PthreadCondition Class Reference

#include <PthreadCondition.h>

Inheritance diagram for PthreadCondition:

Collaboration diagram for PthreadCondition:

Public Member Functions
	PthreadCondition (void)
	PthreadCondition (const PthreadConditionAttr &condattr)
	~PthreadCondition (void)
	operator pthread_cond_t * (void)
PthreadCondition &	Signal (void)
PthreadCondition &	Broadcast (void)
PthreadCondition &	Wait (PthreadMutex &mutex)
int	TimedWait (PthreadMutex &mutex, const timespec *abstime)
int	TimedWait (PthreadMutex &mutex, double reltime)
int	Error (void)
void	Clear (void)

Protected Member Functions
void	TrapError (int result)

Protected Attributes
int	error

Private Attributes
pthread_cond_t	theCond

Detailed Description

Definition at line 40 of file PthreadCondition.h.

Constructor & Destructor Documentation

PthreadCondition::PthreadCondition

(

void

)

Definition at line 32 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

{
    TrapError(pthread_cond_init(&theCond, 0));
}

Here is the call graph for this function:

PthreadCondition::PthreadCondition

(

const PthreadConditionAttr &

condattr

)

Definition at line 41 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

{
    //  It should simply be:
//  TrapError(pthread_cond_init(&theCond, cAttr));

    //  This is necessary because
    //      SGI's pthread_cond_init is not const correct!!!

    pthread_condattr_t* myAttr = (PthreadConditionAttr&)cAttr;
    TrapError(pthread_cond_init(&theCond, myAttr));
}

Here is the call graph for this function:

PthreadCondition::~PthreadCondition

(

void

)

Definition at line 56 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

{
    try {
        TrapError(pthread_cond_destroy(&theCond));
    } catch (...) {
        std::terminate();
    }
}

Here is the call graph for this function:

Member Function Documentation

PthreadCondition & PthreadCondition::Broadcast

(

void

)

Definition at line 76 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

Referenced by CPN::RemoteQueue::ActionThreadEntryPoint(), Sync::Future< int >::Cancel(), Sync::Future< void >::Cancel(), CPN::RemoteQueue::HandleError(), CPN::RemoteQueue::InternalCheckStatus(), CPN::QueueBase::InternalFlush(), CPN::QueueBase::InternalReset(), Sync::Future< int >::InternalSet(), Sync::Future< void >::InternalSet(), Pthread::Join(), CPN::QueueBase::NotifyData(), CPN::QueueBase::NotifyFreespace(), CPN::QueueBase::NotifyTerminate(), Pthread::Pthread(), Pthread::PthreadCleanup(), Pthread::PthreadEntryPoint(), CPN::LocalContext::SignalKernelEnd(), CPN::LocalContext::SignalKernelStart(), CPN::LocalContext::SignalNodeEnd(), CPN::LocalContext::SignalNodeStart(), Pthread::Start(), CPN::LocalContext::Terminate(), CPN::RemoteQueue::UnlockedShutdown(), PthreadReadWriteLock::WriteUnlock(), Pthread::~Pthread(), and CPN::RemoteQueue::~RemoteQueue().

{   TrapError(pthread_cond_broadcast(&theCond));
    return *this;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void PthreadErrorHandler::Clear ( void  )

inlineinherited

Definition at line 40 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

{ error = 0; }

int PthreadErrorHandler::Error ( void  )

inlineinherited

Definition at line 39 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

{ return error; }

PthreadCondition::operator pthread_cond_t * ( void  )

inline

Definition at line 47 of file PthreadCondition.h.

References theCond.

{ return &theCond; }

PthreadCondition & PthreadCondition::Signal

(

void

)

Definition at line 68 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

Referenced by CPN::RemoteQueueHolder::CleanupQueue(), and PthreadReadWriteLock::ReadUnlock().

{   TrapError(pthread_cond_signal(&theCond));
    return *this;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int PthreadCondition::TimedWait	(	PthreadMutex &	mutex,
		const timespec *	abstime
	)

Definition at line 91 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

{
    int err = pthread_cond_timedwait(&theCond, mutex, abstime);
    if (err != 0) {
        if (err == ETIMEDOUT) { return true; }
        TrapError(err);
    }
    return false;
}

Here is the call graph for this function:

int PthreadCondition::TimedWait	(	PthreadMutex &	mutex,
		double	reltime
	)

Definition at line 103 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

{
    timespec ts;
    timeval tv;
    int ret = gettimeofday(&tv, 0);
    if (ret != 0) throw ErrnoException();
    ts.tv_sec = tv.tv_sec;
    ts.tv_nsec = tv.tv_usec * 1000;
    unsigned sec = (unsigned)reltime;
    if (sec > 0) {
        ts.tv_sec += sec;
        unsigned nsec = (unsigned)((reltime - sec)*1e9);
        if (nsec > 0) ts.tv_nsec += nsec;
    }
    int err = pthread_cond_timedwait(&theCond, mutex, &ts);
    if (err != 0) {
        if (err == ETIMEDOUT) { return true; }
        TrapError(err);
    }
    return false;
}

Here is the call graph for this function:

void PthreadErrorHandler::TrapError ( int  result )

inlineprotectedinherited

Definition at line 48 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

Referenced by Broadcast(), PthreadAttr::DetachState(), PthreadBase::Join(), Pthread::Join(), PthreadMutex::Lock(), PthreadMutex::Poll(), Pthread::Pthread(), PthreadAttr::PthreadAttr(), PthreadBase::PthreadBase(), PthreadCondition(), PthreadConditionAttr::PthreadConditionAttr(), PthreadKey< T >::PthreadKey(), PthreadMutex::PthreadMutex(), PthreadMutexAttr::PthreadMutexAttr(), PthreadReadWriteLock::ReadUnlock(), PthreadAttr::ScheduleScope(), PthreadKey< T >::Set(), Signal(), TimedWait(), PthreadMutex::Unlock(), Wait(), PthreadReadWriteLock::WriteUnlock(), PthreadAttr::~PthreadAttr(), ~PthreadCondition(), PthreadConditionAttr::~PthreadConditionAttr(), PthreadKey< T >::~PthreadKey(), PthreadMutex::~PthreadMutex(), and PthreadMutexAttr::~PthreadMutexAttr().

{
    if (err) {
        error = err;
        throw ErrnoException(err);
    }
}

Here is the caller graph for this function:

PthreadCondition & PthreadCondition::Wait

(

PthreadMutex &

mutex

)

Definition at line 84 of file PthreadCondition.cc.

References theCond, and PthreadErrorHandler::TrapError().

Referenced by CPN::RemoteQueue::FileThreadEntryPoint(), Sync::Future< int >::InternalWait(), Sync::Future< void >::InternalWait(), Pthread::Join(), Pthread::PthreadEntryPoint(), PthreadReadWriteLock::ReadLock(), CPN::RemoteContextClient::RemoteCall(), CPN::RemoteQueueHolder::Shutdown(), CPN::RemoteQueue::UnlockedGrow(), CPN::LocalContext::WaitForAllNodeEnd(), CPN::QueueBase::WaitForData(), CPN::QueueBase::WaitForFreespace(), CPN::LocalContext::WaitForKernelStart(), CPN::LocalContext::WaitForNodeEnd(), CPN::LocalContext::WaitForNodeStart(), and PthreadReadWriteLock::WriteLock().

{   TrapError(pthread_cond_wait(&theCond, mutex));
    return *this;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

int PthreadErrorHandler::error

protectedinherited

Definition at line 43 of file PthreadErrorHandler.h.

Referenced by PthreadErrorHandler::Clear(), PthreadErrorHandler::Error(), PthreadErrorHandler::PthreadErrorHandler(), and PthreadErrorHandler::TrapError().

pthread_cond_t PthreadCondition::theCond

private

Definition at line 60 of file PthreadCondition.h.

Referenced by Broadcast(), operator pthread_cond_t *(), PthreadCondition(), Signal(), TimedWait(), Wait(), and ~PthreadCondition().

---

The documentation for this class was generated from the following files:

• include/cpn/threading/PthreadCondition.h
• lib/threading/PthreadCondition.cc
