#include <RemoteContext.h>

Inheritance diagram for CPN::RemoteContext:

Collaboration diagram for CPN::RemoteContext:

Public Member Functions
	RemoteContext (const SocketAddress &addr)

	RemoteContext (const SockAddrList &addrs)

	RemoteContext (int fd)

	~RemoteContext ()

virtual int	LogLevel () const

virtual int	LogLevel (int level)

virtual void	Log (int level, const std::string &logmsg)
	Log a message to this outputer. More...

virtual CPN::Key_t	SetupKernel (const std::string &name, const std::string &hostname, const std::string &servname, CPN::KernelBase *kernel)
	Called by the Kernel when it has successfully set it self up. This gives the Context a way to notify the Kernel of events and lets other Kernels look up the connection information for this Kernel. More...

virtual CPN::Key_t	SetupKernel (const std::string &name, KernelBase *kernel)
	Called by the kernel when it is not in remote mode. More...

virtual CPN::Key_t	GetKernelKey (const std::string &kernel)

virtual std::string	GetKernelName (CPN::Key_t kernelkey)

virtual void	GetKernelConnectionInfo (CPN::Key_t kernelkey, std::string &hostname, std::string &servname)
	obtain the connection information for the given kernel More...

virtual CPN::Key_t	WaitForKernelStart (const std::string &kernel)
	Does not return until the given kernel has started. More...

virtual void	SignalKernelStart (CPN::Key_t kernelkey)
	Signal to the context that the given kernel has started. More...

virtual void	SignalKernelEnd (CPN::Key_t kernelkey)
	Signal to the Context that the given kernel is dead. More...

virtual void	SendCreateWriter (CPN::Key_t kernelkey, const CPN::SimpleQueueAttr &attr)
	Tell a given kernel that it needs to create a queue write end. More...

virtual void	SendCreateReader (CPN::Key_t kernelkey, const CPN::SimpleQueueAttr &attr)
	Tell a given kernel that it needs to create a queue read end. More...

virtual void	SendCreateQueue (CPN::Key_t kernelkey, const CPN::SimpleQueueAttr &attr)
	Tell a given kernel that it needs to create a queue. More...

virtual void	SendCreateNode (CPN::Key_t kernelkey, const CPN::NodeAttr &attr)
	Tell a given kernel that it needs to create a node. More...

virtual CPN::Key_t	CreateNodeKey (CPN::Key_t kernelkey, const std::string &nodename)
	Tell the context to allocate a new node key and data structure for a node with nodename which is on kernelkey. More...

virtual CPN::Key_t	GetNodeKey (const std::string &nodename)

virtual std::string	GetNodeName (CPN::Key_t nodekey)

virtual CPN::Key_t	GetNodeKernel (CPN::Key_t nodekey)

virtual void	SignalNodeStart (CPN::Key_t nodekey)
	Called by the node startup routine to indicate that the node has started. More...

virtual void	SignalNodeEnd (CPN::Key_t nodekey)
	Called by the node cleanup routine to indicate that the node has ended. More...

virtual CPN::Key_t	WaitForNodeStart (const std::string &nodename)
	Waits until the node starts and returns the key, if the node is already started returns the key. More...

virtual void	WaitForNodeEnd (const std::string &nodename)
	Waits for the given node to signal end. More...

virtual void	WaitForAllNodeEnd ()
	Convenience method which waits until there are no nodes running. If no node have started then this will return immediately. More...

virtual CPN::Key_t	GetCreateReaderKey (CPN::Key_t nodekey, const std::string &portname)
	Get the key associated with the given endpoint for the given node. Creates the information if it does not exist. More...

virtual CPN::Key_t	GetReaderNode (CPN::Key_t portkey)

virtual CPN::Key_t	GetReaderKernel (CPN::Key_t portkey)

virtual std::string	GetReaderName (CPN::Key_t portkey)

virtual CPN::Key_t	GetCreateWriterKey (CPN::Key_t nodekey, const std::string &portname)

virtual CPN::Key_t	GetWriterNode (CPN::Key_t portkey)

virtual CPN::Key_t	GetWriterKernel (CPN::Key_t portkey)

virtual std::string	GetWriterName (CPN::Key_t portkey)

virtual void	ConnectEndpoints (CPN::Key_t writerkey, CPN::Key_t readerkey, const std::string &qname)
	Called by the kernel when a queue is created. Note that the endpoints may have been created when the node requests them but the queue may be created long after that. More...

virtual CPN::Key_t	GetReadersWriter (CPN::Key_t readerkey)

virtual CPN::Key_t	GetWritersReader (CPN::Key_t writerkey)

virtual void	Terminate ()
	Signal to the Context that the network is terminating. After this call most methods will throw a ShutdownException. More...

virtual bool	IsTerminated ()

virtual bool	RequireRemote ()
	Lets the kernel know that this context type requires remote activity. This overrides the kernel option for remote activity. Default value is false. More...

void	DispatchMessage (const Variant &msg)

void	CheckTerminated ()
	Convenience method that checks IsTerminated and if so throws a ShutdownException. More...

virtual unsigned	CalculateGrowSize (unsigned currentsize, unsigned request)
	Calculate the new queue size when a queue needs to grow. More...

Static Public Member Functions
static shared_ptr< Context >	Local ()
	Create a local context. More...

Protected Member Functions
void	SendMessage (const Variant &msg)

void *	EntryPoint ()

Protected Attributes
PthreadMutex	lock

Private Member Functions
void	EndWrite ()

bool	IsEndWrite ()

Private Attributes
std::auto_ptr< Pthread >	thread

SocketHandle	sock

bool	endwrite

Detailed Description

An implementation for the RemoteContextClient that is paired with RemoteContextDaemon.

Definition at line 37 of file RemoteContext.h.

Constructor & Destructor Documentation

CPN::RemoteContext::RemoteContext ( const SocketAddress & addr )

Definition at line 33 of file RemoteContext.cc.

References SocketHandle::Connect(), CreatePthreadFunctional(), EntryPoint(), SocketHandle::SetNoDelay(), sock, and thread.

         : endwrite(false)
     {
         thread.reset(CreatePthreadFunctional(this, &RemoteContext::EntryPoint));
         sock.Connect(addr);
         sock.SetNoDelay(true);
         thread->Start();
     }

Here is the call graph for this function:

CPN::RemoteContext::RemoteContext ( const SockAddrList & addrs )

Definition at line 42 of file RemoteContext.cc.

References SocketHandle::Connect(), CreatePthreadFunctional(), EntryPoint(), SocketHandle::SetNoDelay(), sock, and thread.

         : endwrite(false)
     {
         thread.reset(CreatePthreadFunctional(this, &RemoteContext::EntryPoint));
         sock.Connect(addrs);
         sock.SetNoDelay(true);
         thread->Start();
     }

Here is the call graph for this function:

CPN::RemoteContext::RemoteContext ( int fd )

Definition at line 51 of file RemoteContext.cc.

References CreatePthreadFunctional(), EntryPoint(), SocketHandle::SetNoDelay(), sock, and thread.

         : sock(fd)
     {
         thread.reset(CreatePthreadFunctional(this, &RemoteContext::EntryPoint));
         sock.SetNoDelay(true);
         thread->Start();
     }

Here is the call graph for this function:

CPN::RemoteContext::~RemoteContext ( )

Definition at line 59 of file RemoteContext.cc.

References EndWrite(), and thread.

                                   {
         EndWrite();
         thread->Join();
     }

Here is the call graph for this function:

Member Function Documentation

virtual unsigned CPN::Context::CalculateGrowSize	(	unsigned	currentsize,
		unsigned	request
	)

inlinevirtualinherited

Calculate the new queue size when a queue needs to grow.

Returns: the new queue size

Definition at line 275 of file Context.h.

275 { return currentsize + request; }

void CPN::Context::CheckTerminated ( )

inherited

Convenience method that checks IsTerminated and if so throws a ShutdownException.

Exceptions

ShutdownException

Definition at line 44 of file Context.cc.

References CPN::Context::IsTerminated().

                                   {
         if (IsTerminated()) {
             throw ShutdownException();
         }
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::ConnectEndpoints	(	CPN::Key_t	writerkey,
		CPN::Key_t	readerkey,
		const std::string &	qname
	)

virtualinherited

Called by the kernel when a queue is created. Note that the endpoints may have been created when the node requests them but the queue may be created long after that.

Parameters

writerkey	the unique key for the writer endpoint
readerkey	the unique key for the reader endpoint

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 481 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CONNECT_ENDPOINTS, and CPN::RemoteContextClient::SendMessage().

                                                                                                        {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_CONNECT_ENDPOINTS;
         msg["readerkey"] = readerkey;
         msg["writerkey"] = writerkey;
         msg["qname"] = qname;
         SendMessage(msg);
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::CreateNodeKey	(	CPN::Key_t	kernelkey,
		const std::string &	nodename
	)

virtualinherited

Tell the context to allocate a new node key and data structure for a node with nodename which is on kernelkey.

Parameters

kernelkey	the id of the kernel that the node will run on
nodename	the name of the node

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 266 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CREATE_NODE_KEY, and CPN::RemoteContextClient::RemoteCall().

                                                                                        {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_CREATE_NODE_KEY;
         msg["kernelkey"] = kernelkey;
         msg["name"] = nodename;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("Node " + nodename + " already exists.");
         }
         return reply["nodeinfo"]["key"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::DispatchMessage ( const Variant & msg )

inherited

Handle a message from the RemoteContextServer.

Parameters

msg	the message

Definition at line 580 of file RemoteContextClient.cc.

References ASSERT, CPN::RemoteContextClient::callwaiters, CPN::RemoteContextClient::InternalTerminate(), CPN::RemoteContextClient::kernels, CPN::RemoteContextClient::lock, CPN::MsgToNodeAttr(), CPN::MsgToQueueAttr(), CPN::RCTXMT_CREATE_NODE, CPN::RCTXMT_CREATE_QUEUE, CPN::RCTXMT_CREATE_READER, CPN::RCTXMT_CREATE_WRITER, CPN::RCTXMT_TERMINATE, CPN::KernelBase::RemoteCreateNode(), CPN::KernelBase::RemoteCreateQueue(), CPN::KernelBase::RemoteCreateReader(), CPN::KernelBase::RemoteCreateWriter(), AutoLock< Lockable >::Unlock(), and CPN::RemoteContextClient::waiters.

Referenced by EntryPoint().

                                                                 {
         if (!msg.IsMap()) { return; }
         AutoLock<PthreadMutex> plock(lock);
         if (msg.Contains("type") && msg["type"].AsNumber<RCTXMT_t>() == RCTXMT_TERMINATE) {
             InternalTerminate();
             return;
         }
         // Need to add for the general informative messages.
         //
         // The specific reply messages
         std::string msgtype = msg["msgtype"].AsString();
         if (msgtype == "reply") {
             unsigned tranid = msg["msgid"].AsUnsigned();
             WaiterMap::iterator entry;
             entry = callwaiters.find(tranid);
             ASSERT(entry != callwaiters.end());
             entry->second->msg = msg;
             entry->second->signaled = true;
             entry->second->cond.Signal();
             callwaiters.erase(entry);
         } else if (msgtype == "broadcast") {
             WaiterList::iterator entry;
             entry = waiters.begin();
             while (entry != waiters.end()) {
                 GenericWaiterPtr waiter = entry->lock();
                 if (waiter) {
                     waiter->messages.push_back(msg);
                     waiter->cond.Signal();
                     ++entry;
                 } else {
                     entry = waiters.erase(entry);
                 }
             }
         } else if (msgtype == "kernel") {
             Key_t kernelkey = msg["kernelkey"].AsNumber<Key_t>();
             KernelMap::iterator entry = kernels.find(kernelkey);
             if (entry != kernels.end()) {
                 KernelBase *kernel = entry->second;
                 // Cannot call a kernel method with the lock.
                 plock.Unlock();
                 ASSERT(kernel);
                 switch (msg["type"].AsNumber<RCTXMT_t>()) {
                 case RCTXMT_CREATE_NODE:
                     kernel->RemoteCreateNode(MsgToNodeAttr(msg["nodeattr"]));
                     break;
                 case RCTXMT_CREATE_QUEUE:
                     kernel->RemoteCreateQueue(MsgToQueueAttr(msg["queueattr"]));
                     break;
                 case RCTXMT_CREATE_WRITER:
                     kernel->RemoteCreateWriter(MsgToQueueAttr(msg["queueattr"]));
                     break;
                 case RCTXMT_CREATE_READER:
                     kernel->RemoteCreateReader(MsgToQueueAttr(msg["queueattr"]));
                     break;
                 default:
                     ASSERT(false, "Unknown kernel message type");
                 }
             } else {
                 ASSERT(false, "Message for kernel %llu but said kernel doesn't exist!", kernelkey);
             }
         } else {
             ASSERT(false);
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::RemoteContext::EndWrite ( )

private

Definition at line 114 of file RemoteContext.cc.

References endwrite, CPN::RemoteContextClient::lock, SocketHandle::ShutdownWrite(), and sock.

Referenced by ~RemoteContext().

                                  {
         PthreadMutexProtected alock(lock);
         endwrite = true;
         sock.ShutdownWrite();
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void * CPN::RemoteContext::EntryPoint ( )

protected

Definition at line 76 of file RemoteContext.cc.

References FileHandle::Close(), CPN::RemoteContextClient::DispatchMessage(), FileHandle::Eof(), ErrnoException::Error(), FileHandle::Good(), FileHandle::Poll(), FileHandle::Readable(), SocketHandle::Recv(), sock, CPN::RemoteContextClient::Terminate(), and ErrnoException::what().

Referenced by RemoteContext().

                                     {
         std::vector<char> buf(4*1024);
         unsigned num = 0;
         try {
             sock.Readable(false);
             sock.Poll(-1);
             while (sock.Good()) {
                 if (buf.size() - num <= 0) {
                     buf.resize(buf.size()*2);
                 }
                 unsigned numread = sock.Recv(&buf[num], buf.size() - num, false);
                 if (numread == 0) {
                     if (sock.Eof()) {
                         Terminate();
                         return 0;
                     }
                     sock.Poll(-1);
                 } else {
                     num += numread;
                     char *end = (char*)memchr(&buf[0], 0, num);
                     while (end != 0) {
                         Variant v = libvariant::DeserializeJSON(&buf[0]);
                         DispatchMessage(v);
                         end += 1;
                         num -= (end - &buf[0]);
                         memmove(&buf[0], end, num);
                         end = (char*)memchr(&buf[0], 0, num);
                     }
                 }
             }
         } catch (const ErrnoException &e) {
             fprintf(stderr, "RemoteContext: Uncaught errno exception (%d): %s\n", e.Error(), e.what());
             Terminate();
         }
         sock.Close();
         return 0;
     }

Here is the call graph for this function:

Here is the caller graph for this function:

Key_t CPN::RemoteContextClient::GetCreateReaderKey	(	CPN::Key_t	nodekey,
		const std::string &	portname
	)

virtualinherited

Get the key associated with the given endpoint for the given node. Creates the information if it does not exist.

Parameters

nodekey	the unique id for the node
portname	the name of the endpoint.

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 435 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetCreateEndpointKey(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_CREATE_READER_KEY.

                                                                                           {
         PthreadMutexProtected plock(lock);
         return GetCreateEndpointKey(RCTXMT_GET_CREATE_READER_KEY, nodekey, portname);
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetCreateWriterKey	(	CPN::Key_t	nodekey,
		const std::string &	portname
	)

virtualinherited

See Also: GetCreateReaderKey

Implements CPN::Context.

Definition at line 458 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetCreateEndpointKey(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_CREATE_WRITER_KEY.

                                                                                           {
         PthreadMutexProtected plock(lock);
         return GetCreateEndpointKey(RCTXMT_GET_CREATE_WRITER_KEY, nodekey, portname);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::GetKernelConnectionInfo	(	CPN::Key_t	kernelkey,
		std::string &	hostname,
		std::string &	servname
	)

virtualinherited

obtain the connection information for the given kernel

Parameters

kernelkey	the unique id for the kernel
hostname	(output) string to be filled with the hostname
servname	(output) string to be filled with the service name

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 111 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_KERNEL_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                                                                {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_KERNEL_INFO;
         msg["key"] = kernelkey;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such kernel");
         }
         Variant kernelinfo = reply["kernelinfo"];
         hostname = kernelinfo["hostname"].AsString();
         servname = kernelinfo["servname"].AsString();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetKernelKey ( const std::string & kernel )

virtualinherited

Parameters

kernel the name of the kernel

Returns: the key for the given kernel.

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 85 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_KERNEL_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                    {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_KERNEL_INFO;
         msg["name"] = kernel;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such kernel");
         }
         return reply["kernelinfo"]["key"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

std::string CPN::RemoteContextClient::GetKernelName ( CPN::Key_t kernelkey )

virtualinherited

Parameters

kernelkey the key to the kernel

Returns: the name for the kernel

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 98 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_KERNEL_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                 {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_KERNEL_INFO;
         msg["key"] = kernelkey;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such kernel");
         }
         return reply["kernelinfo"]["name"].AsString();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetNodeKernel ( CPN::Key_t nodekey )

virtualinherited

Parameters

nodekey the unique key for the node

Returns: the key for the kernel the node is running on

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 421 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_NODE_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                           {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NODE_INFO;
         msg["key"] = nodekey;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such node");
         }
         return reply["nodeinfo"]["kernelkey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetNodeKey ( const std::string & nodename )

virtualinherited

Returns: the unique key associated with the given node name.

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 280 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_NODE_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                    {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NODE_INFO;
         msg["name"] = nodename;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such node");
         }
         return reply["nodeinfo"]["key"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

std::string CPN::RemoteContextClient::GetNodeName ( CPN::Key_t nodekey )

virtualinherited

Returns: the name associated with the given node key

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 293 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_GET_NODE_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                             {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NODE_INFO;
         msg["key"] = nodekey;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
             throw std::invalid_argument("No such node");
         }
         return reply["nodeinfo"]["name"].AsString();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetReaderKernel ( CPN::Key_t portkey )

virtualinherited

Parameters

portkey the unique id for the port

Returns: the key for the kernel this port is on

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 446 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_READER_INFO.

                                                             {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_READER_INFO, portkey);
         return info["kernelkey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

std::string CPN::RemoteContextClient::GetReaderName ( CPN::Key_t portkey )

virtualinherited

Parameters

portkey the unique id for the port

Returns: the name of the port

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 452 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_READER_INFO.

                                                               {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_READER_INFO, portkey);
         return info["name"].AsString();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetReaderNode ( CPN::Key_t portkey )

virtualinherited

Parameters

portkey the unique id for the port

Returns: the key for the node this port is on

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 440 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_READER_INFO.

                                                           {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_READER_INFO, portkey);
         return info["nodekey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetReadersWriter ( CPN::Key_t readerkey )

virtualinherited

Parameters

readerkey a unique reader key

Returns: the writer key associated with this reader key if there is one

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 492 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_READER_INFO.

                                                                {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_READER_INFO, readerkey);
         return info["writerkey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetWriterKernel ( CPN::Key_t portkey )

virtualinherited

See Also: GetReaderKernel

Implements CPN::Context.

Definition at line 469 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_WRITER_INFO.

                                                             {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_WRITER_INFO, portkey);
         return info["kernelkey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

std::string CPN::RemoteContextClient::GetWriterName ( CPN::Key_t portkey )

virtualinherited

See Also: GetReaderName

Implements CPN::Context.

Definition at line 475 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_WRITER_INFO.

                                                               {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_WRITER_INFO, portkey);
         return info["name"].AsString();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetWriterNode ( CPN::Key_t portkey )

virtualinherited

See Also: GetReaderNode

Implements CPN::Context.

Definition at line 463 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_WRITER_INFO.

                                                           {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_WRITER_INFO, portkey);
         return info["nodekey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::GetWritersReader ( CPN::Key_t writerkey )

virtualinherited

Parameters

writerkey a unique writer key

Returns: the reader key associated with this writer

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 498 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::GetEndpointInfo(), CPN::RemoteContextClient::lock, and CPN::RCTXMT_GET_WRITER_INFO.

                                                                {
         PthreadMutexProtected plock(lock);
         Variant info = GetEndpointInfo(RCTXMT_GET_WRITER_INFO, writerkey);
         return info["readerkey"].AsNumber<Key_t>();
     }

Here is the call graph for this function:

bool CPN::RemoteContext::IsEndWrite ( )

private

Definition at line 120 of file RemoteContext.cc.

References endwrite, and CPN::RemoteContextClient::lock.

                                    {
         PthreadMutexProtected alock(lock);
         return endwrite;
     }

bool CPN::RemoteContextClient::IsTerminated ( )

virtualinherited

Returns: true if Terminate has been called

Implements CPN::Context.

Definition at line 551 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, and CPN::RemoteContextClient::shutdown.

                                            {
         PthreadMutexProtected plock(lock);
         return shutdown;
     }

shared_ptr< Context > CPN::Context::Local ( )

staticinherited

Create a local context.

Returns: a new local context.

Definition at line 29 of file Context.cc.

Referenced by CPN::Kernel::Kernel(), and CPN::VariantCPNLoader::LoadContext().

                                        {
         return shared_ptr<Context>(new LocalContext);
     }

Here is the caller graph for this function:

void CPN::RemoteContextClient::Log	(	int	level,
		const std::string &	msg
	)

virtualinherited

Log a message to this outputer.

Parameters

level	the level of this message
msg	the message

Implements LoggerOutput.

Definition at line 56 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, CPN::RemoteContextClient::loglevel, CPN::RCTXMT_LOG, and CPN::RemoteContextClient::SendMessage().

                                                                     {
         PthreadMutexProtected plock(lock);
         if (level >= loglevel) {
             Variant msg(Variant::MapType);
             msg["type"] = RCTXMT_LOG;
             msg["msg"] = logmsg;
             SendMessage(msg);
         }
     }

Here is the call graph for this function:

int CPN::RemoteContextClient::LogLevel ( ) const

virtualinherited

Returns: the current log level

Implements LoggerOutput.

Definition at line 46 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, and CPN::RemoteContextClient::loglevel.

                                             {
         PthreadMutexProtected plock(lock);
         return loglevel;
     }

int CPN::RemoteContextClient::LogLevel ( int level )

virtualinherited

Parameters

level the new log level

Returns: the new log level

Implements LoggerOutput.

Definition at line 51 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, and CPN::RemoteContextClient::loglevel.

                                                 {
         PthreadMutexProtected plock(lock);
         return loglevel = level;
     }

bool CPN::RemoteContextClient::RequireRemote ( )

virtualinherited

Lets the kernel know that this context type requires remote activity. This overrides the kernel option for remote activity. Default value is false.

Returns: true or false

Reimplemented from CPN::Context.

Definition at line 556 of file RemoteContextClient.cc.

                                             {
         return true;
     }

void CPN::RemoteContextClient::SendCreateNode	(	CPN::Key_t	kernelkey,
		const CPN::NodeAttr &	attr
	)

virtualinherited

Tell a given kernel that it needs to create a node.

Parameters

kernelkey	the id of the kernel
attr	the node attribute

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 193 of file RemoteContextClient.cc.

References CPN::NodeAttr::GetKernel(), CPN::NodeAttr::GetKey(), CPN::NodeAttr::GetName(), CPN::NodeAttr::GetParams(), CPN::NodeAttr::GetTypeName(), CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CREATE_NODE, and CPN::RemoteContextClient::SendMessage().

                                                                                   {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["msgtype"] = "kernel";
         msg["type"] = RCTXMT_CREATE_NODE;
         msg["kernelkey"] = kernelkey;
         Variant nodeattr;
         nodeattr["kernelkey"] = kernelkey;
         nodeattr["kernel"] = attr.GetKernel();
         nodeattr["name"] = attr.GetName();
         nodeattr["nodetype"] = attr.GetTypeName();
         const std::map<std::string, std::string> &params = attr.GetParams();
         for (std::map<std::string, std::string>::const_iterator i = params.begin(),
                 e = params.end(); i != e; ++i) {
             nodeattr["param"][i->first] = i->second;
         }
         nodeattr["key"] = attr.GetKey();
         msg["nodeattr"] = nodeattr;
         SendMessage(msg);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SendCreateQueue	(	CPN::Key_t	kernelkey,
		const CPN::SimpleQueueAttr &	attr
	)

virtualinherited

Tell a given kernel that it needs to create a queue.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 187 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CREATE_QUEUE, and CPN::RemoteContextClient::SendQueueMsg().

                                                                                           {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         SendQueueMsg(kernelkey, RCTXMT_CREATE_QUEUE, attr);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SendCreateReader	(	CPN::Key_t	kernelkey,
		const CPN::SimpleQueueAttr &	attr
	)

virtualinherited

Tell a given kernel that it needs to create a queue read end.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 181 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CREATE_READER, and CPN::RemoteContextClient::SendQueueMsg().

                                                                                            {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         SendQueueMsg(kernelkey, RCTXMT_CREATE_READER, attr);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SendCreateWriter	(	CPN::Key_t	kernelkey,
		const CPN::SimpleQueueAttr &	attr
	)

virtualinherited

Tell a given kernel that it needs to create a queue write end.

Parameters

kernelkey	the id of the kernel
attr	the queue attribute

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 175 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_CREATE_WRITER, and CPN::RemoteContextClient::SendQueueMsg().

                                                                                            {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         SendQueueMsg(kernelkey, RCTXMT_CREATE_WRITER, attr);
     }

Here is the call graph for this function:

void CPN::RemoteContext::SendMessage ( const Variant & msg )

protectedvirtual

Called by the functions to send a message to the RemoteContextServer.

Parameters

msg	the message

Implements CPN::RemoteContextClient.

Definition at line 64 of file RemoteContext.cc.

References FileHandle::Closed(), endwrite, sock, and FileHandle::Write().

                                                       {
         // We have the lock
         if (!sock.Closed() && !endwrite) {
             std::string message = libvariant::SerializeJSON(msg);
             //printf("<<< %s\n", message.c_str());
             unsigned numwritten = 0;
             while (numwritten < message.size() + 1) {
                 numwritten += sock.Write(message.c_str() + numwritten, (message.size() + 1) - numwritten);
             }
         }
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::SetupKernel	(	const std::string &	name,
		const std::string &	hostname,
		const std::string &	servname,
		CPN::KernelBase *	kernel
	)

virtualinherited

Called by the Kernel when it has successfully set it self up. This gives the Context a way to notify the Kernel of events and lets other Kernels look up the connection information for this Kernel.

Parameters

name	the kernel name
hostname	the hostname to use to connect to this kernel
servname	the service name the kernel is listening on
kernel	callback reference

Returns: the unique key for the new kernel

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 66 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::kernels, CPN::RemoteContextClient::lock, CPN::RCTXMT_SETUP_KERNEL, and CPN::RemoteContextClient::RemoteCall().

                                                            {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         if (!kernel) { throw std::invalid_argument("Must have non null Kernel."); }
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_SETUP_KERNEL;
         msg["name"] = name;
         msg["hostname"] = hostname;
         msg["servname"] = servname;
         Variant reply = RemoteCall(msg);
         if (!reply.Get("success", false).IsTrue()) {
            throw std::invalid_argument("Cannot create two kernels with the same name");
         }
         Key_t key = reply["kernelinfo"]["key"].AsNumber<Key_t>();
         kernels.insert(std::make_pair(key, kernel));
         return key;
     }

Here is the call graph for this function:

virtual CPN::Key_t CPN::RemoteContextClient::SetupKernel	(	const std::string &	name,
		KernelBase *	kernel
	)

inlinevirtualinherited

Called by the kernel when it is not in remote mode.

Parameters

name	the kernel name
kernel	callback reference

Returns: the unique key for the new kernel

Implements CPN::Context.

Definition at line 58 of file RemoteContextClient.h.

References ASSERT.

58 { ASSERT(false, "RemoteContextClient requires remote operation is turned on."); }

ASSERT

#define ASSERT(exp,...)

Definition: ThrowingAssert.h:62

void CPN::RemoteContextClient::SignalKernelEnd ( CPN::Key_t kernelkey )

virtualinherited

Signal to the Context that the given kernel is dead.

Parameters

kernelkey id of the kernel that died

Exceptions

std::invalid_argument

Implements CPN::Context.

Definition at line 126 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::kernels, CPN::RemoteContextClient::lock, CPN::RCTXMT_SIGNAL_KERNEL_END, and CPN::RemoteContextClient::SendMessage().

                                                              {
         PthreadMutexProtected plock(lock);
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_SIGNAL_KERNEL_END;
         msg["key"] = kernelkey;
         SendMessage(msg);
         kernels.erase(kernelkey);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SignalKernelStart ( CPN::Key_t kernelkey )

virtualinherited

Signal to the context that the given kernel has started.

Parameters

kernelkey the id for the kernel

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 166 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_SIGNAL_KERNEL_START, and CPN::RemoteContextClient::SendMessage().

                                                                {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["key"] = kernelkey;
         msg["type"] = RCTXMT_SIGNAL_KERNEL_START;
         SendMessage(msg);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SignalNodeEnd ( CPN::Key_t nodekey )

virtualinherited

Called by the node cleanup routine to indicate that the node has ended.

Parameters

nodekey the unique key for the node

Exceptions

std::invalid_argument

Implements CPN::Context.

Definition at line 315 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, CPN::RCTXMT_SIGNAL_NODE_END, and CPN::RemoteContextClient::SendMessage().

                                                          {
         PthreadMutexProtected plock(lock);
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_SIGNAL_NODE_END;
         msg["key"] = nodekey;
         SendMessage(msg);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::SignalNodeStart ( CPN::Key_t nodekey )

virtualinherited

Called by the node startup routine to indicate that the node has started.

Parameters

nodekey the unique key for the node

Exceptions

ShutdownException
std::invalid_argument

Implements CPN::Context.

Definition at line 306 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RCTXMT_SIGNAL_NODE_START, and CPN::RemoteContextClient::SendMessage().

                                                            {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_SIGNAL_NODE_START;
         msg["key"] = nodekey;
         SendMessage(msg);
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::Terminate ( )

virtualinherited

Signal to the Context that the network is terminating. After this call most methods will throw a ShutdownException.

Implements CPN::Context.

Definition at line 504 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalTerminate(), CPN::RemoteContextClient::lock, CPN::RCTXMT_TERMINATE, CPN::RemoteContextClient::SendMessage(), and CPN::RemoteContextClient::shutdown.

Referenced by EntryPoint().

                                         {
         PthreadMutexProtected plock(lock);
         if (!shutdown) {
             InternalTerminate();
             Variant msg(Variant::MapType);
             msg["type"] = RCTXMT_TERMINATE;
             SendMessage(msg);
         }
     }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::RemoteContextClient::WaitForAllNodeEnd ( )

virtualinherited

Convenience method which waits until there are no nodes running. If no node have started then this will return immediately.

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 391 of file RemoteContextClient.cc.

References ASSERT, CPN::RemoteContextClient::lock, CPN::RemoteContextClient::NewGenericWaiter(), CPN::RCTXMT_GET_NUM_NODE_LIVE, CPN::RemoteContextClient::RemoteCall(), and CPN::RemoteContextClient::shutdown.

                                                 {
         PthreadMutexProtected plock(lock);
         if (shutdown) { return; }
         GenericWaiterPtr genwait = NewGenericWaiter();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NUM_NODE_LIVE;
         Variant reply;
         try {
             reply = RemoteCall(msg);
         } catch (const ShutdownException &e) {
             return;
         }
         ASSERT(reply.Get("success", false).IsTrue(), "msg: %s", libvariant::SerializeJSON(reply).c_str());
         if (reply["numlivenodes"].AsUnsigned() == 0) {
             return;
         }
         while (true) {
             if (genwait->messages.empty()) {
                 genwait->cond.Wait(lock);
                 if (shutdown) { return; }
             } else {
                 Variant msg = genwait->messages.front();
                 genwait->messages.pop_front();
                 if (msg.Get("numlivenodes", -1).AsUnsigned() == 0) {
                     return;
                 }
             }
         }
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::WaitForKernelStart ( const std::string & kernel )

virtualinherited

Does not return until the given kernel has started.

Parameters

kernel the name of the kernel (the key may not be known yet)

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 135 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RemoteContextClient::NewGenericWaiter(), CPN::RCTXMT_GET_KERNEL_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                          {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         GenericWaiterPtr genwait = NewGenericWaiter();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_KERNEL_INFO;
         msg["name"] = kernel;
         Variant reply = RemoteCall(msg);
         if (reply.Get("success", false).IsTrue()) {
             Variant kernelinfo = reply["kernelinfo"];
             if (kernelinfo.Get("live", false).IsTrue()) {
                 return kernelinfo["key"].AsNumber<Key_t>();
             }
         }
         while (true) {
             if (genwait->messages.empty()) {
                 genwait->cond.Wait(lock);
                 InternalCheckTerminated();
             } else {
                 Variant msg = genwait->messages.front();
                 genwait->messages.pop_front();
                 if (msg.Contains("kernelinfo")) {
                     Variant kernelinfo = msg["kernelinfo"];
                     if (kernelinfo["name"].AsString() == kernel && kernelinfo["live"].IsTrue()) {
                         return kernelinfo["key"].AsNumber<Key_t>();
                     }
                 }
             }
         }
     }

Here is the call graph for this function:

void CPN::RemoteContextClient::WaitForNodeEnd ( const std::string & nodename )

virtualinherited

Waits for the given node to signal end.

Parameters

nodename the name of the node

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 355 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::lock, CPN::RemoteContextClient::NewGenericWaiter(), CPN::RCTXMT_GET_NODE_INFO, CPN::RemoteContextClient::RemoteCall(), and CPN::RemoteContextClient::shutdown.

                                                                       {
         PthreadMutexProtected plock(lock);
         if (shutdown) { return; }
         GenericWaiterPtr genwait = NewGenericWaiter();

         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NODE_INFO;
         msg["name"] = nodename;
         Variant reply;
        try {
           reply  = RemoteCall(msg);
        } catch (const ShutdownException &e) {
            return;
        }
         if (reply.Get("success", false).IsTrue()) {
             if (reply["nodeinfo"]["dead"].IsTrue()) {
                 return;
             }
         }
         while (true) {
             if (genwait->messages.empty()) {
                 genwait->cond.Wait(lock);
                 if (shutdown) { return; }
             } else {
                 Variant msg = genwait->messages.front();
                 genwait->messages.pop_front();
                 if (msg.Contains("nodeinfo")) {
                     Variant nodeinfo = msg["nodeinfo"];
                     if (nodeinfo["dead"].IsTrue() && nodeinfo["name"].AsString() == nodename) {
                         return;
                     }
                 }
             }
         }
     }

Here is the call graph for this function:

Key_t CPN::RemoteContextClient::WaitForNodeStart ( const std::string & nodename )

virtualinherited

Waits until the node starts and returns the key, if the node is already started returns the key.

Parameters

nodename the name of the node to wait for

Returns: the key for the node

Exceptions

ShutdownException

Implements CPN::Context.

Definition at line 323 of file RemoteContextClient.cc.

References CPN::RemoteContextClient::InternalCheckTerminated(), CPN::RemoteContextClient::lock, CPN::RemoteContextClient::NewGenericWaiter(), CPN::RCTXMT_GET_NODE_INFO, and CPN::RemoteContextClient::RemoteCall().

                                                                          {
         PthreadMutexProtected plock(lock);
         InternalCheckTerminated();
         GenericWaiterPtr genwait = NewGenericWaiter();
         Variant msg(Variant::MapType);
         msg["type"] = RCTXMT_GET_NODE_INFO;
         msg["name"] = nodename;
         Variant reply = RemoteCall(msg);

         if (reply.Get("success", false).IsTrue()) {
             Variant nodeinfo = reply["nodeinfo"];
             if (nodeinfo["started"].IsTrue()) {
                 return nodeinfo["key"].AsNumber<Key_t>();
             }
         }
         while (true) {
             if (genwait->messages.empty()) {
                 genwait->cond.Wait(lock);
                 InternalCheckTerminated();
             } else {
                 Variant msg = genwait->messages.front();
                 genwait->messages.pop_front();
                 if (msg.Contains("nodeinfo")) {
                     Variant nodeinfo = msg["nodeinfo"];
                     if (nodeinfo["started"].IsTrue() && nodeinfo["name"].AsString() == nodename) {
                         return nodeinfo["key"].AsNumber<Key_t>();
                     }
                 }
             }
         }
     }
