NodeBase.h File Reference

The base definition of all nodes. More...

#include <cpn/common.h>
#include <cpn/NodeAttr.h>
#include <cpn/NodeFactory.h>
#include <cpn/bits/PseudoNode.h>
#include <cpn/utils/ParseBool.h>
#include <sstream>
#include <map>
#include <string>
#include <stdexcept>

Include dependency graph for NodeBase.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	CPN::NodeBasePrivate::CoerceParam< T >
struct	CPN::NodeBasePrivate::CoerceParam< bool >
class	CPN::NodeBase
	The definition common to all nodes in the process network. More...

Namespaces
	CPN
	CPN::NodeBasePrivate

Macros
#define	CPN_DECLARE_NODE_FACTORY(type, klass)
#define	CPN_DECLARE_NODE_AND_FACTORY(type, klass)

Detailed Description

The base definition of all nodes.

Author

John Bridgman

Definition in file NodeBase.h.

Macro Definition Documentation

#define CPN_DECLARE_NODE_AND_FACTORY	(		type,
			klass
	)

Value:

class klass : public CPN::NodeBase { \
    public : klass(CPN::Kernel &kern, const CPN::NodeAttr& attr) : CPN::NodeBase(kern,attr) {} \
    private: void Process(); }; \
CPN_DECLARE_NODE_FACTORY(type,klass)

Definition at line 134 of file NodeBase.h.

#define CPN_DECLARE_NODE_FACTORY	(		type,
			klass
	)

Value:

class type ## Factory : public CPN::NodeFactory {\
    public: type ## Factory() : CPN::NodeFactory(#type) {}\
    CPN::shared_ptr<CPN::NodeBase> Create(CPN::Kernel &ker, const CPN::NodeAttr &attr) { return CPN::shared_ptr<CPN::NodeBase>(new klass(ker, attr)); }};\
extern "C" CPN::shared_ptr<CPN::NodeFactory> cpninit ## type (void);\
CPN::shared_ptr<CPN::NodeFactory> cpninit ## type (void) { return CPN::shared_ptr<CPN::NodeFactory>(new type ## Factory); }

Definition at line 128 of file NodeBase.h.
