CPN::PacketEncoder Class Reference

#include <PacketEncoder.h>

Inheritance diagram for CPN::PacketEncoder:

Public Member Functions
	PacketEncoder ()
virtual	~PacketEncoder ()
template<typename Queue_t >
void	SendEnqueue (const Packet &packet, Queue_t &queue)
void	SendPacket (const Packet &packet)
void	SendPacket (const Packet &packet, void *data)

Protected Member Functions
virtual void	WriteBytes (const iovec *iov, unsigned iovcnt)=0

Detailed Description

Take the various message types that can be sent over the wire and encode them into byte representation.

Definition at line 38 of file PacketEncoder.h.

Constructor & Destructor Documentation

CPN::PacketEncoder::PacketEncoder

(

)

Definition at line 28 of file PacketEncoder.cc.

{}

CPN::PacketEncoder::~PacketEncoder ( )

virtual

Definition at line 30 of file PacketEncoder.cc.

{}

Member Function Documentation

template<typename Queue_t >

void CPN::PacketEncoder::SendEnqueue ( const Packet &  packet, Queue_t &  queue  )

inline

Definition at line 44 of file PacketEncoder.h.

References ASSERT, CPN::Packet::Count(), CPN::Packet::header, CPN::PACKET_ENQUEUE, and CPN::Packet::Type().

                                                               {
            ASSERT(packet.Type() == PACKET_ENQUEUE);
            std::vector<iovec> iovs;
            // Must use const_cast here because iovec.iov_base isn't const... :(
            iovec header = { const_cast<PacketHeader*>(&packet.header), sizeof(packet.header) };
            iovs.push_back(header);
            for (unsigned i = 0; i < queue.NumChannels(); ++i) {
                iovec iov;
                iov.iov_base = const_cast<void*>(queue.GetRawDequeuePtr(packet.Count(), i));
                ASSERT(iov.iov_base);
                iov.iov_len = packet.Count();
                iovs.push_back(iov);
            }
            WriteBytes(&iovs[0], iovs.size());
            queue.Dequeue(packet.Count());
        }

Here is the call graph for this function:

void CPN::PacketEncoder::SendPacket

(

const Packet &

packet

)

Definition at line 32 of file PacketEncoder.cc.

References CPN::Packet::header, and WriteBytes().

Referenced by CPN::RemoteQueue::SendD4RTagPacket(), CPN::RemoteQueue::SendDequeuePacket(), CPN::RemoteQueue::SendEndOfReadPacket(), CPN::RemoteQueue::SendEndOfWritePacket(), CPN::RemoteQueue::SendFlushPacket(), CPN::RemoteQueue::SendGrowPacket(), CPN::RemoteQueue::SendReadBlockPacket(), CPN::RemoteQueue::SendResetPacket(), and CPN::RemoteQueue::SendWriteBlockPacket().

                                                       {
        iovec iov;
        iov.iov_base = const_cast<PacketHeader*>(&packet.header);
        iov.iov_len = sizeof(packet.header);
        WriteBytes(&iov, 1);
    }

Here is the call graph for this function:

Here is the caller graph for this function:

void CPN::PacketEncoder::SendPacket	(	const Packet &	packet,
		void *	data
	)

Definition at line 39 of file PacketEncoder.cc.

References ASSERT, CPN::Packet::DataLength(), CPN::Packet::header, and WriteBytes().

                                                                   {
        ASSERT(data);
        iovec iov[2];
        iov[0].iov_base = const_cast<PacketHeader*>(&packet.header);
        iov[0].iov_len = sizeof(packet.header);
        iov[1].iov_base = data;
        iov[1].iov_len = packet.DataLength();
        WriteBytes(&iov[0], 2);
    }

Here is the call graph for this function:

virtual void CPN::PacketEncoder::WriteBytes ( const iovec *  iov, unsigned  iovcnt  )

protectedpure virtual

Implemented in CPN::RemoteQueue.

Referenced by SendPacket().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• lib/PacketEncoder.h
• lib/PacketEncoder.cc
