Pthread Class Reference

#include <PthreadLib.h>

Inheritance diagram for Pthread:

Collaboration diagram for Pthread:

Public Member Functions
	Pthread (void)
	Pthread (const PthreadAttr &attr)
virtual	~Pthread (void)
void	Start (void)
int	Running (void)
int	Done (void)
void *	Join (void)
	operator pthread_t * (void)
	operator pthread_t (void)
int	operator== (pthread_t t2)
int	Detach (void)
int	Cancel (void)
int	SendSignal (int sig)
int	Kill (int sig)
int	Error (void)
void	Clear (void)

Static Public Member Functions
static pthread_t	Self (void)
static void	TestCancel (void)
static void	Exit (void *value)
static int	SendSignal (pthread_t thd, int sig)
static int	Kill (pthread_t thd, int sig)
static int	GetSignalMask (sigset_t *oldSet)
static int	SetSignalMask (const sigset_t *set, sigset_t *oldSet=0)
static int	BlockSignals (const sigset_t *set, sigset_t *oldSet=0)
static int	UnblockSignals (const sigset_t *set, sigset_t *oldSet=0)
static int	CancelEnable (void)
static int	CancelDisable (void)
static int	CancelDeferred (void)
static int	CancelAsynchronous (void)

Protected Member Functions
virtual void *	EntryPoint (void)=0
void	TrapError (int result)

Protected Attributes
pthread_t	theThread
int	error

Private Types
enum	PthreadState {   uninitialized = 0, created, started, running,   done, joined, canceled }

Static Private Member Functions
static void *	PthreadEntryPoint (void *arg)
static void	PthreadCleanup (void *arg)

Private Attributes
PthreadMutex	mutex
PthreadCondition	cond
void *	returnResult
bool	inJoin
PthreadState	state

Detailed Description

Definition at line 56 of file PthreadLib.h.

Member Enumeration Documentation

enum Pthread::PthreadState

private

Enumerator
uninitialized
created
started
running
done
joined
canceled

Definition at line 89 of file PthreadLib.h.

{ uninitialized = 0, created, started, running, done, joined, canceled };

Constructor & Destructor Documentation

Pthread::Pthread

(

void

)

Definition at line 32 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, created, inJoin, mutex, PthreadEntryPoint(), returnResult, state, PthreadBase::theThread, PthreadErrorHandler::TrapError(), and uninitialized.

{
    PthreadMutexProtected p(mutex);
    returnResult = 0;
    inJoin = false;
    state = uninitialized;
    TrapError( pthread_create( &theThread, 0, PthreadEntryPoint, this) );
    state = created;
    cond.Broadcast();
}

Here is the call graph for this function:

Pthread::Pthread

(

const PthreadAttr &

attr

)

Definition at line 46 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, created, inJoin, mutex, PthreadEntryPoint(), returnResult, state, PthreadBase::theThread, PthreadErrorHandler::TrapError(), and uninitialized.

{
    PthreadMutexProtected p(mutex);
    returnResult = 0;
    inJoin = false;
    state = uninitialized;

    //  It should simply be:
//  TrapError( pthread_create(&theThread, attr, PthreadEntryPoint, this) );

    //  This is necessary because
    //      SGI's pthread_create is not const correct!!!
    pthread_attr_t* myAttr = (PthreadAttr&)attr;
    TrapError( pthread_create(&theThread, myAttr, PthreadEntryPoint, this) );
    state = created;
    cond.Broadcast();
}

Here is the call graph for this function:

Pthread::~Pthread ( void  )

virtual

Definition at line 67 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), canceled, cond, created, Join(), mutex, running, Start(), started, state, and uninitialized.

{
    try {
        // Force the thread to terminate if it has not already done so.
        // Is it safe to do this to a thread that has already terminated?

        bool need_start = false;
        {
            PthreadMutexProtected p(mutex);
            switch (state) {
                case uninitialized:
                    // should be impossible
                    return;
                case created:
                    need_start = true;
                case started:
                case running:
                    state = canceled;
                    cond.Broadcast();
                default:
                    break;
            }
        }

        if (need_start) { Start(); }
        // Now wait.
        Join();
    } catch (...) {
        std::terminate();
    }
}

Here is the call graph for this function:

Member Function Documentation

static int PthreadBase::BlockSignals ( const sigset_t *  set, sigset_t *  oldSet = 0  )

inlinestaticinherited

Definition at line 77 of file PthreadBase.h.

                                    { return pthread_sigmask(SIG_BLOCK, set, oldSet); }

int PthreadBase::Cancel ( void  )

inlineinherited

Definition at line 59 of file PthreadBase.h.

References PthreadBase::theThread.

{ return pthread_cancel(theThread); }

int PthreadBase::CancelAsynchronous ( void  )

staticinherited

Definition at line 105 of file PthreadBase.cc.

{
    int oldState;
    pthread_setcanceltype(PTHREAD_CANCEL_ASYNCHRONOUS, &oldState);
    return oldState;
}

int PthreadBase::CancelDeferred ( void  )

staticinherited

Definition at line 95 of file PthreadBase.cc.

{
    int oldState;
    pthread_setcanceltype(PTHREAD_CANCEL_DEFERRED, &oldState);
    return oldState;
}

int PthreadBase::CancelDisable ( void  )

staticinherited

Definition at line 86 of file PthreadBase.cc.

{
    int oldState;
    pthread_setcancelstate(PTHREAD_CANCEL_DISABLE, &oldState);
    return oldState;
}

int PthreadBase::CancelEnable ( void  )

staticinherited

Definition at line 76 of file PthreadBase.cc.

{
    int oldState;
    pthread_setcancelstate(PTHREAD_CANCEL_ENABLE, &oldState);
    return oldState;
}

void PthreadErrorHandler::Clear ( void  )

inlineinherited

Definition at line 40 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

{ error = 0; }

int PthreadBase::Detach ( void  )

inlineinherited

Definition at line 58 of file PthreadBase.h.

References PthreadBase::theThread.

{ return pthread_detach(theThread); }

int Pthread::Done ( void  )

inline

Returns

true if Joining would not block.

Definition at line 72 of file PthreadLib.h.

References done, joined, mutex, and state.

                   {
        PthreadMutexProtected p(mutex);
        return state == done || state == joined;
    }

virtual void* Pthread::EntryPoint ( void  )

protectedpure virtual

Implemented in PthreadFunctionalTemplate< T >, and PthreadFunctional.

Referenced by PthreadEntryPoint().

Here is the caller graph for this function:

int PthreadErrorHandler::Error ( void  )

inlineinherited

Definition at line 39 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

{ return error; }

static void PthreadBase::Exit ( void *  value )

inlinestaticinherited

Definition at line 64 of file PthreadBase.h.

{ pthread_exit(value); }

static int PthreadBase::GetSignalMask ( sigset_t *  oldSet )

inlinestaticinherited

Definition at line 73 of file PthreadBase.h.

                                    { return pthread_sigmask(SIG_SETMASK, 0, oldSet); }

void * Pthread::Join

(

void

)

Definition at line 108 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, inJoin, joined, mutex, returnResult, state, PthreadBase::theThread, PthreadErrorHandler::TrapError(), and PthreadCondition::Wait().

Referenced by ~Pthread().

                        {
    void *result = 0;
    {
        PthreadMutexProtected p(mutex);
        if (inJoin || state == joined) {
            while (state != joined) {
                cond.Wait(mutex);
            }
            return returnResult;
        }
        inJoin = true;
    }
    TrapError( pthread_join(theThread, &result) );
    {
        PthreadMutexProtected p(mutex);
        returnResult = result;
        state = joined;
        cond.Broadcast();
        return returnResult;
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

int PthreadBase::Kill ( int  sig )

inlineinherited

Definition at line 68 of file PthreadBase.h.

References PthreadBase::theThread.

{ return pthread_kill(theThread, sig); }

static int PthreadBase::Kill ( pthread_t  thd, int  sig  )

inlinestaticinherited

Definition at line 71 of file PthreadBase.h.

{ return pthread_kill(thd, sig); }

PthreadBase::operator pthread_t ( void  )

inlineinherited

Definition at line 52 of file PthreadBase.h.

References PthreadBase::theThread.

{ return theThread; }

PthreadBase::operator pthread_t * ( void  )

inlineinherited

Definition at line 51 of file PthreadBase.h.

References PthreadBase::theThread.

{ return &theThread; }

int PthreadBase::operator== ( pthread_t  t2 )

inlineinherited

Definition at line 54 of file PthreadBase.h.

References PthreadBase::theThread.

{ return pthread_equal(theThread, t2); }

void Pthread::PthreadCleanup ( void *  arg )

staticprivate

Definition at line 154 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, done, mutex, and state.

Referenced by PthreadEntryPoint().

{
    Pthread* ptr = (Pthread*) arg;
    PthreadMutexProtected p(ptr->mutex);
//  ptr->Cleanup();     // the sub-classes have already been destructed
    ptr->state = done;
    ptr->cond.Broadcast();
}

Here is the call graph for this function:

Here is the caller graph for this function:

void * Pthread::PthreadEntryPoint ( void *  arg )

staticprivate

Definition at line 131 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, created, EntryPoint(), mutex, PthreadCleanup(), running, started, state, PthreadBase::TestCancel(), and PthreadCondition::Wait().

Referenced by Pthread().

{
    void* result = 0;
    Pthread* ptr = (Pthread*) arg;
    {
        PthreadMutexProtected p(ptr->mutex);
        while (ptr->state == created) {
            ptr->cond.Wait(ptr->mutex);
        }
        if (ptr->state != started) return 0;
        ptr->state = running;
        ptr->cond.Broadcast();
    }
    TestCancel();
    pthread_cleanup_push( PthreadCleanup, ptr);
    result = ptr->EntryPoint();
    pthread_cleanup_pop(1);
    return result;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int Pthread::Running ( void  )

inline

Definition at line 64 of file PthreadLib.h.

References mutex, running, and state.

                      {
        PthreadMutexProtected p(mutex);
        return state == running;
    }

static pthread_t PthreadBase::Self ( void  )

inlinestaticinherited

Definition at line 61 of file PthreadBase.h.

Referenced by PthreadBase::PthreadBase().

{ return pthread_self(); }

Here is the caller graph for this function:

int PthreadBase::SendSignal ( int  sig )

inlineinherited

Definition at line 67 of file PthreadBase.h.

References PthreadBase::theThread.

{ return pthread_kill(theThread, sig); }

static int PthreadBase::SendSignal ( pthread_t  thd, int  sig  )

inlinestaticinherited

Definition at line 70 of file PthreadBase.h.

{ return pthread_kill(thd, sig); }

static int PthreadBase::SetSignalMask ( const sigset_t *  set, sigset_t *  oldSet = 0  )

inlinestaticinherited

Definition at line 75 of file PthreadBase.h.

                                    { return pthread_sigmask(SIG_SETMASK, set, oldSet); }

void Pthread::Start

(

void

)

Definition at line 100 of file PthreadLib.cc.

References PthreadCondition::Broadcast(), cond, created, mutex, started, and state.

Referenced by ~Pthread().

                        {
    PthreadMutexProtected p(mutex);
    if (state == created) {
        state = started;
        cond.Broadcast();
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void PthreadBase::TestCancel ( void  )

inlinestaticinherited

Definition at line 63 of file PthreadBase.h.

Referenced by PthreadEntryPoint().

{ pthread_testcancel(); }

Here is the caller graph for this function:

void PthreadErrorHandler::TrapError ( int  result )

inlineprotectedinherited

Definition at line 48 of file PthreadErrorHandler.h.

References PthreadErrorHandler::error.

Referenced by PthreadCondition::Broadcast(), PthreadAttr::DetachState(), PthreadBase::Join(), Join(), PthreadMutex::Lock(), PthreadMutex::Poll(), Pthread(), PthreadAttr::PthreadAttr(), PthreadBase::PthreadBase(), PthreadCondition::PthreadCondition(), PthreadConditionAttr::PthreadConditionAttr(), PthreadKey< T >::PthreadKey(), PthreadMutex::PthreadMutex(), PthreadMutexAttr::PthreadMutexAttr(), PthreadReadWriteLock::ReadUnlock(), PthreadAttr::ScheduleScope(), PthreadKey< T >::Set(), PthreadCondition::Signal(), PthreadCondition::TimedWait(), PthreadMutex::Unlock(), PthreadCondition::Wait(), PthreadReadWriteLock::WriteUnlock(), PthreadAttr::~PthreadAttr(), PthreadCondition::~PthreadCondition(), PthreadConditionAttr::~PthreadConditionAttr(), PthreadKey< T >::~PthreadKey(), PthreadMutex::~PthreadMutex(), and PthreadMutexAttr::~PthreadMutexAttr().

{
    if (err) {
        error = err;
        throw ErrnoException(err);
    }
}

Here is the caller graph for this function:

static int PthreadBase::UnblockSignals ( const sigset_t *  set, sigset_t *  oldSet = 0  )

inlinestaticinherited

Definition at line 79 of file PthreadBase.h.

                                    { return pthread_sigmask(SIG_UNBLOCK, set, oldSet); }

Member Data Documentation

PthreadCondition Pthread::cond

private

Definition at line 85 of file PthreadLib.h.

Referenced by Join(), Pthread(), PthreadCleanup(), PthreadEntryPoint(), Start(), and ~Pthread().

int PthreadErrorHandler::error

protectedinherited

Definition at line 43 of file PthreadErrorHandler.h.

Referenced by PthreadErrorHandler::Clear(), PthreadErrorHandler::Error(), PthreadErrorHandler::PthreadErrorHandler(), and PthreadErrorHandler::TrapError().

bool Pthread::inJoin

private

Definition at line 87 of file PthreadLib.h.

Referenced by Join(), and Pthread().

PthreadMutex Pthread::mutex

private

Definition at line 84 of file PthreadLib.h.

Referenced by Done(), Join(), Pthread(), PthreadCleanup(), PthreadEntryPoint(), Running(), Start(), and ~Pthread().

void* Pthread::returnResult

private

Definition at line 86 of file PthreadLib.h.

Referenced by Join(), and Pthread().

PthreadState Pthread::state

private

Definition at line 90 of file PthreadLib.h.

Referenced by Done(), Join(), Pthread(), PthreadCleanup(), PthreadEntryPoint(), Running(), Start(), and ~Pthread().

pthread_t PthreadBase::theThread

protectedinherited

Definition at line 126 of file PthreadBase.h.

Referenced by PthreadBase::Cancel(), PthreadBase::Detach(), PthreadBase::Join(), Join(), PthreadBase::Kill(), PthreadBase::operator pthread_t(), PthreadBase::operator pthread_t *(), PthreadBase::operator==(), Pthread(), PthreadBase::PthreadBase(), and PthreadBase::SendSignal().

---

The documentation for this class was generated from the following files:

• include/cpn/threading/PthreadLib.h
• lib/threading/PthreadLib.cc
