CPN::QueueBase::inenqueue

protectedinherited

Definition at line 284 of file QueueBase.h.

Referenced by CPN::QueueBase::Enqueue(), CPN::RemoteQueue::EnqueuePacket(), CPN::QueueBase::GetRawEnqueuePtr(), InternalGetRawEnqueuePtr(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), CPN::RemoteQueue::ResetPacket(), and UnlockedGrow().

KernelBase* CPN::QueueBase::kernel

protectedinherited

Definition at line 286 of file QueueBase.h.

Referenced by CPN::QueueBase::Detect(), CPN::RemoteQueue::FileThreadEntryPoint(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::InternalCheckStatus(), CPN::QueueBase::ReadBlocked(), and CPN::QueueBase::WriteBlocked().

PthreadMutex CPN::QueueBase::lock

mutableprotectedinherited

Definition at line 289 of file QueueBase.h.

Referenced by CPN::RemoteQueue::FileThreadEntryPoint(), CPN::RemoteQueue::UnlockedGrow(), CPN::QueueBase::WaitForData(), and CPN::QueueBase::WaitForFreespace().

Logger CPN::QueueBase::logger

protectedinherited

Definition at line 288 of file QueueBase.h.

TQImpl* CPN::ThresholdQueue::oldqueue

protected

Definition at line 88 of file CPNThresholdQueue.h.

Referenced by InternalDequeue(), InternalEnqueue(), InternalGetRawDequeuePtr(), InternalGetRawEnqueuePtr(), InternalReset(), CPN::RemoteQueue::ResetPacket(), UnlockedDequeueChannelStride(), UnlockedEnqueueChannelStride(), UnlockedGrow(), and ~ThresholdQueue().

unsigned CPN::QueueBase::postpad

protectedinherited

Definition at line 278 of file QueueBase.h.

Referenced by CPN::QueueBase::InternalFlush().

unsigned CPN::QueueBase::prepad

protectedinherited

Definition at line 277 of file QueueBase.h.

Referenced by CPN::QueueBase::InternalReset().

TQImpl* CPN::ThresholdQueue::queue

protected

Definition at line 87 of file CPNThresholdQueue.h.

Referenced by CPN::RemoteQueue::EnqueuePacket(), CPN::RemoteQueue::GrowPacket(), CPN::RemoteQueue::InternalCheckStatus(), InternalDequeue(), InternalEnqueue(), InternalGetRawDequeuePtr(), InternalGetRawEnqueuePtr(), InternalReset(), CPN::RemoteQueue::ReadBlockPacket(), CPN::RemoteQueue::ResetPacket(), CPN::RemoteQueue::SendDequeuePacket(), CPN::RemoteQueue::SendEnqueuePacket(), CPN::RemoteQueue::SendGrowPacket(), ThresholdQueue(), UnlockedCount(), CPN::RemoteQueue::UnlockedCount(), UnlockedDequeueChannelStride(), UnlockedEmpty(), CPN::RemoteQueue::UnlockedEmpty(), UnlockedEnqueueChannelStride(), UnlockedFreespace(), UnlockedFull(), UnlockedGrow(), CPN::RemoteQueue::UnlockedGrow(), UnlockedMaxThreshold(), UnlockedNumChannels(), UnlockedNumDequeued(), UnlockedNumEnqueued(), UnlockedQueueLength(), CPN::RemoteQueue::WriteBlockPacket(), and ~ThresholdQueue().

shared_ptr<Node> D4R::QueueBase::reader

protectedinherited

Definition at line 122 of file D4RQueue.h.

Referenced by CPN::RemoteQueue::InternalCheckStatus(), D4R::QueueBase::ReadBlock(), CPN::RemoteQueue::SendD4RTagPacket(), D4R::QueueBase::SetReaderNode(), D4R::QueueBase::UnlockedSignalReaderTagChanged(), D4R::QueueBase::UnlockedSignalWriterTagChanged(), and D4R::QueueBase::WriteBlock().

const Key_t CPN::QueueBase::readerkey

protectedinherited

Definition at line 273 of file QueueBase.h.

Referenced by CPN::QueueBase::Dequeue(), CPN::RemoteQueue::GetKey(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::LogState(), CPN::QueueBase::QueueBase(), and CPN::RemoteQueue::RemoteQueue().

unsigned CPN::QueueBase::readrequest

protectedinherited

Definition at line 279 of file QueueBase.h.

Referenced by CPN::RemoteQueue::DequeuePacket(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::GetState(), CPN::RemoteQueue::InternalCheckStatus(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), CPN::QueueBase::NotifyData(), CPN::QueueBase::ReadBlocked(), CPN::RemoteQueue::ReadBlockPacket(), CPN::QueueBase::ReadRequest(), CPN::RemoteQueue::ResetPacket(), and CPN::RemoteQueue::SendReadBlockPacket().

bool CPN::QueueBase::readshutdown

protectedinherited

Definition at line 275 of file QueueBase.h.

Referenced by CPN::QueueBase::Dequeue(), CPN::RemoteQueue::DequeuePacket(), CPN::RemoteQueue::EndOfReadPacket(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::GetState(), CPN::RemoteQueue::HandleError(), CPN::RemoteQueue::InternalCheckStatus(), CPN::QueueBase::InternalFlush(), CPN::QueueBase::IsReaderShutdown(), CPN::QueueBase::LogState(), CPN::QueueBase::ReadBlocked(), CPN::RemoteQueue::ReadBlockPacket(), CPN::QueueBase::UnlockedShutdownReader(), and CPN::QueueBase::WriteBlocked().

bool D4R::QueueBase::readtagchanged

protectedinherited

Definition at line 124 of file D4RQueue.h.

Referenced by D4R::QueueBase::UnlockedSignalReaderTagChanged(), and D4R::QueueBase::WriteBlock().

bool CPN::QueueBase::useD4R

protectedinherited

Definition at line 287 of file QueueBase.h.

Referenced by CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::ReadBlockPacket(), CPN::QueueBase::WaitForData(), CPN::QueueBase::WaitForFreespace(), and CPN::RemoteQueue::WriteBlockPacket().

shared_ptr<Node> D4R::QueueBase::writer

protectedinherited

Definition at line 123 of file D4RQueue.h.

Referenced by CPN::RemoteQueue::InternalCheckStatus(), D4R::QueueBase::ReadBlock(), CPN::RemoteQueue::SendD4RTagPacket(), D4R::QueueBase::SetWriterNode(), D4R::QueueBase::UnlockedSignalReaderTagChanged(), D4R::QueueBase::UnlockedSignalWriterTagChanged(), and D4R::QueueBase::WriteBlock().

unsigned CPN::QueueBase::writerequest

protectedinherited

Definition at line 280 of file QueueBase.h.

Referenced by CPN::QueueBase::Detect(), CPN::RemoteQueue::EnqueuePacket(), CPN::QueueBase::GetRawDequeuePtr(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::RemoteQueue::GetState(), CPN::RemoteQueue::InternalCheckStatus(), CPN::QueueBase::InternalFlush(), CPN::QueueBase::InternalReset(), CPN::QueueBase::LogState(), CPN::QueueBase::NotifyFreespace(), CPN::RemoteQueue::ResetPacket(), CPN::RemoteQueue::SendWriteBlockPacket(), CPN::QueueBase::WriteBlocked(), CPN::RemoteQueue::WriteBlockPacket(), and CPN::QueueBase::WriteRequest().

const Key_t CPN::QueueBase::writerkey

protectedinherited

Definition at line 274 of file QueueBase.h.

Referenced by CPN::QueueBase::Enqueue(), CPN::RemoteQueue::GetKey(), CPN::QueueBase::GetRawEnqueuePtr(), CPN::QueueBase::InternalFlush(), CPN::QueueBase::LogState(), CPN::QueueBase::QueueBase(), and CPN::RemoteQueue::RemoteQueue().

bool CPN::QueueBase::writeshutdown

protectedinherited

Definition at line 276 of file QueueBase.h.

bool D4R::QueueBase::writetagchanged

protectedinherited

Definition at line 125 of file D4RQueue.h.

Referenced by D4R::QueueBase::ReadBlock(), and D4R::QueueBase::UnlockedSignalWriterTagChanged().

The documentation for this class was generated from the following files:

lib/CPNThresholdQueue.h
lib/CPNThresholdQueue.cc

Classes

Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
