ThresholdQueueBase Class Reference

#include <ThresholdQueueBase.h>

Inheritance diagram for ThresholdQueueBase:

Collaboration diagram for ThresholdQueueBase:

Public Types
typedef unsigned long	ulong

Public Member Functions
	ThresholdQueueBase (ulong elemSize, ulong queueLen, ulong maxThresh, ulong numChans=1)
	ThresholdQueueBase (ulong elemSize, const ThresholdQueueAttr &attr)
	~ThresholdQueueBase (void)
void	Reset (void)
void *	GetRawEnqueuePtr (ulong enqueueThresh, ulong chan=0) const
void	Enqueue (ulong count)
const void *	GetRawDequeuePtr (ulong dequeueThresh, ulong chan=0) const
void	Dequeue (ulong count)
ulong	Count (void) const
ulong	Freespace (void) const
bool	Empty (void) const
bool	Full (void) const
ulong	QueueLength (void) const
ulong	MaxThreshold (void) const
ulong	NumChannels (void) const
ulong	ChannelStride (void) const
ulong	ElementsEnqueued (void) const
ulong	ElementsDequeued (void) const
void	Grow (ulong queueLen, ulong maxThresh)

Protected Member Functions
void	AllocateBuf (ulong queueLen, ulong maxThresh, ulong numChans, bool useMBS)

Protected Attributes
ulong	elementSize
ulong	head
ulong	tail
ulong	queueLength
ulong	maxThreshold
ulong	numChannels
ulong	channelStride
ulong	chanOffset
ulong	baseOffset
ulong	elementsEnqueued
ulong	elementsDequeued
void *	base
MirrorBufferSet *	mbs

Detailed Description

Definition at line 86 of file ThresholdQueueBase.h.

Member Typedef Documentation

typedef unsigned long ThresholdQueueBase::ulong

Definition at line 90 of file ThresholdQueueBase.h.

Constructor & Destructor Documentation

ThresholdQueueBase::ThresholdQueueBase	(	ulong	elemSize,
		ulong	queueLen,
		ulong	maxThresh,
		ulong	numChans = 1
	)

Definition at line 20 of file ThresholdQueueBase.cc.

References AllocateBuf(), maxThreshold, numChannels, queueLength, and Reset().

:   elementSize(elemSize),
    queueLength(queueLen),
    maxThreshold(maxThresh),
    numChannels(numChans),
    chanOffset(0), baseOffset(0),
    base(0), mbs(0)
{
    if (maxThreshold<1)
        maxThreshold = 1;
    if (maxThreshold>queueLength)
        queueLength = maxThreshold;

    Reset();

    bool useMBS = 1;
    AllocateBuf(queueLength, maxThreshold, numChannels, useMBS);
}

Here is the call graph for this function:

ThresholdQueueBase::ThresholdQueueBase	(	ulong	elemSize,
		const ThresholdQueueAttr &	attr
	)

Definition at line 42 of file ThresholdQueueBase.cc.

References AllocateBuf(), ThresholdQueueAttr::baseOffset, baseOffset, ThresholdQueueAttr::chanOffset, chanOffset, elementSize, maxThreshold, numChannels, MirrorBufferSet::PageSize(), queueLength, Reset(), and ThresholdQueueAttr::useMBS.

:   elementSize(elemSize),
    queueLength(attr.queueLength),
    maxThreshold(attr.maxThreshold),
    numChannels(attr.numChannels),
    chanOffset(0), baseOffset(0),
    base(0), mbs(0)
{
    if (maxThreshold<1)
        maxThreshold = 1;
    if (maxThreshold>queueLength)
        queueLength = maxThreshold;

    Reset();

    bool useMBS = attr.useMBS;
    if (useMBS) {
        // there is no reason for an offset bigger than the page size
        baseOffset = attr.baseOffset % MirrorBufferSet::PageSize();
        baseOffset = baseOffset / elementSize;
        chanOffset = attr.chanOffset  / elementSize;
    }

    AllocateBuf(queueLength, maxThreshold, numChannels, useMBS);
}

Here is the call graph for this function:

ThresholdQueueBase::~ThresholdQueueBase

(

void

)

Definition at line 120 of file ThresholdQueueBase.cc.

References base, and mbs.

{
    if (mbs) {
        delete mbs;
        mbs = 0;
    } else {
        free(base);
    }
    base = 0;
}

Member Function Documentation

void ThresholdQueueBase::AllocateBuf ( ulong  queueLen, ulong  maxThresh, ulong  numChans, bool  useMBS  )

protected

Definition at line 71 of file ThresholdQueueBase.cc.

References base, baseOffset, MirrorBufferSet::BufferSize(), channelStride, chanOffset, elementSize, maxThreshold, mbs, MINIMUM_ALIGNMENT, MirrorBufferSet::MirrorSize(), numChannels, queueLength, Reset(), and MirrorBufferSet::Supported().

Referenced by Grow(), and ThresholdQueueBase().

{
    if (maxThresh<1)        maxThresh = 1;
    if (maxThresh>queueLen) queueLen = maxThresh;
    numChannels = numChans;

    if ( useMBS && MirrorBufferSet::Supported() ) {
        ulong bufSz = queueLen * elementSize;
        ulong mirSz = maxThresh-1 + baseOffset + (numChannels-1)*chanOffset;
        mirSz *= elementSize;
        mbs = new MirrorBufferSet(bufSz, mirSz, numChannels);
        // MirrorBufferSet may have just resized everything...
        queueLength  = mbs->BufferSize() / elementSize;
        maxThreshold = mbs->MirrorSize() / elementSize + 1;
        channelStride = queueLength + maxThreshold-1 + chanOffset;
        maxThreshold -= baseOffset + (numChannels-1)*chanOffset;
        base = (char*)((void*)(*mbs)) + baseOffset;
        // Corner case of queueLength == maxThreshold
        if (maxThreshold > queueLength) { maxThreshold = queueLength; }
    } else {
        queueLength = queueLen;
        maxThreshold = maxThresh;
        channelStride = queueLength + maxThreshold - 1;
        ulong mod = channelStride%MINIMUM_ALIGNMENT;
        if (mod != 0) {
            channelStride += MINIMUM_ALIGNMENT - mod;
        }
        base = malloc(channelStride * numChannels * elementSize);
    }
    Reset();
}

Here is the call graph for this function:

Here is the caller graph for this function:

ulong ThresholdQueueBase::ChannelStride ( void  ) const

inline

Definition at line 114 of file ThresholdQueueBase.h.

References channelStride.

Referenced by CPN::ThresholdQueue::UnlockedDequeueChannelStride(), and CPN::ThresholdQueue::UnlockedEnqueueChannelStride().

{ return channelStride; }

Here is the caller graph for this function:

ThresholdQueueBase::ulong ThresholdQueueBase::Count

(

void

)

const

Definition at line 217 of file ThresholdQueueBase.cc.

References head, queueLength, and tail.

Referenced by Empty(), CPN::RemoteQueue::EnqueuePacket(), Freespace(), GetRawDequeuePtr(), CPN::ThresholdQueue::TQImpl::Grow(), Grow(), CPN::RemoteQueue::InternalCheckStatus(), CPN::ThresholdQueue::InternalEnqueue(), CPN::RemoteQueue::ReadBlockPacket(), CPN::RemoteQueue::SendDequeuePacket(), CPN::RemoteQueue::SendEnqueuePacket(), CPN::ThresholdQueue::UnlockedCount(), CPN::RemoteQueue::UnlockedCount(), and CPN::RemoteQueue::WriteBlockPacket().

{
    register ulong count = (2*queueLength - head + tail);
    while (count>=queueLength) count -= queueLength;
    if (count) return count;
    return (head==tail) ? 0 : queueLength;
}

Here is the caller graph for this function:

void ThresholdQueueBase::Dequeue

(

ulong

count

)

Definition at line 205 of file ThresholdQueueBase.cc.

References elementsDequeued, head, and queueLength.

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), Grow(), CPN::ThresholdQueue::InternalDequeue(), and CPN::ThresholdQueue::InternalEnqueue().

{
    register ulong newHead = head+count;
    while (newHead>=2*queueLength) newHead -= 2*queueLength;
    head = newHead;
    elementsDequeued += count;
}

Here is the caller graph for this function:

ulong ThresholdQueueBase::ElementsDequeued ( void  ) const

inline

Definition at line 118 of file ThresholdQueueBase.h.

References elementsDequeued.

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), Grow(), and CPN::ThresholdQueue::UnlockedNumDequeued().

{ return elementsDequeued; }

Here is the caller graph for this function:

ulong ThresholdQueueBase::ElementsEnqueued ( void  ) const

inline

Definition at line 117 of file ThresholdQueueBase.h.

References elementsEnqueued.

Referenced by CPN::ThresholdQueue::TQImpl::Grow(), Grow(), and CPN::ThresholdQueue::UnlockedNumEnqueued().

{ return elementsEnqueued; }

Here is the caller graph for this function:

bool ThresholdQueueBase::Empty ( void  ) const

inline

Definition at line 107 of file ThresholdQueueBase.h.

References Count().

Referenced by CPN::RemoteQueue::InternalCheckStatus(), CPN::ThresholdQueue::UnlockedEmpty(), and CPN::RemoteQueue::UnlockedEmpty().

{ return !Count(); }

Here is the call graph for this function:

Here is the caller graph for this function:

void ThresholdQueueBase::Enqueue

(

ulong

count

)

Definition at line 162 of file ThresholdQueueBase.cc.

References base, channelStride, elementsEnqueued, elementSize, maxThreshold, mbs, numChannels, queueLength, and tail.

Referenced by Grow(), and CPN::ThresholdQueue::InternalEnqueue().

{
    if (!mbs) { // the mbs maintains circularity

        // we must mirror by ourselves
        register ulong idx = tail;
        while (idx>=queueLength) idx -= queueLength;

        // elems to copy from queue area to mirror area
        register ulong countUp = 0;
        if (idx<maxThreshold-1) countUp = maxThreshold-1-idx;   // to mirror's lower edge
        if (idx+count<maxThreshold-1) countUp = count;

        // elems to copy from mirror area to queue area
        register ulong countDn = 0;
        if (idx+count>queueLength) countDn = idx+count-queueLength;

        if (countUp || countDn)
            for (ulong chan=0; chan<numChannels; chan++) {
                char* chanBase = (char*)base + (chan*channelStride) * elementSize;

                // move data in the queue (below the threshold) to the mirror area
                char* dst = chanBase + (idx + queueLength) * elementSize;
                char* src = chanBase + idx * elementSize;
                memcpy(dst,src,countUp*elementSize);

                // move data from the mirror area to the queue (below the threshold)
                src = chanBase + queueLength * elementSize;
                memcpy(chanBase,src,countDn*elementSize);
            }
    }

    // update the tail pointer
    register ulong newTail = tail+count;
    while (newTail>=2*queueLength) newTail -= 2*queueLength;
    tail = newTail;
    elementsEnqueued += count;
}

Here is the caller graph for this function:

ThresholdQueueBase::ulong ThresholdQueueBase::Freespace

(

void

)

const

Definition at line 229 of file ThresholdQueueBase.cc.

References Count(), and queueLength.

Referenced by CPN::RemoteQueue::EnqueuePacket(), Full(), GetRawEnqueuePtr(), CPN::RemoteQueue::InternalCheckStatus(), and CPN::ThresholdQueue::UnlockedFreespace().

{
    return queueLength - Count();
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool ThresholdQueueBase::Full ( void  ) const

inline

Definition at line 108 of file ThresholdQueueBase.h.

References Freespace().

Referenced by CPN::ThresholdQueue::UnlockedFull().

{ return !Freespace(); }

Here is the call graph for this function:

Here is the caller graph for this function:

const void * ThresholdQueueBase::GetRawDequeuePtr	(	ulong	dequeueThresh,
		ulong	chan = 0
	)		const

Definition at line 148 of file ThresholdQueueBase.cc.

References base, channelStride, Count(), elementSize, head, MaxThreshold(), and queueLength.

Referenced by ThresholdQueue< T >::GetDequeuePtr(), CPN::ThresholdQueue::TQImpl::Grow(), Grow(), CPN::ThresholdQueue::InternalEnqueue(), and CPN::ThresholdQueue::InternalGetRawDequeuePtr().

{
    if (thresh>Count() || thresh>MaxThreshold()) return 0;
//  if (chan>=numChannels) return 0;
//  assert(chan<numChannels);
    register ulong idx = head;
    while (idx>=queueLength) idx -= queueLength;
    return (char*) base + (chan*channelStride + idx) * elementSize;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void * ThresholdQueueBase::GetRawEnqueuePtr	(	ulong	enqueueThresh,
		ulong	chan = 0
	)		const

Definition at line 134 of file ThresholdQueueBase.cc.

References base, channelStride, elementSize, Freespace(), MaxThreshold(), queueLength, and tail.

Referenced by ThresholdQueue< T >::GetEnqueuePtr(), Grow(), CPN::ThresholdQueue::InternalEnqueue(), and CPN::ThresholdQueue::InternalGetRawEnqueuePtr().

{
    if (thresh>Freespace() || thresh>MaxThreshold()) return 0;
//  if (chan>=numChannels) return 0;
//  assert(chan<numChannels);
    register ulong idx = tail;
    while (idx>=queueLength) idx -= queueLength;
    return (char*) base + (chan*channelStride + idx) * elementSize;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void ThresholdQueueBase::Grow	(	ulong	queueLen,
		ulong	maxThresh
	)

Definition at line 242 of file ThresholdQueueBase.cc.

References AllocateBuf(), Count(), Dequeue(), ElementsDequeued(), elementsDequeued, ElementsEnqueued(), elementsEnqueued, elementSize, Enqueue(), GetRawDequeuePtr(), GetRawEnqueuePtr(), MaxThreshold(), mbs, numChannels, and QueueLength().

{
    fprintf(stderr, "ThresholdQueueBase::Grow(%lu,%lu)\n", queueLen, maxThresh);

    // handle the default parameter case
    if (!maxThresh) maxThresh = MaxThreshold();

    // ignore the do-nothing case
    if (queueLen <= QueueLength() && maxThresh <= MaxThreshold()) return;

    // we don't do any shrinking
    if (maxThresh <= MaxThreshold()) maxThresh = MaxThreshold();
    if (queueLen <= QueueLength()) queueLen = QueueLength();

    // keep our old info around
    ThresholdQueueBase  oldQueue(*this);    // just duplicate the pointers

    // allocate a new buffer (or MirrorBufferSet)
    AllocateBuf(queueLen,maxThresh,numChannels,mbs?1:0);

    // growth should not affect this member
    elementsDequeued = oldQueue.ElementsDequeued();

    // copy all in oldQueue to our new buffer with existing mechanisms
    ulong count;
    while ((count = oldQueue.Count()) != 0) {
        if (count>oldQueue.MaxThreshold())
            count = oldQueue.MaxThreshold();
        for (ulong chan=0; chan<numChannels; chan++) {
            const void* src = oldQueue.GetRawDequeuePtr(count,chan);
            void* dst = GetRawEnqueuePtr(count,chan);
            assert(src && dst);
            memcpy(dst,src,count*elementSize);
        }
        Enqueue(count);
        oldQueue.Dequeue(count);
    }

    // growth should not affect this member
    elementsEnqueued = oldQueue.ElementsEnqueued();

    // when oldQueue gets destructed, it will deallocate the old buffers
}

Here is the call graph for this function:

ulong ThresholdQueueBase::MaxThreshold ( void  ) const

inline

Definition at line 111 of file ThresholdQueueBase.h.

References maxThreshold.

Referenced by CPN::RemoteQueue::EnqueuePacket(), GetRawDequeuePtr(), GetRawEnqueuePtr(), CPN::ThresholdQueue::TQImpl::Grow(), Grow(), CPN::RemoteQueue::GrowPacket(), CPN::ThresholdQueue::InternalEnqueue(), CPN::RemoteQueue::SendEnqueuePacket(), CPN::RemoteQueue::SendGrowPacket(), CPN::RemoteQueue::UnlockedGrow(), and CPN::ThresholdQueue::UnlockedMaxThreshold().

{ return maxThreshold; }

Here is the caller graph for this function:

ulong ThresholdQueueBase::NumChannels ( void  ) const

inline

Definition at line 113 of file ThresholdQueueBase.h.

References numChannels.

Referenced by CPN::RemoteQueue::EnqueuePacket(), CPN::ThresholdQueue::InternalEnqueue(), CPN::RemoteQueue::SendEnqueuePacket(), and CPN::ThresholdQueue::UnlockedNumChannels().

{ return numChannels; }

Here is the caller graph for this function:

ulong ThresholdQueueBase::QueueLength ( void  ) const

inline

Definition at line 110 of file ThresholdQueueBase.h.

References queueLength.

Referenced by CPN::RemoteQueue::EnqueuePacket(), Grow(), and CPN::ThresholdQueue::UnlockedQueueLength().

{ return queueLength; }

Here is the caller graph for this function:

void ThresholdQueueBase::Reset

(

void

)

Definition at line 108 of file ThresholdQueueBase.cc.

References elementsDequeued, elementsEnqueued, head, and tail.

Referenced by AllocateBuf(), CPN::ThresholdQueue::InternalReset(), CPN::RemoteQueue::ResetPacket(), and ThresholdQueueBase().

{
    elementsEnqueued = 0;
    elementsDequeued = 0;

    head = 0;
    tail = 0;
}

Here is the caller graph for this function:

Member Data Documentation

void* ThresholdQueueBase::base

protected

Definition at line 129 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Enqueue(), GetRawDequeuePtr(), GetRawEnqueuePtr(), and ~ThresholdQueueBase().

ulong ThresholdQueueBase::baseOffset

protected

Definition at line 127 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), and ThresholdQueueBase().

ulong ThresholdQueueBase::channelStride

protected

Definition at line 126 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), ChannelStride(), Enqueue(), GetRawDequeuePtr(), and GetRawEnqueuePtr().

ulong ThresholdQueueBase::chanOffset

protected

Definition at line 127 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), and ThresholdQueueBase().

ulong ThresholdQueueBase::elementsDequeued

protected

Definition at line 128 of file ThresholdQueueBase.h.

Referenced by Dequeue(), ElementsDequeued(), Grow(), and Reset().

ulong ThresholdQueueBase::elementsEnqueued

protected

Definition at line 128 of file ThresholdQueueBase.h.

Referenced by ElementsEnqueued(), Enqueue(), Grow(), and Reset().

ulong ThresholdQueueBase::elementSize

protected

Definition at line 123 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Enqueue(), GetRawDequeuePtr(), GetRawEnqueuePtr(), Grow(), and ThresholdQueueBase().

ulong ThresholdQueueBase::head

protected

Definition at line 124 of file ThresholdQueueBase.h.

Referenced by Count(), Dequeue(), GetRawDequeuePtr(), CPN::ThresholdQueue::TQImpl::Grow(), and Reset().

ulong ThresholdQueueBase::maxThreshold

protected

Definition at line 125 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Enqueue(), MaxThreshold(), and ThresholdQueueBase().

MirrorBufferSet* ThresholdQueueBase::mbs

protected

Definition at line 130 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Enqueue(), Grow(), and ~ThresholdQueueBase().

ulong ThresholdQueueBase::numChannels

protected

Definition at line 126 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Enqueue(), Grow(), NumChannels(), and ThresholdQueueBase().

ulong ThresholdQueueBase::queueLength

protected

Definition at line 125 of file ThresholdQueueBase.h.

Referenced by AllocateBuf(), Count(), Dequeue(), Enqueue(), Freespace(), GetRawDequeuePtr(), GetRawEnqueuePtr(), QueueLength(), and ThresholdQueueBase().

ulong ThresholdQueueBase::tail

protected

Definition at line 124 of file ThresholdQueueBase.h.

Referenced by Count(), Enqueue(), GetRawEnqueuePtr(), CPN::ThresholdQueue::TQImpl::Grow(), and Reset().

---

The documentation for this class was generated from the following files:

• lib/ThresholdQueueBase.h
• lib/ThresholdQueueBase.cc
